  • Page 1 OPERATOR’S MANUAL DG8000 Feeding Monitoring...

  • Page 3: Table Of Contents

    General Information INDICATOR DG8000 RevB0 INDICE INDICE ..................................1 TECHNICAL DATA ................................ 3 DIMENSIONS ................................3 CONFIGURATION ................................ 4 CONNECTIONS SCHEME .............................. 5 UNIVERSAL BOX ................................5 SLIM BOX ..................................10 SPECIFICATION ON FUNCTION KEYS ..........................16 SYMBOLS ...................................21 SYSTEM CONFIGURATION ............................23 WORKING DATA ................................
  • Page 4 General Information INDICATOR DG8000 RevB0 DATA TRANSFER BY MODEM............................78 SCHEDULER MANAGEMENT ............................80 TO ENABLE THE SCHEDULER ON THE INDICATOR ......................80 TO DISABLE THE SCHEDULER ............................81 SCHEDULER MANAGEMENT FROM THE INDICATOR ...................... 81 MANAGEMENT OF DATA ............................82 IRM S ...........................

  • Page 5: Technical Data

    General Information INDICATOR DG8000 RevB0 TECHNICAL DATA Range (f.s.): 0 - 999.999 Resolution: 1 - 2 - 5 -10 - 20 - 50 Accuracy: < +/- 0,015 % f.s. -30° / +65 °C (-22° / +150 °F) Operating temperature: (-45 °C /-49°F on request) Power supply: 9,5 –...

  • Page 6: Configuration

    General Information INDICATOR DG8000 RevB0 CONFIGURATION 1. ON / OFF key. 2. RESET key. 3. Directional keys. 4. Power, sensor and accessories connectors. 5. Data Transfer connector. 6. ENTER key. 7. Function and setting keys. 8. Graphical Display WVGA Full Color.

  • Page 7: Connections Scheme

    General Information INDICATOR DG8000 RevB0 CONNECTIONS SCHEME UNIVERSAL BOX Power and sensor connections (system with junction box) If the load cells are not all connected to the indicator, it's necessary to close the connectors not used with the special cap.
  • Page 8 General Information INDICATOR DG8000 RevB0 Power and sensor connection (system without junction box)
  • Page 9 General Information INDICATOR DG8000 RevB0 Accessories connection (NIR Scanner and Power & Communication Box)
  • Page 10 General Information INDICATOR DG8000 RevB0 Accessories connection (system with 4 sensor connectors)
  • Page 11 General Information INDICATOR DG8000 RevB0 Accessories connection (system with connection box 2 accessories Hi-Tech)

  • Page 12: Slim Box

    General Information INDICATOR DG8000 RevB0 SLIM BOX Power and sensor connection (system with junction box) If the load cells are not all connected to the indicator, it's necessary to close the connectors not used with the special cap.
  • Page 13 General Information INDICATOR DG8000 RevB0 Accessories connection (NIR Scanner and Power & Communication Box)
  • Page 14 General Information INDICATOR DG8000 RevB0 Accessories connection (system with connection box 2 accessories Hi-Tech)
  • Page 15 General Information INDICATOR DG8000 RevB0 Accessories connection (system without connection box 2 accessories Hi-Tech)
  • Page 16 General Information INDICATOR DG8000 RevB0 Display connection (available for UNIVERSAL BOX and for SLIM BOX)
  • Page 17 General Information INDICATOR DG8000 RevB0 Connection front loader side...

