Panasonic TX-29FX20R Service Manual

Specifications
Power Source :
Power Consumption :
Aerial Impedance :
Receiving System :
Receiving Channels :
VHF
UHF
CATV
Video / Audio Terminals :
DVD
Y
PB
All manuals and user guides at all-guides.com
AC SINGLE 220-240V, 50/60 Hz
98W
75Ω unbalanced
Coaxial type
17 Systems
2-12 PAL / SECAM B,K1
0-12 PAL B (AUST)
1-9 PAL B (N.Z)
1-12 PAL/SECAM D
1-12 NTSC M (JAPAN)
2-13 NTSC M (U.S.A)
21-69 PAL G,H,I / SECAM G,K,K1
28-69 PAL B (AUST)
13-57 PAL D,K
13-62 NTSC M (JAPAN)
13-69 NTSC M (USA)
S1-S20 (OSCAR)
1-125 (U.S.A CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
5A, 9A (AUST)
1.0Vp-p, 75Ω
0.7Vp-p, 75Ω
TX-29FX20R
GP41 Chassis
PR
AV 1,2,3
Video In
Audio In
Monitor Out
Video Out
Audio Out
Intermediate Frequency :
Video
Sound
Colour
High Voltage :
Picture Tube :
Audio Output :
Dimensions :
© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO. MTV0601420CE
Colour Television
0.7Vp-p, 75Ω
1Vp-p, 75Ω
Approx. 0.5V, 47kΩ
1Vp-p, 75Ω
Approx. 0.5V, 1kΩ
38.0 MHz
31.5 MHz (D, K, K1)
32 MHz (I)
32.5 MHz (B, G)
33.5 MHz (M)
33.57 MHz (PAL)
33.6 MHz (SECAM)
33.75 MHz (SECAM)
34.42 MHz (NTSC)
31.0kV ±1.0
at zero beam current
A68LZU185X-E
67.6cm (29 inches)
Measured diagonally,
90° deflection
16.0W
Height : 578 mm
Width : 786 mm
Unauthorized copying and
