Manual No.'15•SRK-T-172
RESIDENTIAL AIR-CONDITIONING
TECHNICAL MANUAL & PARTS LIST
WALL MOUNTED TYPE
RESIDENTIAL AIR-CONDITIONERS
(Split system, air cooled cooling only type)
SRK10CRV-S, S1
SRK13CRV-S, S1
SRK10CRS-S, S1, S2, S3, S4, S5, S6
SRK13CRS-S, S1, S2, S3, S4, S5, S6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRK10CRV-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi Heavy Industries SRK10CRV-S

Summary of Contents for Mitsubishi Heavy Industries SRK10CRV-S

  • Page 1 All manuals and user guides at all-guides.com Manual No.'15•SRK-T-172 RESIDENTIAL AIR-CONDITIONING TECHNICAL MANUAL & PARTS LIST WALL MOUNTED TYPE RESIDENTIAL AIR-CONDITIONERS (Split system, air cooled cooling only type) SRK10CRV-S, S1 SRK13CRV-S, S1 SRK10CRS-S, S1, S2, S3, S4, S5, S6 SRK13CRS-S, S1, S2, S3, S4, S5, S6...
  • Page 2 All manuals and user guides at all-guides.com...
  • Page 3 All manuals and user guides at all-guides.com '15 • SRK-T-172 TECHNICAL MANUAL...

  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com '15 • SRK-T-172 CONTENTS 1. SPECIFICATIONS ..................2. EXTERIOR DIMENSIONS ................ 22 (1) Indoor units ..................22 (2) Outdoor units ..................23 (3) Wireless remote control ..............24 3. ELECTRICAL WIRING ................25 (1) Indoor units ..................
  • Page 5 All manuals and user guides at all-guides.com '15 • SRK-T-172 ..56 .......... 56 ........57 ■How to read the model name Example: SRK 10 C RV-S Series code Cooling only type Product capacity Model name SRK : Wall mounted type SRC : Outdoor unit...

  • Page 6: Specifications

    All manuals and user guides at all-guides.com '15 • SRK-T-172 1. SPECIFICATIONS SRK10CRV-S Model Item Indoor unit SRK10CRV-S Outdoor unit SRC10CRS-S Cooling capacity (1) 2700 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 0.740 consumption Running Cooling current Operation...
  • Page 7 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRV-S1 Model Item Indoor unit SRK10CRV-S1 Outdoor unit SRC10CRS-S1 Cooling capacity (1) 2700 Power source 1 Phase, 220 V, 50Hz Power Cooling 0.750 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 8 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRV-S Model Item Indoor unit SRK13CRV-S Outdoor unit SRC13CRV-S Cooling capacity (1) 3600 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 1.000 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 9 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRV-S1 Model Item Indoor unit SRK13CRV-S1 Outdoor unit SRC13CRV-S1 Cooling capacity (1) 3600 Power source 1 Phase, 220 V, 50Hz Power Cooling 1.000 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 10 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S Model Item Indoor unit SRK10CRS-S Outdoor unit SRC10CRS-S Cooling capacity (1) 2700 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 0.740 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 11 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S1 Model Item Indoor unit SRK10CRS-S1 Outdoor unit SRC10CRS-S1 Cooling capacity (1) 2700 Power source 1 Phase, 220 V, 50Hz Power Cooling 0.750 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 12 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S2 Model Item Indoor unit SRK10CRS-S2 Outdoor unit SRC10CRS-S2 Cooling capacity (1) 2700 Power source 1 Phase, 220 V, 50Hz Power Cooling 0.750 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 13 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S3 Model Item Indoor unit SRK10CRS-S3 Outdoor unit SRC10CRS-S3 Cooling capacity (1) 2700 Power source 1 Phase, 220-240V, 50Hz Power Cooling 0.740 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 14 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S4 Model Item Indoor unit SRK10CRS-S4 Outdoor unit SRC10CRS-S4 Cooling capacity (1) 2700 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 0.740 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 15 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S5 Model Item Indoor unit SRK10CRS-S5 Outdoor unit SRC10CRS-S5 Cooling capacity (1) 2700 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 0.740 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 16 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S6 Model Item Indoor unit SRK10CRS-S6 Outdoor unit SRC10CRS-S6 Cooling capacity (1) 2700 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 0.740 consumption Running Cooling current Operation data Inrush current Cooling 3.65 Sound level...
  • Page 17 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S Model Item Indoor unit SRK13CRS-S Outdoor unit SRC13CRS-S Cooling capacity (1) 3600 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 1.00 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 18 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S1 Model Item Indoor unit SRK13CRS-S1 Outdoor unit SRC13CRS-S1 Cooling capacity (1) 3600 Power source 1 Phase, 220 V, 50Hz Power Cooling 1.00 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 19 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S2 Model Item Indoor unit SRK13CRS-S2 Outdoor unit SRC13CRS-S2 Cooling capacity (1) 3600 Power source 1 Phase, 220 V, 50Hz Power Cooling 1.00 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 20 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S3 Model Item Indoor unit SRK13CRS-S3 Outdoor unit SRC13CRS-S3 Cooling capacity (1) 3600 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 1.00 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 21 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S4 Model Item Indoor unit SRK13CRS-S4 Outdoor unit SRC13CRS-S4 Cooling capacity (1) 3600 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 1.00 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 22 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S5 Model Item Indoor unit SRK13CRS-S5 Outdoor unit SRC13CRS-S5 Cooling capacity (1) 3600 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 1.000 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...
  • Page 23 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S6 Model Item Indoor unit SRK13CRS-S6 Outdoor unit SRC13CRS-S6 Cooling capacity (1) 3600 Power source 1 Phase, 220-240 V, 50Hz Power Cooling 1.000 consumption Running Cooling current Operation data Inrush current 12.0 Cooling 3.60...

