2. Getting Started
Connecting the Components
1.
Connect each of the sensors that you have purchased to the appropriate wire in the wiring harness, as listed above.
2.
Insert a charged 9.6v battery pack into the battery tray on the rear of the
white power connections..
3.
Switch the unit on by means of the switch on the rear .
You can now proceed to familiarise yourself with operating the Display Module.
Picture of rear showing battery fitting and power switch.
6
STACK Dash-2 Kart Logger
Kart Logger and connect the
Dash-2
Users Guide
