- Page 1 USER’S MANUAL FLOOR CUTTER FS 27-E / 7.5 kW Maschinenbau GmbH Lanzstraße 4 - D-88410 Bad Wurzach Telefon +49 (0) 75 64/3 07-0 - Fax + 49 (0) 75 64/3 07-5 00 lissmac@lissmac.com - www.lissmac.com Edition: 2011/11 Translation of the original operating manual...
- Page 2 Introduction This operating manual should make it easier to learn about the machine and its features. The operating manual contains important information on operating the machine safely, correctly and efficiently. Following the instructions helps prevent accidents, unnecessary repair costs and down time, which extends the machine’s reliability and service life.
- Page 3 1. General Safety Precautions 1.1 Warning Labels and Symbols used in this Manual Danger! Not following the instructions can result in serious injuries or even death. Caution! Not following the instructions can, under certain conditions, result in injuries. Note! Not following the instructions can result in damage to the machine or other equipment.
- Page 4 1.3.3 Any personnel working on the machine must read this operating manual especially this chapter on safety precautions-prior to beginning. Learning on the job is too late. This especially applies to personnel who occasionally work on the machine (e.g. setup and maintenance crews). 1.3.4 Perform regular spot checks to ensure that personnel are doing their jobs in a safe and conscientious manner and that they are adhering to the instructions in the operating manual!
- Page 5 accompanied at all times by an experienced operator while working on the machine! 1.4.6 Any work at the electrical equipment of the floor cutter must be carried out by a qualified electrician only or a trained person under the supervision of a qualified electrician, in accordance with the rules and standards for electronics.
- Page 6 1.5.2.3 When the machine is completely turned off for maintenance or repair work, it must be safeguarded against an unexpected restart. 1.5.2.4 Before cleaning machine with water or with other cleansing agents cover and seal all openings into which, due to safety or functional reasons, water/cleansing agent may not penetrate.
- Page 7 1.6.2 Dust 1.6.2.1 Observe all national regulations and standards when working in small spaces! 1.6.3 Noise 1.6.3.1 Officially prescribed personal ear protection! 1.7 Transport 1.7.1 Ensure that your hoisting gear and load suspension devices have adequate carrying capacity. 1.7.2 Have an experienced coordinator direct the lifting process! 1.7.3 Lift the machines using only approved lifting equipment as per the instructions in the operating manual (striking points for loading procedures)!
- Page 8 2. Description of Machine Componentry 2.1 Component Overview Pos. 1 Cut depth adjustment Pos. 2 Locking for cut depth adjustment Pos. 3 Steering rod Pos. 4 Fixing of saw hood Pos. 5 Saw hood Pos. 6 Main switch Pos. 7 Star-delta-switch (Eyebolt) Pos.
- Page 10 Kind of current 3PH + N + PE Number of revolutions – saw blade 1350 r.p.m. 2.4. Noise emitted FS 27-E Guaranteed sound level = 96 dB(A) Attention! Ear muffs must be worn if a 90 dB(A) noise level is...
- Page 11 3. Commissioning Prior to starting work, familiarize yourself with the operation of the floor cutter. The conditional connections (Point 12.) must be observed concerning the electromagnetic compatibility. 3.1 Start preparation - On demand install saw blade (see 5.2 and 5.3) - Drive floor cutter in position 3.2 Check sense of rotation of saw blade Switch the main switch (Pos.
- Page 12 4. Transport 4.1 To transport: - positioning rod folded up - lift saw arm up for sufficient ground clearance - arrest spindle and bolt (Pos. 2) 4.2 Displacement by crane - Observe all points specified under 4.1 Put crane suspension gear into eye hook (Pos. 8) ...
- Page 13 13 13...
- Page 15 - Reinstall flange pressure disc and flange nut ATTENTION! Mount the cotter pin! - Mount saw hood 5.3 Choice of saw blade See the “Lissmac Diamond Tools” brochure. Only use saw blades recommended by the manufacturer.
- Page 16 5.4 Change from right- to left-cut - Detach wing screw (Pos. 4) - Remove saw hood (Pos. 5) with rod assembly - Open plug (Pos. 15) - Disconnect water hose - Turn motor totally down via crank handle (Pos. 1) - Remove ring bolts (Pos.
- Page 17 Date Operating hours performed maintenance work Signature / stamp...
- Page 19 8. Trouble shooting Defect Possible cause Remedial action poor cutting performance slack v-belt restretch, exchange (see 8.3) saw blade does not move clogged supply line no water at saw blade clean sieve inside supply line dirty sieve flush water supply line (5-8 bar) 8.2 Checking of V-belt tension - Remove safety cap (Pos.
- Page 20 10. Guarantee The guarantee time is 12 months. The following wearing parts you will get only in guarantee, when the wearing is not due to working conditions. Wearing parts are parts, which will be worn out in working conditions due to intended use of a machine.
- Page 21 11. Disposal This machine is in subject to directive no. 2002/96EG (WEEE) dated 27.01.2003. The manufacturer is engaged to take back this machine for the disposal. The machine has to be delivered to the manufacturer or to the named point of acceptance exempt from charges.
- Page 22 Translation of the original declaration of conformity LISSMAC Floor cutter FS 27 E. Producer: LISSMAC Maschinenbau GmbH Lanzstrasse 4 D-88410 Bad Wurzach Storage of the Andreas Buschle (Technischer Redakteur) technical documents LISSMAC Maschinenbau GmbH Lanzstrasse 4 D-88410 Bad Wurzach Description of machine: Floor cutter FS 27 E Cutting depth max.