  • Page 18: Specification On Function Keys

    General Information INDICATOR DG8000 RevB0 Specification on function Keys MAIN MENU System calibration (zero setting of the system) Block mode to freeze the weight Partial weighing mode Load execution mode Unload execution mode WiFi Synchronization Loading programming mode / Recipes...
  • Page 19 General Information INDICATOR DG8000 RevB0 GENERAL SUB-MENUS Variation % mode Change of total weight to load/unload Total weighing mode (gross weight) Switching unit mode (kg / %) Saving data Print data Delete data Weight setting Customer editing SPECIFIC SUB-MENUS Partial weighing...
  • Page 20 General Information INDICATOR DG8000 RevB0 Recipe programming mode Animals number editing Recipe start time editing Show components Unloafing program execution mode Unloading mode Show uloading points Animals weight editing Recipe programming mode Recipe name editing Select component Component weight editing...
  • Page 21 General Information INDICATOR DG8000 RevB0 Unloading points programming (only if the parameter #89 is disabled) Unloading points name editing (only if the parameter #89 is disabled) Mode “Management of the Components accumulations” (recipes) Mode “Management of the pen accumulations” (unloading...
  • Page 22 General Information INDICATOR DG8000 RevB0 CONFIGURATION + WORD PROCESS KEYS and VALUES INCREASE Go back to the initial parameter configuration Recall the default values of parameters Change the type format Delete the character at the right of the cursor Increase value by 0.01 unit Increase value by 0.1 unit...

  • Page 23: Symbols

    General Information INDICATOR DG8000 RevB0 SYMBOLS CONVENTIONAL SIGNS This user’s manual uses some conventional signs, in order to lead the user through the reading of important instructions and advices; especially while setting the parameters of the system for it to work properly.
  • Page 24 General Information INDICATOR DG8000 RevA3 CONVENTIONAL TERMINOLOGY This manual uses a conventional terminology to describe the main concepts of the Feeding Process. Below is a list of the main important terms and their meanings: Component: Ingredient used in order to create a Recipe (or Diet) to feed the cattle.

  • Page 25: System Configuration

    Configuration INDICATOR DG8000 RevB0 SYSTEM CONFIGURATION Switch on the DG8000 weight Indicator. The message “System Initialization” will appear on the display. Press ENTER to get into the configuration menu of the system. Select an option from the list by pressing the button with the corresponding number.

  • Page 26: Setting Of The Base Parameters

    Configuration INDICATOR DG8000 RevB0 SETTING OF THE BASE PARAMETERS Access through the key number 2 of the Setup menu. In this section, all parameters necessary for the correct functioning of the weighing system are set up. All data contained in this section can be modified by the operator.
  • Page 27 Configuration INDICATOR DG8000 RevB0 DG8000 –Base Parameters Values Parameter Name Description (default) Device Name of the device (DG8000) Name 0..65535 PC/GSM Address for the GSM network Address Identification code that allows the indicator to Handy connect, by RF, only to those devices that have Address 0..255...
  • Page 28 Configuration INDICATOR DG8000 RevB0 When executing programs, it is not possible to carry out what follows, if not enabled: LOAD Scrolling the Components with the ↑ or ↓; UNLOAD Manual Confirm a partial execution of a Component by Component BOTH pressing ENTER.
  • Page 29 Configuration INDICATOR DG8000 RevB0 Kg, Lb Unit of Measuring unit for weight. (Kg) Measure Customer ID 0..99 Customer code. Manual 0..65000 Alarm threshold (weight) in “Partial” mode. Alarm Value Transmission relationship between cardan joint 1,00..650,0 Transmissio and auger. 0 (1,00)
  • Page 30 None to set a loading mode of a Component such that Mode Weight you can activate a timer after which the DG8000 Percent will automatically switch to the next Component, (None) even if you have not reached the target of the Component.
  • Page 31 (NO) communication. It indicates the maximum time (expressed in Max Load 0…240 minutes) where the DG8000 Indicator will show Runtime one Component inside one loading execution. If this parameter is set on 0 , there is no limit about time...

  • Page 32: Automatic Skip Of The Components

    ) the DG8000 automatically switches to the next Component. The value is equal to the Tolerance (Weight) of the Component (if set on the DTM), otherwise to the value set into the Auto Next Threshold Weight set on the DG8000 and equal for all the Components.
  • Page 33 Target Weight (and also after an acoustic alarm fixed to (Alarm Delay ) and eventually to a Stabilization Time (if the Stabilization Time is set) ), the DG8000 automatically switches to the next Component. Tolerance (Weight) The field Tolerance (Weight), can be set only on DTM;...

