NextCentury RE4 Operation And Installation Manual

RE4 Repeater
NextCentury Connect™ Wireless Network Repeater
Operation and Installation Guide
1| Product Overview
The NextCentury RE4 Repeater is an easy to use, full featured
device that receives signals from Transceivers and routes the
data to the Gateway.
The Repeater increases coverage by amplifying and repeating
signals in the network. The RE4 Repeater has the longest range in
its class with LED light indicators allowing for immediate
verification of signal delivery during setup and maintenance.
The RE4 is a drop-in replacement for the previous RE201
Repeater model and is compatible with all NextCentury radio
devices.
2| Technical Specifications
2.1 – Certifications
FCC: 2AB8I-RE4 IC: 20949-RE4
2.2 – Wireless
Two-way NextCentury RF Connect™
●
902-928 MHz Unlicensed Band
●
2.5 – Power Requirements
120/240 VAC power supply (included)
●
2.6 – Dimensions:
5.7" x 4.6" x 1.7" (145mm x 117mm x 44mm)
●
2.7 – Operation Environment:
● -20°C to 60°C (-4°F to 140°F )
● Indoor or NEMA rated enclosure required
3| Device Compatibility
The RE4 Repeater is compatible with all NextCentury end
devices and Gateways. It is a drop-in replacement for the
previous RE201 Repeater model.
3.1 – Transceiver Compatibility
●
●
●
●
3.2 – Gateway Compatibility
●
●
●
4| Network Layout
The Repeater can be installed in any location within RF range and
will automatically be integrated into the wireless network by the
Gateway and other nearby Repeaters.
Where possible, select locations:
●
●
●
5| In-Field Installation
5.1 –Mounting Plate
●
●
5.2 – Power Supply
●
Note: GFCI receptacles can nuisance trip when in close proximity to
any RF transmitting device – use the full length of the power supply
cord and install the RE4 at least 3' from a GFCI receptacle.
sales@nextcenturymeters.com
www.nextcenturymeters.com
TR201 Transceiver
TR4 Transceiver
RR301-TR Remote Reader (with Radio)
RR4 Remote Reader
GW201 LCD Gateway (Legacy)
GW301 Cellular Gateway
GW4 Cellular Gateway
Away from immediate obstructions
Not directly mounted on metal beams or floor decking
Mounted as high as possible
Adhesive backing provided to aid in installation, use of
screws recommended
Attach the mounting plate to the wall surface using
the included sheetrock anchors and screws
Plug in the included 15v power supply to the Repeater
and a standard 120v receptacle
V. 052521
