BUTTERFLY
S
D
I
I
HOWER
OOR
NSTALLATION
NSTRUCTIONS
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time
TM
without prior notice. For the latest up-to-date technical drawings, manuals or any
other details please refer to the
support.BathAuthority.com
web page.
Please carefully read the instructions before installing. If you have any questions
regarding installation, please call our technical support specialists Monday through
Friday 9:00 AM – 5:00 PM EST at 1-866-731-8378, ext. 3 or e-mail our technical
support@BathAuthority.com.
support group at
TM
For more information on
DreamLine
Shower Door
please visit
www.BathAuthority.com
Rev 1.1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BUTTERFLY and is the answer not in the manual?

Questions and answers

Related Manuals for Dreamline BUTTERFLY

Summary of Contents for Dreamline BUTTERFLY

  • Page 1 BUTTERFLY HOWER NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page. Please carefully read the instructions before installing. If you have any questions regarding installation, please call our technical support specialists Monday through Friday 9:00 AM –...

  • Page 2: Tools Required

    3. Please note that you should consult your local building codes on questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not responsible for code compliance standards for your project. 4. Please insure that prior to the installation the installation surface is leveled and solid and will be able to support the total weight of the unit.

  • Page 3: Packing List

    Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
  • Page 4 Shower Door Assembly NOTICE: The installation presented here is for the left door opening. For the right door opening, you will need to rotate the frame 180 degrees. 1. Place the Glass door A (04) and the Glass door B (05) on a flat surface.
  • Page 5 3. Attach the top and the bottom Rollers (12) to the right edge of the Glass Door B (05). Mind the position of the rollers on the glass. See Fig. 3 and Fig. 5 for details. 4. Connect the Glass door A (04) to the Glass door B (05) using the top and the bottom Middle hinges (11).
  • Page 6 5. Locate the Guide rails (03) and the Glass profile (02). Connect the left end of the Guide rails to the Glass profile using the Round head screws ST4.2×30 (09). See fig. 6 for details. NOTICE: Make sure that the Seal strip flange on the Glass profile, pointing inside the Shower.
  • Page 7 6. Slide the glass unit into the channel of the Guide rails (03) from the right side. See Fig. 7 and Fig. 8 for details. Rev 1.1...
  • Page 8 7. Secure the Hinges (13) inside the Guide rails (03) using the Round head screws ST4.2×12 (08). See Fig. 9 for details. 8. Attach another Glass profile (02) at the right side of the glass unit and fasten it to the Guide rails (03) with the Round head screws ST4.2×30 (09).
  • Page 9 . 11 9. Secure the Roller stoppers (16) inside the top and the bottom Guide rails (03) with the Round head screw ST4.2×12 (08). See Fig. 12 for details. . 12 Rev 1.1...
  • Page 10 10. Install the Shower base according to the Shower base installation manual See Fig. 13 for details. . 13 11. Locate the Wall profiles (01) in the package. See fig. 14 for details. . 14 Rev 1.1...
  • Page 11 12. Push the Wall profiles (01) over the Glass profiles (02) on both sides. Be sure to keep the flange with predrilled holes inside the shower. See fig. 15 for details. . 15 13. Move the assembled Glass unit on the Shower base and butt up the Wall profiles (01) against the walls.
  • Page 12 14. Outline the Wall profiles (01) from inside of the Shower. Move the Glass unit aside. Remove the Wall Ø 5/16 profiles from the Glass unit and place them back on the wall. Mark the drill holes through the predrilled holes on the Wall profiles (01).
  • Page 13 16. Fold the Glass door, and adjust the bolts on the Rollers (12) to make the door slide smoothly. See fig. 19 for details. . 19 17. Mount the Handle (07) onto the glass door. Open the door and attach Anti-water strip (15) to the vertical edge of the Glass door.

  • Page 14: Product Maintenance

    18. Apply the silicone along the Wall profiles (01), as well as along the Guide rail (03). See Fig. 21 for details. NOTICE: Any adjustment to make the door stable can be applied on the bolts of hinges and hardware during the installation or after use. This door is reversible from right to left opening.

  • Page 15: Warranty

    Any product replaced or repaired during the warranty period will be covered only for the remaining period of the original warranty. In no event will DreamLine be liable for costs of repair or replacement of any installation material, including but not limited to tiles, marble, etc.
  • Page 16 TEL: 866-731-8378 – 215-957-1411 FAX: 866-227-9245 – 215-893-1780 WWW.B .COM UTHORITY For more information on DreamLine Shower Doors please visit www.BathAuthority.com Rev 1.1...