  • Page 34: Checking The Hardware Modules

    Configuration INDICATOR DG8000 RevB0 CHECKING THE HARDWARE MODULES Access through the key number 4 of the Setup menu. This section carries out a check on the hardware parts of the system: -Display -Keyboard (it is possible to strike a key and see the corresponding acquired code);...

  • Page 35: String Setup

    Configuration INDICATOR DG8000 RevB0 STRING SETUP Access through the key number 5 of the Setup menu. In this section it is possible to change the components and unloading points in the same way described in the section   Use of microcomputer...

  • Page 36: Configuration Protected By Password

    Configuration INDICATOR DG8000 RevB0 CONFIGURATION PROTECTED BY PASSWORD In this section you can access the password-protected menus. The information considered so important as to require a password concern the calibration of the instrument and other specific passwords. Using the increase keys, enter the desired password.

  • Page 37: Password 4 - Printing Work Process

    Configuration INDICATOR DG8000 RevB0 Password 4 – Printing Work Process Enables the printing at the end of the working process (Loading + Unloading Program) Password 12 - Calibration In this section, the calibration value of the local plant is set: The system waits for the operator to confirm, by pressing ENTER.
  • Page 38 Configuration INDICATOR DG8000 RevB0 Password 23 - Calibration procedure with fixed values In this section, the calibration value of the local plant is set from a list of pre-defined values for given loading cell types: The system waits for the operator to confirm, by pressing ENTER, that he/she wants to proceed with calibration (by pressing RESET, you can go back to the main configuration menu).

  • Page 39: Password 45 - Calibration With Sample Weight

    Configuration INDICATOR DG8000 RevB0 Password 45 - Calibration with sample weight This procedure allows to carry out the calibration of the weighing system on the basis of a known weight that must be appropriately weighed on the medium in which the weighing system is mounted.
  • Page 40 Configuration INDICATOR DG8000 RevB0 Wait until the value of the NEW CALIBRATION is saved. Confirm with ENTER or cancel the calibration with the RESET button. The message with the electrical signal appears. Confirm with the ENTER key or cancel the calibration with the RESET button.

  • Page 41: Password 46 - Inverse Calibration With Sample Weight

    Configuration INDICATOR DG8000 RevB0 Password 46 – Inverse Calibration with sample weight This procedure allows to carry out the calibration of the weighing system on the basis of a known weight that must be appropriately weighed on the medium in which the weighing system is mounted.
  • Page 42 Configuration INDICATOR DG8000 RevB0 The message with the electrical signal appears. Confirm with the ENTER key or cancel the calibration with the RESET button. "Calibration data stored memory" message appears. "CALIBRATED CHANNEL" message means that the calibration procedure was successful.

  • Page 43: Password 166 - Scheduler Activation

    Password 387 – Cancellation Scheduler Memory Cancellation of all the scheduler programs that are present in the internal memory of the DG8000. With the Enter key the cancellation is carried out while with the Reset key cancellation is not carried out.

  • Page 44: Password 603 - How To Enable The Xl Display

    Enter key Password 1066 – User and Password Activation The DG8000 gives you the possibility to have a different access to all functions in order to trace the loading /unloading operations made by a specific user. This function has to be enabled/disabled specifically by the user following these easy steps: Once entered the password, “User...
  • Page 45 Pressing RESET, the DG8000 proposes the recipes and unloading programs that are present on the card. After that, the DG8000 will ask for the USERNAME. Choose it and confirm with ENTER. Insert the PASSWORD and then press ENTER.
  • Page 46 DG8000 proposes a “Welcome Message”: Once the welcome message has been visualized: a) The DG8000 proposes to the User only the recipes and the unloading programs that are related to the specific operator or to an undefined operator.

  • Page 47: Assword Diting Of Gprs Connection Mode You Can Enter Only If Password Is Enable

    Password 1999 – Remote display with simple protocol Selection of the communication protocol for the Motor Control Box: (default value), (to communicate with a Motor Control Box directly connected by cable to the DG8000).

