Panasonic TX-29G455R-IRAN Service Manual

Specifications
Power Source :
Power Consumption :
Aerial Impedance :
Receiving System :
Receiving Channels :
VHF
2 - 12
0 - 12
1 - 9
1 - 12
1 - 12
2 - 13
UHF
21 - 69
28 - 69
13 - 57
13 - 62
14 - 69
CATV
S1 - S20
1 - 125
C13 - C49
S21 - C41
Z1 - Z37
5A, 9A
Intermediate Frequency :
AC SINGLE 220-240V, 50/60Hz
110W
75 Ω unbalanced
Coaxial type
17 Systems
PAL/SECAM B, K1
PAL B (AUST.)
PAL B (N.Z.)
PAL/SECAM D
NTSC M (JAPAN)
NTSC M (U.S.A)
PAL G, H, I/SECAM G, K, K1
PAL B (AUST.)
PAL D, K
NTSC M (JAPAN)
NTSC M (U.S.A.)
(OSCAR)
(U.S.A. CATV)
(JAPAN)
(HYPER)
(CHINA)
(AUST.)
TX-29G455R-IRAN
GP21 Chassis
Video
Sound
Colour
Video / Terminals :
AV 1, 2
S-Video In
DVD
Y
PB
YR
AV 1, 2, 3, 4
Video In
Audio In
Monitor Out
1 Vp-p, 75 Ω
Video Out
Approx. 0.5V, 1k Ω
Audio Out
High Voltage :
Picture Tube :
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO. MTV0701552CE
Colour Television
38.0 MHz
31.5 MHz (D, K, K1)
32 MHz (I)
32.5 MHz (B, G)
33.5 MHz (M)
33.57 MHz (PAL)
33.6 MHz (SECAM)
33.75 MHz (SECAM)
34.42 MHz (NTSC)
Y:1 Vp-p, 75 Ω
C:0.3 Vp-p, 75 Ω
1.0 Vp-p, 75 Ω
0.7 Vp-p, 75 Ω
0.7 Vp-p, 75 Ω
1 Vp-p, 75 Ω
Approx. 0.5V, 47k Ω
31.0kV±1.0V
at zero beam current
A68MAU085X44
67.6cm (29 inches)
Unauthorized copying and
