13
Main Gear
Hauptantrieb
T02084 M4 Flanged Nylon Nut
Flansch Nylon Mutter
............1
T02039
T02040
T02084
14
Rear Damper Tower
Hintere Dämpferbrücke
T02082 M3x10 Screw
Schraube
..................4
T02082 M3x22 Screw
Schraube
......2
T02063 5mm Ball stud
Kugelkopf
...........................2
T02001
T02038
T02021
T02063
T02025
T02039
T02038
T02082(M3x22)
7
approx.18mm
circa.18mm
T02082(M3x10)
T02082(M3x22)
T02063