  • Page 48: Setting Of Customer Code

    INDICATOR DG8000 RevB0 SETTING OF CUSTOMER CODE The DG8000 is able to show the description of the customer and the association Customer/Recipes (or Unloading program) so that it allows the operator to see only the Recipes (or Unloading program) related to a specific customer during the executions. In...
  • Page 49 The indicator proposes only the recipes and the unloading programs related to this specific customer or to “All Customers”. b) All executions made on the DG8000 will be related to this specific customer. This information appears before the beginning of each recipe execution, unloading program.

  • Page 50: Use Of The Data Transfer (Memory Card)

    Before to perform any operations of data transfer, it is necessary connect the memory card to the indicator and format it. DG8000 allows to program the Recipes or Unloading programs in the following ways: a) MEMORY CARD CONNECTED (DG8000 shows the message “Data Transfer INSERTED”)
  • Page 51 (the previous program will be deleted). If select NO: the programs (Recipes/Unloading program) currently on the DG8000 will not be cancelled. Before the execution of a batch the system checks if there is enough space on the memory card.

  • Page 52: Initial Setting

    Configuration INDICATOR DG8000 RevB0 INITIAL SETTING It is advisable to turn on the power unit and wait 10/15 minutes before you start work in order to eliminate interference on weight due to initial temperature jumps of electronic components. Before you start work with DG80000 it is advisable to set the following settings.

  • Page 53: Setting Date And Time

    Configuration INDICATOR DG8000 RevB0 SETTING DATE AND TIME Wait for the indicator to go into TOTAL WEIGHT. On the second page open the menu and then select the Use the ↑ or ↓ keys to modify values Use the → and ← keys to move from one position to the other Press ENTER to confirm setting If you want to quit without saving the setting press the RESET key.

  • Page 54: Use Of The Microcomputer

    INDICATOR DG8000 RevB0 USE OF THE MICROCOMPUTER MANUAL WEIGHING Turning on the microcomputer Turn the microcomputer on with the ON / OFF button. Wait for the system to initialize until the screen with the weight appears. Calibration (zero set the system) Press the key for 3 seconds in order to calibrate the system.
  • Page 55 INDICATOR DG8000 RevB0 Weighings with alarm (net weight with alarm) 1 After calibrating the system, enter the partial weighing menu . then press the key in order to enter into the alarm threshold set screen 2 Use the ↑ or ↓ keys or the quick increment keys in order to set the desired alarm value.

  • Page 56: Programming From The Indicator

    INDICATOR DG8000 RevB0 PROGRAMMING FROM THE INDICATOR NOTE: To activate the following functions, it is necessary to set the Data Transfer Enabled (basic parameter number 89) to “No”. From TOTAL WEIGHT mode, press the keys in second page (Recipes) /...

  • Page 57: Recipes

    Each Recipe modified or created by the user on the DG8000 can be properly acquired by the DTM; Press then press ENTER for 1 second to delete the selected recipe.
  • Page 58 INDICATOR DG8000 RevB0 Press the button to associate an Unloading Program with the Recipe selected. In this way, the Unloading Program is run automatically at the end of the completion of the Recipe. Scroll through the Unloading Programs using the keys ↓ and ↑ and select the desired one with the ENTER key.
  • Page 59 INDICATOR DG8000 RevB0 key is used to add components to a recipe. Use the function to set/ modify the weight of a selected component. key permits to set/ modify the mix time of a selected component of the recipe. Press on the key to edit the mix time of the entire recipe.

  • Page 60: Unloading Programs

    INDICATOR DG8000 RevB0 Unloading programs From the programming main screen, enter the edit unloading programs by pressing the key. A list of unloading programs will appear. View and edit the detail of a selected unloading program by pressing on again.

  • Page 61: Components And Unloading Points

    INDICATOR DG8000 RevB0 The key allows to delete the selected unloading programs. By pressing the print key , it is possible to print the data that appears on the screen. Use the key to return to the edit mode and save your modifications.

  • Page 62: Customer

    INDICATOR DG8000 RevB0 Press to delete the selected component/unloading point. Press to delete all the components / unloading points. Press to print the data visualized on the screen. Customer From the programming main screen, use key to select the desired customer.

