SCHEMATIC DIAGRAM
Bleed valve
For product demonstration please view on You Tube or via www.sentinelprotects.com/uk/eliminator
Eliminator V2-CM-03-17
Eliminator Instructions V1-CM (14-03-17) (inc Spanish).indd 3
Dual seals
Collar
Cyclone
cartridge
Collection bin
Magnet tray
Washer
Anti tamper drain valve
EN
Isolation valve
Directional T piece
Flow arrow
Isolation valve
Fig. 1
14/03/2017 14:20
3