  • Page 24: Exterior Dimensions

    All manuals and user guides at all-guides.com '15 • SRK-T-172 2. EXTERIOR DIMENSIONS (1) Indoor unit All models...

  • Page 25: Outdoor Units

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (2) Outdoor units Models SRC10CRV-S, S1 SRC10CRS-S, S1, S2, S3, S4, S5, S6 Unit:mm 50.6 390.6 Symbol Content φ9.52 （ 3／8"） （ Flare） Service valve connection （ gas side） φ6.35 （ 1／4"） （ Flare） Service valve connection （...

  • Page 26: Wireless Remote Control

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (3) Wireless remote control Models SRK10CRV-S, S1 Unit: mm SRK13CRV-S, S1 Unit: mm 17.3 17.3 Models SRK10CRS-S, S1, S2, S3, S4, S5, S6 SRK13CRS-S, S1, S2, S3, S4, S5, S6...

  • Page 27: Electrical Wiring

    All manuals and user guides at all-guides.com '15 • SRK-T-172 3. ELECTRICAL WIRING (1) Indoor units Models SRK10CRV-S, S1 SRK13CRV-S, S1...
  • Page 28 All manuals and user guides at all-guides.com '15 • SRK-T-172 Models SRK10CRS-S, S1, S2, S3, S4, S5, S6 SRK13CRS-S, S1, S2, S3, S4, S5, S6...

  • Page 29: Outdoor Units

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (2) Outdoor units Models SRC10CRV-S, S1 SRC10CRS-S, S1, S2, S3, S4, S5, S6 ITEM DESCRIPTION COMPRESSOR MOTOR FAN MOTOR RUNNING CAPACITOR FOR COMPRESSOR RUNNING CAPACITOR FOR FAN MOTOR TERMINAL BLOCK INDOOR UNIT TERMINAL BLOCK OUTDOOR UNIT MOTOR PROTECTOR BLACK BLACK Power source  RED WHITE 220-240V 50Hz BLACK Models SRC13CRV-S, S1 SRC13CRS-S, S1, S2, S3, S4, S5, S6 ITEM DESCRIPTION...

  • Page 30: Noise Level

    All manuals and user guides at all-guides.com '15 • SRK-T-172 4. NOISE LEVEL Condition ISO5151 T1, JIS C 9612 Model SRK10CRV-S, S1 SRK10CRS-S, S1, S2, S3, S4, S5, S6 MODE Rated capacity value (Indoor Unit) Mike position as below ●...
  • Page 31 All manuals and user guides at all-guides.com '15 • SRK-T-172 Condition ISO5151 T1, JIS C 9612 MODE Rated capacity value (Indoor Unit) Mike position as below ● SRK13CRV-S, S1 Model SRK13CRS-S, S1, S2, S3, S4, S5, S6 0.8m Unit Mike position Noise Level Cooling 40 dB(A)

  • Page 32: Piping System

    All manuals and user guides at all-guides.com '15 • SRK-T-172 5. PIPING SYSTEM All models Cooling cycle Indoor unit Outdoor unit Flare connecting Service valve (Gas) Check joint Gas pipe 10 : ø9.52 13 : ø12.7 Accumulator Room temp. Heat sensor Heat exchanger...