  • Page 63: Pens Management

    INDICATOR DG8000 RevB0 Print the amounts for all recipes pressing The two amounts data sections are independent from one another, and can be deleted (zeroed) regardless of one another: press in order to delete the amounts data related to the selected...

  • Page 64: Execution Of The Recipe (Loading Program)

    INDICATOR DG8000 RevB0 If you press the key you can have all the information about the unloaded total of each individual pen during all unloading executions. By pressing it is possible to print the data of single pen. You can print the amounts data for each pen, pressing the key.
  • Page 65 INDICATOR DG8000 RevB0 Select the Recipe you want to execute using the ↑ ↓ and → ← (on the display you will only see active programs). Press or ENTER to enter in the program. Recipe load Check that the data on the display is correct.
  • Page 66 INDICATOR DG8000 RevB0 Press the to edit the cows number of recipe, the system will automatically update the total value to be loaded. Press the key to change the total weight to be loaded. Change the value using the ↑ / ↓...
  • Page 67 INDICATOR DG8000 RevB0 On the second page, by pressing key, it appears a window showing the distribution (updated automatically in case of changes to the total load values) of the individual components of the recipe. Press ENTER or RESET to return to the batch scheduling.
  • Page 68 INDICATOR DG8000 RevB0 The screens, during the whole phase of the execution, will provide several pieces of useful information as shown below. The left column shows the loading state of each component, the right column shows the loading state of the whole recipe.

  • Page 69: End Of The Execution

    INDICATOR DG8000 RevB0 If you press the key you can suspend the program during the movements of the wagon so that the soil conditions and mechanical tensions do not alter the weight, on the display you will see the “program suspended”...

  • Page 70: Execution Of The Unloading Program

    INDICATOR DG8000 RevB0 EXECUTION OF THE UNLOADING PROGRAM Press the key to enter in the unloading program execution mode. At this point there are two options. Original DTM: decide to execute the Last Scale modified: decide to execute the program as programmed originally by the program with the last modification made on DTM software or;...
  • Page 71 INDICATOR DG8000 RevB0 Press to visualize the unloading points of program. Press to modify the weight of animals. Press the key to change the total weight to be loaded. Change the value using the ↑ / ↓ keys on the keypad or the display increment keys.
  • Page 72 INDICATOR DG8000 RevB0 Press the key in order to set the weight actually loaded on the wagon. The system will automatically update the total weight to be unloaded with the value actually loaded at the moment. Press the key in order to set...
  • Page 73 INDICATOR DG8000 RevB0 The screens, during the whole phase of the execution, will provide several pieces of useful information as shown below. At the top you can find the name of unloading program. The left column shows the state of unloading on the feeding of the relative group, the right column shows the unloading state of the whole program.
  • Page 74 INDICATOR DG8000 RevB0 Restart function If you press the key you can recall the programmed value of a Component. This function is used in case of mistakes by the operator or in case the program is not suspended during the movements and a variation in the weight of the Component to be loaded occurs.

  • Page 75: Suspended Execution

    INDICATOR DG8000 RevB0 SUSPENDED EXECUTION If during loading or unloading phase the power of the microcomputer suddenly was turned off the execution is suspended and you may resume it. If there was suspended program in the If there was suspended unload in the...
  • Page 76 INDICATOR DG8000 RevB0 Load the refused on the feed mixer. Press and select the group using ↑ and ↓ keys. Press ENTER to confirm the operation. Once the previous steps have been carried out the message of execution saved will be visualized.

  • Page 77: How To Reset The Refused Weight

    In the refused mode window , press the key Press ENTER in order to reset the value stored in the Internal memory of the DG8000 or RESET in order to cancel the operation. How to use the refused weight before the execution of the recipe...
  • Page 78 Now, according to the new quantity to load, DG8000 automatically updates the new amount to load for each component. If you decide to use the refused feed, DG8000 resets automatically the value of the Total Refused stored in the internal memory.

  • Page 79: Auto Link Between An Unloading Program And A Recipe

    INDICATOR DG8000 RevB0 Auto link between an Unloading Program and a Recipe This functionality allows the user to have the recalculation of the loading if the linked Unloading Program has been changed previously. This functionality works if : The base parameter “ Load Update by Unload “ is set to “ YES “ ( see the...

