1. Introducing the Kart Logger

1. Introducing the Kart Logger
The STACK Dash-2 Kart Logger monitors and displays a range of values, known as performance parameters, needed for effective kart
and driver management in most competitive situations.
The system combines an analogue tachometer with a digital display for the following performance parameters:
1. Engine speed (RPM)
2. Wheel Speed
3. Cylinder Head Temperature (CHT) (option)
4. Water Temperature (option)
5. Exhaust Gas Temperature (EGT) (option)
6. Battery Voltage
7. Lap Times
8. Steering Position (option)
9. Throttle Position (option)
10. Brake Position (option)
11. Lateral Acceleration (option)
12. Maximum and minimum corner speeds display (option)
Performance Meter (option)
13.
You can view the peak values (tell-tales) for all the parameters except lateral g, steering, throttle and brake.
The system provides a range of warning messages based on preset alarm values for the following performance parameters:
1. High Cylinder Head Temperature
2. High Exhaust Gas Temperature
3. High Water Temperature
4. Low Battery Voltage
5. Low Lithium Battery Voltage
You can enable or disable the warning system for each parameter individually.
You can redefine preset alarm values to values that are more suitable for your kart.
The system provides a gear shift warning light that is based on an RPM value that you define for your kart.

How to Use this Manual

STACK recommends that you unpack and connect the components in the system
to familiarise yourself with operating the display and configuring it for the kart.
Users Guide
1. Introducing the Kart Logger
you install it in your kart. This will enable you
before