  • Page 33: Range Of Usage & Limitations

    All manuals and user guides at all-guides.com '15 • SRK-T-172 6. RANGE OF USAGE & LIMITATIONS Models All models Item Indoor return air temperature ( Upper, lower limits ) Refer to the selection chart Outdoor air temperature ( Upper, lower limits ) Refrigerant line ( one way ) length Max.
  • Page 34 All manuals and user guides at all-guides.com '15 • SRK-T-172 (2) Correction of cooling capacity in relation to one way length of refrigerant piping Piping length [m] Cooling 0.99 0.975 How to obtain the cooling capacity SRK13CRV-S 3510 3600 SRK13CRV-S...

  • Page 35: Capacity Tables

    All manuals and user guides at all-guides.com '15 • SRK-T-172 7. CAPACITY TABLES Models SRK10CRV-S SRK10CRS-S, S3, S4, S5, S6 (220-240V) Cooling Mode Capacity 2.700 kW Wind ( kW ) Air flow 10 (m /min) indoor temperature 14℃WB 16℃WB 18℃WB 19℃WB...
  • Page 36 All manuals and user guides at all-guides.com '15 • SRK-T-172 Models SRK13CRV-S SRK13CRS-S, S3, S4, S5, S6 (220-240V) Cooling Mode Capacity 3.600 kw Wind ( kW ) Air flow 10 (m /min) indoor temperature 14℃WB 16℃WB 18℃WB 19℃WB 20℃WB 22℃WB 24℃WB 21℃WB 23℃WB...

  • Page 37: Application Data

    All manuals and user guides at all-guides.com '15 • SRK-T-172 8. APPLICATION DATA While install the unit, be sure to check the selection of installation place, power supply WALL TYPE AIR-CONDITIONER specifications, usage limitation (piping length, height differences between indoor and R410A REFRIGERANT USED outdoor units, power supply voltage and etc.) and installation spaces.
  • Page 38 All manuals and user guides at all-guides.com '15 • SRK-T-172 Safety precautions CAUTION Carry out the electrical work for ground lead with care. Do not connect the ground lead to the gas line, water line, lightning conductor or telephone line’s ground lead. Incorrect grounding can cause unit faults such as electric shocks due to short-circuiting.
  • Page 39 All manuals and user guides at all-guides.com '15 • SRK-T-172 Standard accessories Necessary tools for the installation work Q'ty Accessories for indoor unit Plus headed driver (Phillips screwdriver) Knife ① (Attached to the rear of the indoor unit) ② Wireless remote control Tape measure ③...
  • Page 40 All manuals and user guides at all-guides.com '15 • SRK-T-172 Limitations for one way piping length and vertical height difference One way piping length ( ) 15 m Outdoor unit is 10 m lower Vertical height difference (h) Outdoor unit is 10 m higher Installation of indoor unit...
  • Page 41 All manuals and user guides at all-guides.com '15 • SRK-T-172 Connecting power source by power cable. connecting diagram Terminal and power cable Power source on the indoor unit Brown 〜 Blue Yellow/Green Terminal on the outdoor unit – 32 – RMA012A086_EN.indb 32 17/11/2014 15:17:38...
  • Page 42 All manuals and user guides at all-guides.com '15 • SRK-T-172 Open/close and detachment/attachment of air inlet panel 1 To open, pull the panel at both ends of lower part and release latches, then pull up the panel until you feel resistance. (The air inlet panel stops at approx.
  • Page 43 All manuals and user guides at all-guides.com '15 • SRK-T-172 Installation of outdoor unit ① Make sure that the unit is stable in installation. Fix the unit to stable base. ② Perform wiring, making wire terminal numbers conform to terminal numbers of indoor unit Terminal block terminal block.
  • Page 44 15.88 (5/8") 30 ~ 40 the system. Oil running back into an air-conditioning system may cause the refrigerant cycle to break down. Models SRK10CRV-S SRK13CRV-S SRK10CRS-S, S3, S4, S5, S6 SRK13CRS-S, S3, S4, S5, S6 Additional refrigerant charge When refrigerant piping exceeds 5m conduct additional refrigerant charge after refrigerant sweeping.
  • Page 45 All manuals and user guides at all-guides.com '15 • SRK-T-172 How to relocate or dispose of the unit In order to protect the environment, be sure to pump down Forced cooling operation (recovery of refrigerant). Turn on a power supply again after a while after turn off a power supply. Pump down is the method of recovering refrigerant from the Then press continually the ON/OFF button 5 seconds or more.
  • Page 46 All manuals and user guides at all-guides.com '15 • SRK-T-172 Installations test check points Check the following points again after completion of the installation, and before turning on the power. Conduct a test run again and ensure that the unit operates properly. At the same time, explain to the customer how to use the unit and how to take care of the unit following the instruction manual.

