Rear Suspension
Hintere Aufhängung
<Right>
<Rechts>
T02093 Ball stud - short
Kugelkopf kurz
.....................2
T02034 2x9.8 Shaft
Schaft
.....................2
22
Rear Suspension
Hintere Aufhängung
T02057 2.3 E-ring
..............................4
T02013 3.1x6x1 Plastic Washer
Beilagscheibe
...........................2
Assemble left and right sides the same way
L
R
Beide Seiten (links/rechts) auf die gleiche
Weise montieren
T02058
T02100 5x10x4 Ball Bearing
Kugellager
...............4
T02057 3x30.5 Hinge pin Rear outer
Welle hinten außen
............2
Apply grease
Schmiermittel verwenden
T02013
T02100
T02057
11
<Left>
<Links>
T02093
T02100
T02034
T02057
T02013
T02057
TU0254
L
R
L
R
