RE4 Repeater
NextCentury Connect™ Wireless Repeater
Operation and Installation Guide
1| Product Overview
The NextCentury RE4 Repeater is a powerful
wireless device that extends and amplifies network
coverage.
Dual antennas and smart frequency hopping help
mitigate interference in even the most challenging
environments.
With the longest range in its class and simple plug-n-
play setup, the RE4 makes property installation
quick and easy.
NextCentury Connect™ Wireless
Utilizing NextCentury Wireless Connect™ technology,
RE4 Repeaters create a multi-hop network supporting
properties with hundreds or even thousands of meters.
The NextCentury Connect™ technology includes a multi-
stage encryption engine for security and data privacy.
Intelligent
network
balancing
communication and a high resolution of meter usage data.
allows
for
reliable
sales@nextcenturymeters.com
www.nextcenturymeters.com
2| Technical Specifications
2.1 – Certifications
FCC: 2AB8I-RE4
●
2.2 – Wireless
●
Two-way NextCentury RF Connect™ (902-928 MHz
Unlicensed Band)
BLE – Direct Connect using your iOS or Android
●
mobile device
2.5 – Power Requirements
●
120/240 VAC outlet required
15 VDC 1A power supply (included)
●
2.6 – Dimensions:
4.7" x 3.1" x 1.1" | 120mm x 80mm x 28mm
●
2.7 – Operation Environment:
-4°F to 140°F | -20°C to 60°C)
●
●
Indoor (or NEMA rated enclosure required)
3| Device Compatibility
3.1 – Transceiver Compatibility
- TR4 Transceiver
- TR4-X Outdoor Transceiver - RR301-TR Remote Reader
- TR201 Transceiver
3.2 – Network Device Compatibility
- GW4 Gateway (5G/LTE)
- GW301 Gateway
- GW201 Gateway (LCD)
4| Package Contents
A – RE4 Repeater
B - Mounting Plate
IC: 20949-RE4
-
RR4-TR Remote Reader
-
GW4-Lite Gateway
- GW301-Lite Gateway
- RE201 Repeater
C – Mounting Hardware
D – Power Supply
V. 082321