  • Page 47: Outline Of Operation Control By Microcomputer

    All manuals and user guides at all-guides.com '15 • SRK-T-172 9. OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER (1) Operation control function by remote control Models SRK10CRV-S, S1 SRK13CRV-S, S1 Remote control ◆ Operation section FAN SPEED button OPERATION MODE select button...
  • Page 48 All manuals and user guides at all-guides.com '15 • SRK-T-172 Models SRK10CRS-S, S1, S2, S3, S4, S5, S6 Operation and indication section for remote control SRK13CRS-S, S1, S2, S3, S4, S5, S6 SRK10YJV-S Remote control SRK13YJV-S ◆ Operation section Operation section FAN SPEED button OPERATION MODE select button Each time the button is pushed, the...

  • Page 49: Unit On/Off Button

    Unit indication section All manuals and user guides at all-guides.com SRK10YJV-S RUN light (green) SRK13YJV-S '15 • SRK-T-172 Illuminates during operation and CLEAN operation. TIMER light (yellow) Illuminates during TIMER operation. Unit ON/OFF button When the remote control batteries become weak, or if the remote control is lost or malfunctioning, this button may be used to turn the unit on and off.

  • Page 50: Flap And Louver Control

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (5)　Flap and louver control (Louver control function only CRS models)   (a) Flap   (Flap stopped) (Swing)   Angle of Flap from Horizontal Remote control display COOL , DRY, FAN Approx.
  • Page 51 All manuals and user guides at all-guides.com '15 • SRK-T-172 1.4.6 3D auto operation (only SRK10CJV-2, 13CJV-2) (6)　3D auto operation (only CRS models) Control the flap and louver by 3D AUTO button on the wireless remote control. Fan speed and air flow direction are automatically controlled, allowing the entire room to efficiently conditioned. (a) Detail of operation (i) Perform STEP1 →...

  • Page 52: Installation Location Setting

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (7)　Timer operation (a) Comfortable timer setting (ON timer) (b) Sleep timer operation (c) OFF timer operation (8)　Installation location setting (only CRS models) (a) Setting (i) If the air conditioning unit is running, press the ON/OFF button to stop. (ii) Press the AIR FLOW (UP/DOWN) button and the AIR FLOW...

  • Page 53: Outline Of Automatic Operation

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (9) Outline of cooling operation (a) Operation of major functional components in cooling mode Cooling Thermostat ON Thermostat OFF Failure Compressor Indoor fan motor Outdoor fan motor (b) Fan speed switching Model All model Fan speed...

  • Page 54: Protective Control Function

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (11) Protective control function (a) Frost prevention for indoor heat exchanger (During cooling or dehumidifying) (i) Operating conditions Indoor heat exchanger temperature (Th2) is lower than 2.5ºC. 3 minutes elapsed after the start of operation. (ii) Detail of frost prevention operation Compressor Indoor fan...

  • Page 55: Maintenance Data

    All manuals and user guides at all-guides.com '15 • SRK-T-172 10. MAINTENANCE DATA (1) Cautions (a) If you are disassembling and checking an air-conditioner, be sure to turn off the power before beginning. When work- ing on indoor units, let the unit sit for about  minute after turning off the power before you begin work. When work- ing on an outdoor unit, there may be an electrical charge applied to the main circuit (electrolytic condenser), so begin work only after discharging this electrical charge (to DC 0 V or lower).
  • Page 56 All manuals and user guides at all-guides.com '15 • SRK-T-172 (4) Troubleshooting procedure (If the air-conditioner runs) Confirm the contents of the customer complaint. The cause of the trouble can be specifically identified. Eliminate the cause of the trouble and perform an Check the self-diagnosis display.