  • Page 80: Data Transfer By Modem

    INDICATOR DG8000 RevB0 DATA TRANSFER BY MODEM 1 First, to manage the synchronization and to transfer data between the indicator and the DTM software on your PC, the connection between the GPRS and the indicator must be enable. From the configuration system, press key to enter the setups protected by a password.
  • Page 81 INDICATOR DG8000 RevB0 By pressing on the key, you can find these two other functions: . The first one permits you to check the GPRS network information and the signal level of it. The second one is used to initialize the connection with a network.

  • Page 82: Scheduler Management

    When sending data, the indicator clear its internal memory. SCHEDULER MANAGEMENT DG8000, by means of the Scheduler, can start working processes in automatic on the basis of times associated to the relative programs. This way of work is commonly used on stationary applications for full automation of the feed preparation processes (for example, stationary mixer using the Motor Control Box).

  • Page 83: To Disable The Scheduler

    INDICATOR DG8000 RevB0 With DG8000 in Total Weight, open the menu then press in order to enter in the SCHEDULER MODE. Confirm the activation of scheduling with the ENTER key. icon on the upper right hand side of the screen indicates that the function is enabled.

  • Page 84: Management Of Data

    INDICATOR DG8000 RevB0 If the “SCHED. TIME” is the chosen connection mode, it is then possible to set the schedules time by using the ↑ ↓ and → ← keys. This selected time will be the daily synchronization start time.

  • Page 85: Hardware Checkup Of Irm System

    INDICATOR DG8000 RevB0 Press on the key. A window asking you if you want to copy (import) the data will appear. Press ENTER to confirm or RESET to cancel. The transfer of data will next start. Remove the card / USB key and close the connector after the transfer if you must not use it again.
  • Page 86 INDICATOR DG8000 RevB0 Press the key. The message “System HW checkup procedure. Do you confirm?” is shown. Press the ENTER key in order to confirm and wait the execution of system HW checkup for 10-15 seconds. Press the ENTER key in order to...
  • Page 87 INDICATOR DG8000 RevB0 In the table below, you can see the possible errors that you could visualize on the report. Attention, if it is visualized “Err.2” in the parameter “Check linear actuator” is OK.
  • Page 88 INDICATOR DG8000 RevB0 Check HW status / config Error code Error type Description IRB system initialization error error during the start up of the IRB board Err.1 IRB memory 1 error error on the memory #1 of the IRB board Err.

  • Page 89: Wifi Management

    DG8000 can acquire and transfer data on executions by the means of WiFi directly to DTM software installed on the PC. To have this option you need to have IPcom™ module connected to DG8000.

  • Page 90: Optional Accessories

    OPTIONAL ACCESSORIES CAN BUS Connector The J1939 protocol available on the CAN BUS output is deeply described in a specific document, not part of this manual. Please contact the Dinamica Generale Customer Service or R&D office for more information. Cable color...

  • Page 91: Searching For Faults

    Service INDICATOR DG8000 RevB0 SEARCHING FOR FAULTS ALLARME MOTION DISPLAY CAUSE SOLUTION Solution1: DG400 do the TARE. Cause1 Solution2: DG500 The signal coming from the sensors do the calibration with password shows sudden and important weight 12 and then do the TARE change.
  • Page 92 Service INDICATOR DG8000 RevB0 OVERRANGE ALARM CAUSE SOLUTION DISPLAY Cause1 Solution1: DG400 The microcomputer can not read the signal of the load cells: the load cell do the TARE. connection cable does not work DG500 correctly. Solution2: Cause2 DG600 do the calibration with password A connection cable or a load cell does 12 and then do the TARE.

  • Page 93: Messages Of Clock Error

    Service INDICATOR DG8000 RevB0 MESSAGES OF CLOCK ERROR If the battery is completely discharged, the following messages appears for 3 seconds: “Date and Time not valid! Please check the Internal Battery”. If the date and time is not setted, the following messages appears for 3 seconds: “Date and Time not valid!

