Tunstall Fall Detector 66000/01 User Instructions page 3

A l l t h e r e a s s u r a n c e y o u n e e d
Automatic fall detection
• Green light and two "beeps" indicates that
the fall detector has been activated.
• The fall detector will then monitor for
between 6 and 15 seconds to verify if
there could have been a fall. The green
light will flash while it does this.
• If the detector has decided that there is
a fall, then a red light and four "beeps"
indicates that the fall detector is about
to trigger an alarm call (because it has
detected an impact and has not been
upright for between 6 and 15 seconds).
• If the detector has decided that it was
activated by error then the green
flashing light will stop after between 6 to
15 Seconds and the unit will revert to
normal again.
• The fall detector also features a manual
button, which can be used at any time to
raise a call for help if required.
D6607016 Issue A
Page 3 of 11
