- Page 2 WARNING - WHEN USING ELECTRIC PRODUCTS, THESE BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use apparatus near water - for example, but not limited to: near a bathtub, washbowl, kitchen sink, in a wet basement, or near a swimming pool or the like.
- Page 3 Thank you for purchasing the new MisMatcher Petite, from Freedom Enterprise. This patchable, compact video effects unit is based around the original MisMatcher01, sporting most of its circuitry but with a simplified layout. It was designed to provide beginners in the realm of video art with a powerful yet handy tool they can get accustomed to.
- Page 4 Important Safety Instructions Contents User Interface Principle of operation Basics of Analog Video Signals Sync Separator And Sync Mixer Enhancer Patch Examples Specifications Warranty...
- Page 5 Micro USB Power Sync Mixer Input Enhancer Input Sync Separator Input Enhancer Output Sync Mixer Ouput Enhancer’s Gain Enhancer’s Feedback 1 Enhancer’s Feedback 2...
- Page 6 Sync Separator Input Sync Separator Sync Mixer Input Sync Mixer Sync Mixer Ouput Enhancer Input Enhancer Enhancer Output Gain Feedback 1 Feedback 2...
- Page 7 MisMatcher Petite, you’ll need mono 3.5mm patch cables. The MisMatcher Petite, like a guitar pedal, is used inline in between the source of the signal and its destination. A quick example would be a camera connected to the Enhancer In and the Enhancer Out connected to a monitor.
- Page 8 Colour H SYNC Burst Video One Raster Line A composite video signal, or CVBS, is comprised of colour or chroma, video or luma, blanking and sync information in only one channel. CRT monitors draw images using a process called raster scan, where the image is drawn line by line, from top to bottom, left to right.
- Page 9 syncing pulse which lets the monitor know it’s time to draw a new line. After that we have the colour burst, which gives the base reference for the colours to be drawn. Next, we have the picture information which contains the luma, brightens information and chroma, HUE and saturation.
- Page 10 The key to a stable picture is a good sync signal. The distortion of video signals can deteriorate sync, leading to horizontal or vertical scrolling of video on screen. When the loss of sync is undesired by the user, the Sync Separator and Sync Mixer can come into play.
- Page 11 This enhancer can be used to either boost saturation and sharpness of the video or, using the provided Gain and Feedback 1 and 2 controls, to distort the video and create interesting effects. The gain controls how much the signal is amplified. Feedback 1 and 2 takes video from different stages of the circuit and feeds it back into the Enhancer’s input.
- Page 12 The following are examples of possible patches on the MisMatcher Petite. You should explore all possible connections within the MisMatcher Petite and with other effects, even sound oriented effects like guitar pedals. Camera Monitor Here we simply connect a camera to the enhancer In and a monitor to the enhancer out.
- Page 13 Camera Camera Monitor In this instance we resync camera A to camera’s B sync signal, resulting in a scrolling image in monitor A.
- Page 14 Camera Monitor In this example we use the enhancer to distort a video signal, then run it through the sync mixer to restore its sync, so we can always obtain a stable picture in Monitor A.
- Page 15 Size: 49x65x24mm. DC Input: 5 V.
- Page 16 Fully assembled versions of this product are covered by warranty for one year following the date of purchase. This warranty covers any defect in the manufacturing of this product, such as assembly errors or faulty components. This warranty does not cover any damage or malfunction caused by incorrect use, such as, but not limited to, power cables connected backwards, excessive voltage levels, or exposure to extreme temperature or moisture levels.
- Page 17 Mismatcher Petite | Owner’s Manual | Revision B April 2021 Written by Pedro Silva | Art by Seni freedomenterprise.pt | help@freedomenterprise.pt © 2021 Freedom Enterprise Note: Specifications subject to change without notice...