  • Page 94: Check The Damaged Components

    Service INDICATOR DG8000 RevB0 CHECK THE DAMAGED COMPONENTS DEFINE THE TEST PROCEDURE: HAVE YOU GOT A WEIGHING SIMULATOR DG 979-0007? HAVE YOU GOT A SYSTEM WITH JUNCTION BOX? EXECUTE EXECUTE PROCEDURE 4 PROCEDURE 3 EXECUTE HAVE YOU GOT A PROCEDURE 2...
  • Page 95 Service INDICATOR DG8000 RevB0 PROCEDURE 1 Ref. YES / YES Check the working of the scale a) Switch off the microcomputer. b) Disconnect the sensor cable between the scale and the junction box. c) Connect the WEIGHT SIMULATOR (calibrator 979-0007) with the lever in position “Var” (varying) to the SENSORS connector of the scale.
  • Page 96 Service INDICATOR DG8000 RevB0 RESULT CAUSE ACTION Zero stable and correct The sensor cable and the functioning Proceed with the other tests junction box are NOT damaged Try to dry the junction box and Functioning not correct only in repeat the test; in case you do The junction is damaged or wet some junction box connectors.
  • Page 97 Service INDICATOR DG8000 RevB0 PROCEDURE 2 Ref. YES/ NO Check the functioning of the scale Switch off the microcomputer Disconnect all the sensors Connect the WEIGHT SIMULATOR (calibrator) with the lever in “Var” (varying) position to one of the sensor connectors of the weighing system Switch on the microcomputer Do the TARE (use the microcomputer’s manuals for instructions)
  • Page 98 Service INDICATOR DG8000 RevB0 PROCEDURE 3 Ref. NO / YES Check the functioning of the SYSTEM and of the SENSORS WITCH OFF THE MICROCOMPUTER n) Open the JUNCTION BOX. Just leave one sensor and the cable connected to the scale (SENSORS’ CABLE).
  • Page 99 Service INDICATOR DG8000 RevB0 PROCEDURE 4 Ref. NO / NO Check the functioning of the SYSTEM and of the SENSORS WITCH OFF THE MICROCOMPUTER Just leave one sensor connected to the scale. Switch on the microcomputer. Do the TARE (use the microcomputer’s manuals for instructions).

  • Page 100: Eu Declaration Of Conformity

    Il sottoscritto, designato a legale rappresentante della Dinamica Generale s.p.a. , via Mondadori 15, Poggio Rusco (MN) - Italy, dichiara che i prodotti sottoelencati: EN The undersigned, an authorised officer of Dinamica Generale s.p.a. , via Mondadori 15, Poggio Rusco (MN) - Italy, hereby declares that the products listed hereunder: Der Unterzeichner, rechtlicher Vertreter der Dinamica Generale s.p.a.

  • Page 101: Warning

    Rules INDICATOR DG8000 RevB0 WARNING The power cable has to be connected directly to the battery or to a regulated power source. If this is not the case DG does not respond to any eventual damage to the microcomputer. Disconnect the power cable from the microcomputer when the battery of the machine is being charged.

  • Page 102: Guarantee

    NOTES: dinamica generale® has the faculty to modify the content of this handbook due to hardware and software implementations in order to improve their products and thus to guarantee the best service to their users.
  • Page 103 This user’s manual intends to take you through the different performances of the weighing system in the easiest way and to show you some new functions as well. dinamica generale® did not forget to provide you even with the basic information: the configuration, the use of different accessories at your disposal, the service of “searching for...
  • Page 104 +39 346 96 55 640 or service@dinamicagenerale.com NIR & Software Tech support: 8.30 to 18.00 CET NIR Support: Phone +39 0386 52134 E-mail nir.support@dinamicagenerale.com Software Support: Phone +39 0386 741459 E-mail support@dinamicagenerale.com Dinamica Generale® uses PEFC paper for printing manuals and catalogues.
  • Page 105 Cod. 985-0122 Rev. B0 dinamica generale S.p.A. via Mondadori, 15 46025 Poggio Rusco (MN) - Italy...
