INSTRUCTIONS FOR INSTALLATION AND USE.
LF28
Thank you for having chosen an LAE electronic product. Before installing the instrument, please read this instruction booklet carefully
in order to ensure safe installation and optimum performance.

1. INSTALLATION

1.1 LF28, size 105x90x55 mm (WxHxD), must be fitted to a DIN rail in such a position so as to prevent debris and moisture
infiltration which may cause serious damage and compromise safety.
1.2 The instrument should work with room temperatures between -10°.. +50°C and relative humidity between 15%.. 80% inclusive.
Supply voltage, switched powers and connection set-up should scrupulously comply with the indications given on the container. To
reduce the effects of electromagnetic disturbance, keep the flat connecting cable, the sensor and signal cables well separate from
the power wires.
1.3 The display unit LCD16 is secured to the panel by means of the two springs on the side of the box. The unit is mounted on the
panel through a 29x71 mm opening, exert a moderate pressure so as to get the LCD16 to align flush to the panel surface. The main
unit LF28 and the display unit LCD16 are connected to each other by means of the flat cable supplied in the package.
1.4 The sensor T1 measures the air temperature and activates in the thermostat control cycle; it should be placed inside the
appliance in a point that truly represents the temperature of the stored product. If enabled (T2=YES), the sensor T2 measures the
evaporator temperature and should be placed where there is the maximum formation of frost. If enabled (T3=YES), the sensor T3
should be located between the condenser fins, half way between the condenser inlet and outlet. The auxiliary sensor T4 can be used
to monitor the temperature of either a second evaporator (T4=2EU), or of a second condensing unit (T4=2CU) or disabled
(T4=NON).
CAUTION: should the relays have to switch a heavy load frequently, it is advisable to contact the manufacturer for indications on the
lifetime of the contacts.
Whenever products must be kept within very severe specifications or the products have considerable value, the use of a second
instrument is recommended, which activates upon or warns of any malfunction.

2. OPERATING MODES

Upon switching on, just the central line (autotest) appears on the display for approximately three seconds and the subsequent indications depend
on the operating status of the controller. TABLE 1 gives the indications associated with the various states, whereas the symbols appearing in the
text are explained in TABLE 2.
2.1 S
. If button
TANDBY
S
N
TANDBY
ORMAL
OFF
-19
Not
Product
Operating
Temper. (sim.)
DEF
Defrost
REC
Recovery after
defrost
HI
High temp.
alarm
- - -
....
E1
Faulty T1 probe
is pressed for 3 seconds, it allows the LF28 to be put on a standby, or to resume output control (with
0LLF28003EN
I
M
I
D
NFO
ENU
NFO
ATA
T1
-20
Air
temperature
T2
-25
Evaporator
temperature
- - -
- - -
...
TLO
-19
Min. stored
temperature
CND
15
Condenser clean
cycle
LOC
NO
Locked keypad
TABLE 1
S
M
P
ETUP
ENU
ARAMETER
V
ALUE
SCL
1°C
Display scale
SPL
-25
Minimum
setpoint
SPH
-18
Maximum
setpoint
- - -
- - -
....
- - -
- - -
....
- - -
- - -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LF28 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LAE electronic LF28

  • Page 1 1. INSTALLATION 1.1 LF28, size 105x90x55 mm (WxHxD), must be fitted to a DIN rail in such a position so as to prevent debris and moisture infiltration which may cause serious damage and compromise safety.
  • Page 2 INSTRUCTIONS FOR INSTALLATION AND USE. parameter SB=YES only). An indication on the display shows that the outputs are off permanently. 2.2 N . During normal operation, the display shows the temperature measured by probe T1, presented in the most appropriate ORMAL manner.
  • Page 3 INSTRUCTIONS FOR INSTALLATION AND USE. Par. Adjustment Function Sect Par. Adjustment Function Sect 0.. 30 [min] Timed fan stop -12.. +12 [°] Probe T3 offset 0.. 30 [min] Timed fan run NON/2CU/2EU Function auxiliary probe T4 -12.. 0 [°] Low alarm differential -12..
  • Page 4 With FTC=NO the optimised control is excluded, so the fans will run all the time. 6.2 If the LF28 is connected to a door switch and door switch control is enabled (DS=YES), during thermostatic control if the door is opened, the fans will be stopped immediately.
  • Page 5 8. TEMPERATURE STORAGE The LF28 features a system for permanent storage of the minimum and maximum temperature logged during operation. This system is a valid help to achieve compliance with the HACCP directive in its part relating to a correct preservation of foodstuffs. Temperature is measured by probe T1 which should therefore be placed in a point where the temperature of the preserved product may always be measured correctly.
  • Page 6 INSTRUCTIONS FOR INSTALLATION AND USE. AIN COMBINATIONS Manual control of lights: LSM=MAN, OAU=LGT. Two compressors with temperature protection: OAU=2CU, 2CD=10 seconds, T3=YES, T4=2CU, AHM=STP. Two compressors with pressure protection: OAU=2CU, 2CD=10 seconds, T3=NO, T4=NON, DI2=HPS, AHM=STP. Two evaporators: OAU=2EU, T4=2EU, DTY=ELE. 9.5 The function performed by the second digital input DI2 is chosen among: HPS, safety pressure switch (see 7.4);...
  • Page 7 INSTRUCTIONS FOR INSTALLATION AND USE. WIRING DIAGRAM Evp 2 Evp 1 RS485 LCD16 12÷24Vac PC comm. Cond. Door Switch Switch remote T4 T2 T1 T3 20(6)A 12(4)A 7(2)A 7(2)A max. total current 18A Power Supply Evaporator fan Condenser fan LF28D3S4E-B Cond 2 Evp 1 RS485...
