KPF-04
1.Features
•
Accurate AC digital clamp meter for leakage current measurement.
• UA
100 high resolution on 200mA range.
•
Shield transformer jaws to minimizs the effect of external stray magnetic field.
•
Large jaw with 68 mm diameter.
•
Five Ranges (200mA, 2A, 20A, 200A, 1000A) for all application.
•
A filter circuit is designed to eliminate the effect of high frequency noise and
harmonics by setting the frequency selector switch at the 50/60 Hz position
for AC current measurement.
•
Large 3 1/2 digits LCD
•
Fast bargraph display (20 times/sec.)for transient observation.
•
Continuity measurements.
•
Max/Min and Data Hold functions.
•
Peak Value Measurement.
•
600V overload protection for DC/ACV, ohm range measurement.
•
Easy single rotary switch for any function selection.
