- Page 1 ARGUS ARGUS GigaBit Ethernet Manual Version: 1.04 / EN Important notice: Depending on the scope of the functions delivered, certain menu items may be hidden. ARGUS...
- Page 2 Form (Druck, Fotokopie, Mikrofilm oder einem anderen Verfahren) ohne schriftliche Genehmigung reproduziert, vervielfältigt oder verbreitet werden. All rights are reserved. No one is permitted to reproduce or duplicate, in any form, the whole or part of this document without intec´s permission. ARGUS...
-
Page 3: Table Of Contents
ARGUS Introduction ..................4 Operation on an Ethernet access ............5 Ethernet Settings ................7 Setting the Ethernet interface and access mode ......10 Loop (GigE) ..................16 Traffic generator (GigE) ..............20 Appendix ...................27 Acronyms ...................27 Software Licenses ................29 Index ....................30 ARGUS... -
Page 4: Introduction
An overview of a few of the important Gigabit Ethernet functions: Gigabit Ethernet Traffic generator Gigabit Ethernet Loop Should you have any further questions, please contact us: intec Gesellschaft für Informationstechnik mbH Rahmedestr. 90 D-58507 Lüdenscheid Tel.: +49 (0) 2351 / 9070-0 Fax: +49 (0) 2351 / 9070-70 www.argus.info/en... -
Page 5: Operation On An Ethernet Access
2 Operation on an Ethernet access 2 Operation on an Ethernet access In Ethernet mode, the ARGUS supports the following types of access: The individual tests record and store data. The user must comply with the statutory regulations governing the collection and storage of such data and his obligation to give notice in this connection.... - Page 6 2 Operation on an Ethernet access Connection to a PPTP Router/Modem: PPTP Router/ Patch cable Modem e. g. xDSL Ethernet LAN 2 jack e. g. an xDSL access Connection to a PC via IP Patch cable Ethernet LAN 2 / SFP 1 jack ...
-
Page 7: Ethernet Settings
2 Operation on an Ethernet access 2.1 Ethernet Settings Setting Explanation Access parameters: Phys. parameters: Ethernet: Switch on or off. Auto- negotiaion If autonegotiation is enabled, a network card can independently determine the correct transmission speed and duplex setting for the network port to which it is connected and can then configure itself accordingly. - Page 8 2 Operation on an Ethernet access Enter the MAC address in hexadecimal from the keypad and the softkeys <A..F> (e.g. to enter a “C” press the softkey three times or for an “F” six times; conclude by pressing to confirm your entry).
- Page 9 2 Operation on an Ethernet access Autonegotiation / Ethernet link parameter The default setting supports "autonegotiation" for the Ethernet link. Setting: Autonegotiation "on" When negotiating the link parameters, the ARGUS notifies the remote end that the follow- ing is supported (these settings are fixed; they cannot be reconfigured): 10, 100 or 1000 Mbit/s half or full-duplex Flow control on / off (when on: sym.
-
Page 10: Setting The Ethernet Interface And Access Mode
2 Operation on an Ethernet access 2.2 Setting the Ethernet interface and access mode Use the included patch cable to connect the ARGUS as a PC replacement to the modem, a ONT, a hub, a switch or a PC and then switch the ARGUS on. The initial display will depend on the access setting used last (in the examples ADSL and Ethernet): The access menu: Using... - Page 11 2 Operation on an Ethernet access The ARGUS will use the marked Ethernet LAN2 access type. ARGUS opens the Status display. ARGUS Status display The ARGUS will use the default (preset) profile to set up the Ethernet connection (in this example, Profile 1) as well as the marked Ethernet jack (in this example LAN 2 jack).
- Page 12 2 Operation on an Ethernet access Display: - current connection status Displays the Ethernet <Info> connection parameters Displays the tests possible <Test> Disables the Ethernet <Stop> connection - Autonegotiation setting - Autonegotiation on the remote end - Negotiated speed - Type of duplex mode - Flow control setting Opens Ethernet statistics...
- Page 13 2 Operation on an Ethernet access Statistics display: Ethernet frames received (Rx) and sent (Tx) Bytes received (Rx) and sent (Tx) Number of errors on the receiving (Rx) and sending (Tx) sides Number of collisions Hotkey Assignment Hotkey Service Numeric key 0 ARGUS-Status Numeric key 1 Help hotkeys Numeric key 3 IP ping Numeric key 4 Trace route...
- Page 14 2 Operation on an Ethernet access Clear down the Ethernet connection and save the results Status screen Clear down the Ethernet connection. ...
- Page 15 2 Operation on an Ethernet access Once the results have been successfully saved in memory, the ARGUS will return to the Status screen or ARGUS Status Display. A new sync attempt can be started by pressing <Start>....
