Specifications
Power Source :
Power Consumption :
Aerial Impedance :
Receiving System :
Receiving Channels :
VHF
UHF
CATV
Video / Audio Terminals :
DVD
Y
PB
AC SINGLE 220-240V, 50/60 Hz
75Ω unbalanced
Coaxial type
17 Systems
2-12 PAL / SECAM B,K1
0-12 PAL B (AUST)
1-9 PAL B (N.Z)
1-12 PAL/SECAM D
1-12 NTSC M (JAPAN)
2-13 NTSC M (U.S.A)
21-69 PAL G,H,I / SECAM G,K,K1
28-69 PAL B (AUST)
13-57 PAL D,K
13-62 NTSC M (JAPAN)
13-62 NTSC M (JAPAN)
S1-S20 (OSCAR)
1-125 (U.S.A CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
5A, 9A (AUST)
1.0Vp-p, 75Ω
0.7Vp-p, 75Ω
TX-29GX25RS-IRAN
GP41N Chassis
PR
95W
AV 1,2,3
Video In
Audio In
Monitor Out
Video Out
Audio Out
Intermediate Frequency :
Video
Sound
Colour
High Voltage :
Picture Tube :
Audio Output :
Dimensions :
ORDER NO. MTV0701536CE
Colour Television
Measured diagonally,
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
Unauthorized
distribution is a violation of law.
0.7Vp-p, 75Ω
1Vp-p, 75Ω
Approx. 0.5V, 47kΩ
1Vp-p, 75Ω
Approx. 0.5V, 1kΩ
38.0 MHz
31.5 MHz (D, K, K1)
32 MHz (I)
32.5 MHz (B, G)
33.5 MHz (M)
33.57 MHz (PAL)
33.6 MHz (SECAM)
33.75 MHz (SECAM)
34.42 MHz (NTSC)
31.0kV ±1.0
at zero beam current
A68QFN893X11
68cm (29 inches)
90° deflection
16.0W
Height : 576 mm
copying
and
