  • Page 2 ASSEMBLY/REPAIR PARTS MANUAL MODEL NO. WEX145H42B Lawn Tractor ® 166251 10.29.98 JH PRINTED IN U.S.A.

  • Page 3: Table Of Contents

    The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - "Tractor" • Model Number - "WEX145H42B" • Part Number • Part Description TABLE OF CONTENTS ELECTRICAL ......................4-5...
  • Page 4 TRACTOR - - MODEL NUMBER WEX145H42B SCHEMATIC BLACK BATTERY FUSE 30 AMP. STARTER AMMETER (OPTIONAL) BLACK WHITE SOLENOID CLUTCH / BRAKE (PEDAL UP) WHITE SEAT SWITCH IGNITION (NOT OCCUPIED) SWITCH WHITE BLACK BLACK BLACK ATT'MENT CLUTCH GROUNDING (CLUTCH OFF) CONNECTOR...

  • Page 5: Electrical

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B ELECTRICAL...
  • Page 6 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B ELECTRICAL PART DESCRIPTION 144925 Battery 12 Volt 25 AMP 74760412 Bolt Hex Hd 1/4-20unc X 3/4 156417 Case Battery 153664 Switch Interlock Push-In 10090400 Washer Lock 1/4 73350400 Nut Jam Hex 1/4-20 Unc...
  • Page 7 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B CHASSIS AND ENCLOSURES...

  • Page 8: Chassis

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B CHASSIS AND ENCLOSURES PART DESCRIPTION 160393 Chassis LT Stamping 98 140356 Drawbar, Stretch 94 17490612 Screw, Thdrol. 3/8-16 x 3/4 Ty-TT 19131216 Washer 13/32 x 3/4 x 16 Gauge 155272 Bumper Hood/Dash...

  • Page 9: Drive

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B DRIVE...
  • Page 10 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B DRIVE PART PART DESCRIPTION DESCRIPTION 140607 Transmission, Asm. 154778 Keeper, Belt Engine 142431 Spring, Return, Brake 142432 Screw 144698 Pulley, Transmission 134683 Guide, Belt, Mower Drive RH 141003 Rod, Shift 141417 Strap, Torque, Lh...

  • Page 11: Steering Wheel

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B STEERING WHEEL...
  • Page 12 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B STEERING WHEEL PART DESCRIPTION 140044 Wheel Steering 154427 Axle Asm Front 156483 Spindle Asm LH 157473 Spindle Asm RH 6266H Bearing, Race, Thrust Hardened 121748X Washer 25/32 X 1-5/8 X 16 Ga...

  • Page 13: Seat/Decals

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B SEAT PART PART DESCRIPTION DESCRIPTION 127429 Seat 72050412 Nut, Crownlock 1/4-20 x 1-1/2 140551 Bracket, Pivot, Seat 121249X Spacer, Split 74760616 Bolt 123740X Spring 19131610 Washer 13/32 x 1 x 10 Ga.
  • Page 14 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B DECALS PART PART DESCRIPTION DESCRIPTION 145498 Decal, Instruction, Operation 145005 Decal, Btry Dngr/Psn P/L Sym 162395 Decal, Fender Logo 160396 Decal, V-Belt 162389 Decal, Hood Rh 162391 Decal, Deck, Grass/Weedeater 162390 Decal, Hood Lh...

  • Page 15: Engine

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B ENGINE PART PART DESCRIPTION DESCRIPTION 17490512 Screw Thdrol 5/16-18 x 3/4 141359 Control Th/ch 137040 Line Fuel 17720410 Screw Hex Thd Cut 1/4-20x5/8 T - - - - - Plug Oil Drain (Order From Engine - - - - - - Engine Briggs Model No.

  • Page 16: Mower Lift Lever

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B MOWER LIFT 17 18 20 PART PART DESCRIPTION DESCRIPTION 159460 Wire Asm. Inner/Sprg w/Plunger 4939M Spring, Retainer 159471 Shaft, Asm., Lift R/H 127218 Link, Front 105767X Pin, Groove 73350800 Nut, Jam, Hex 1/2-13 Unc...

  • Page 17: Mower Deck

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B MOWER DECK 81 82...
  • Page 18 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B MOWER DECK PART PART DESCRIPTION DESCRIPTION 164691 Housing Asm MWR 42" HL MCH T- 131340 Bolt Shldr 10-24 Zinc Gr 5 42" Path 69180 Nut Lock #10-24 Unc 72140506 Bolt Rdhd Sqnk 5/16-18unc X3/4...

  • Page 19: Transaxle

    REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B TRANSAXLE - HYDRO MODEL NUMBER 0319-0500...
  • Page 20 REPAIR PARTS TRACTOR - - MODEL NUMBER WEX145H42B TRANSAXLE - HYDRO MODEL NUMBER 0319-0500 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 142986 Housing, Lower 150778 Locknut, Hex 5/16-24 UNJC 142987 Assembly, Upper Housing 142958 Brake Rotor/Stator Kit...
  • Page 21 LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and workmanship. For a period of one (1) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