-
Page 16: Loop (Gige)
3 Loop (GigE) 3 Loop (GigE) This Loop will take all incoming Ethernet frames at Layer 1 (L1) and send them back to the sender unchanged. In the case of a Loop on Layer 2 (L2) of the OSI model, the ARGUS swaps the source MAC address with the destination MAC address and then sends all the incoming Ethernet frames back. - Page 17 3 Loop (GigE) Select the test to be configured Loop (in this example, Loop). Settings - Mode - Layer select and edit. Quit the menu without saving the changes. View and edit the marked parameters if necessary ...
- Page 18 3 Loop (GigE) Start Loop (Access Mode: Ethernet) Set up the Ethernet connection The profile shown in the display (in this example, Profile 1) will be used for the Loop. Activates Ethernet <Start> ...
- Page 19 3 Loop (GigE) The Loop is started: Current duration of the test. Duration Number of packets looped so Looped far. Number of packets looped Looped during the current second. in 1 sec. Current data throughput per Through- second. Own MAC address of the looping device (e.g.
-
Page 20: Traffic Generator (Gige)
4 Traffic generator (GigE) 4 Traffic generator (GigE) Use the ARGUS Traffic generator to check the capacity of Ethernet connections. When the ARGUS Traffic generator is used together with a Loop, this will help you to estimate the maximum possible throughput for this Ethernet connection. The following parameters are required for the Traffic generator: ... - Page 21 4 Traffic generator (GigE) Settings select and edit. Quit the menu without saving the changes. View and edit the Loop marked parameters if necessary Setting Explanation Test parameters: Traffic generator: Determine the bandwidth that the ARGUS will generate with the Traffic Bandwidth generator....
- Page 22 4 Traffic generator (GigE) Enter the destination MAC address, the address of the remote end. Destina- tion MAC Default setting: 00 00 00 00 00 00 address ARGUS shows the last used or the stored MAC address. ...
- Page 23 4 Traffic generator (GigE) Move the cursor within the line. Delete the character in front <Delete> of the cursor. Enter and select the <A..F> characters A to F. Enter the destination IP address of the remote end. Destina- tion IP Range: 0.0.0.0 to 255.255.255.255...
- Page 24 4 Traffic generator (GigE) Start Traffic generator Set up the Ethernet connection The profile shown in the display (in this example, Profile 1) will be used for the Traffic generator. Activates Ethernet <Start> ...
- Page 25 4 Traffic generator (GigE) During the Traffic generation, it shows: Data rates in kbit/s Current transmitted (Tx) and received (Rx) line rate Current transmitted (Tx) and received (Rx) frame rate Frame statistics Current transmitted (Tx) and received (Rx) frames, which are OK Current transmitted (Tx) and received (Rx), which are not OK Duration of the Traffic generator...
- Page 26 4 Traffic generator (GigE) Duration of the Traffic generator Used frame size Used IP and MAC addresses Displays the Status screen <Status> without stopping the test Starts a new test <Neu> Saving the results The results of the Traffic generator test are saved in the same manner as for an Ethernet access, see page 14.
-
Page 27: Appendix
5 Appendix 5 Appendix A) Acronyms ADSL Asymmetric Digital Subscriber Line Average Bit/s Bit per second Del. Delete Ethernet File Transfer Protocol FTTx Collective term for different fiber connectivity technology Giga (10 GigE Gigabit-Ethernet hour HTTP Hypertext Transfer Protocol IEEE Institute of Electrical and Electronics Engineers Internet Protocol IPTV... - Page 28 5 Appendix Normal Link Pulses Not OK Nano seconds Optical Network Terminal Open Systems Interconnection Personal Computer Phys. Physical Power over Ethernet Point-to-Point Protocol PPTP Point-to-Point Tunneling Protocol Request for Comments Registered Jack (standardized jack) Received Second Small Form-factor Pluggable SHDSL Single-Pair Highspeed Digital Subscriber Line Software...
-
Page 29: B) Software Licenses
In the event that you are interested in the sources licensed under GPL or LGPL, please contact support@argus.info. A machine-readable copy of the source code can be obtained from intec Gesellschaft fur Informationstechnik mbH for a minimal fee - to cover the cost of physically copying the code. This offer is valid for 3 years. -
Page 30: C) Index
Duplex half- ......................... 9 Ethernet Clear down ......................14 Flow control ........................9 Index ..........................30 intec Gesellschaft für Informationstechnik mbH ............. 4 Internet address ......................4 Loop Ethernet connection ....................18 Layer ........................17 Layer 1 (L1) ......................17 Layer 2 (L2) ......................