  • Page 57: Inspection Procedures Corresponding To Detail Of Trouble

    All manuals and user guides at all-guides.com '15 • SRK-T-172 (6) Inspection procedures corresponding to detail of trouble Sensor error [Broken sensor wire, connector poor connection] Is connector connection good? Correct connection. Is sensor resistance value good? Replace sensor. Replace PCB. ◆...
  • Page 58 All manuals and user guides at all-guides.com '15 • SRK-T-172 Trouble of outdoor unit [Compressor malfunction of insufficient gas (refrigerant)] Replace capacitor for compressor. Is capacitor for compressor normal? Does compressor operation? Is connector for compressor connection Correct connection good? Replace compressor.
  • Page 59 All manuals and user guides at all-guides.com '15 • SRK-T-172 (9) How to make sure of wireless remote control Is remote Remote control control normal? defects Replace the display of indoor unit. Again pushing operating switch Is the unit Normal operable with remote control? Abnormality is not...
  • Page 60 All manuals and user guides at all-guides.com...
  • Page 61 All manuals and user guides at all-guides.com '15 • SRK-T-172 PARTS LIST TECHNICAL MANUAL INDOOR UNIT SRK10CRV-S, S1 SRK13CRV-S, S1 SRK10CRS-S, S1, S2, S3, S4, S5, S6 SRK13CRS-S, S1, S2, S3, S4, S5, S6 OUTDOOR UNIT SRC10CRV-S, S1 SRC13CRV-S, S1...
  • Page 62 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY CRAE0215...
  • Page 63 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRV-S, S1 CRAE0215 END ITEM NO. : RMA002F060CA, 060CB Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1-6 RMA102A100 PANEL ASSY,FRONT 1 RKX122A300L PANEL,FRONT 2 RMA435A100...
  • Page 64 All manuals and user guides at all-guides.com '15 • SRK-T-172...
  • Page 65 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRV-S, S1 CRAE0280 END ITEM NO. : RMA002F060CA, 060CB Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1-4 RKX301A007K HEAT EXCH ASSY (AIR) 2 RKX315D005 HEADER ASSY...
  • Page 66 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY CRAE0215...
  • Page 67 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRV-S, -S1 CRAE0215 END ITEM NO. : RMA002F060DA, 060DB Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-6 RMA102A100 PANEL ASSY,FRONT 1 RKX122A300L PANEL,FRONT 2 RMA435A100 PANEL, AIR INLET 3 RKX437A300 FILTER,AIR...
  • Page 68 All manuals and user guides at all-guides.com '15 • SRK-T-172...
  • Page 69 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRV-S, -S1 CRAE0280 END ITEM NO. : RMA002F060DA, 060DB Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-4 RMA301A022 HEAT EXCH ASSY (AIR) 2 RKX315D005 HEADER ASSY 3 RKX129A016 BRACKET ASSY (L) 4 RKX315A004...
  • Page 70 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY 24 15 CRAE0213...
  • Page 71 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S, S1, S2, S3, S4, S5, S6 CRAE0213 END ITEM NO. : RMA002F060AA, AB, AC, AD, AF, AG, AH Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1-6 RMA102A100B PANEL ASSY,FRONT 2 FOR S, S3, S4, S5, S6...
  • Page 72 All manuals and user guides at all-guides.com '15 • SRK-T-172...
  • Page 73 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK10CRS-S, S1, S2, S3, S4, S5, S6 CRAE0280 END ITEM NO. : RMA002F060AA, AB, AC, AD, AF, AG, AH Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-4 RKX301A007K HEAT EXCH ASSY (AIR) 2 RKX315D005...
  • Page 74 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY 24 15 CRAE0213...
  • Page 75 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S, S1, S2, S3, S4, S5, S6 CRAE0213 END ITEM NO. : RMA002F060BA, BB, BC, BD, BF, BG, BH Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-6 RMA102A100B PANEL ASSY,FRONT 2 FOR S, S3, S4, S5, S6...
  • Page 76 All manuals and user guides at all-guides.com '15 • SRK-T-172...
  • Page 77 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRK13CRS-S, S1, S2, S3, S4, S5, S6 CRAE0280 END ITEM NO. : RMA002F060BA, BB, BC, BD, BF, BG, BH Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-4 RMA301A022 HEAT EXCH ASSY (AIR) 2 RKX315D005...
  • Page 78 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY CRBE0290...
  • Page 79 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC10CRV-S, -S1 CRBE0290 END ITEM NO. : RMC003F060CA, 060CB Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1 RCV122A006C PANEL ASSY, FRONT 2 RCV123A001 PANEL ASSY,SIDE(R) 3 RCV124A500A PANEL ASSY, TOP 4 RCV132A003...
  • Page 80 All manuals and user guides at all-guides.com '15 • SRK-T-172 HEAT EXCH. & CONTROL 17 23 (LIQ.) (GAS) CRBE0420...
  • Page 81 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC10CRV-S, -S1 CRBE0420 END ITEM NO. : RMC003F060CA, 060CB Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1-3 RMC301A082 HEAT EXCH ASSY (AIR) 2 RMC321A262 PIPE ASSY 3 RMC321A263 PIPE ASSY 4-5 RMC304A041...
  • Page 82 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY CRBE0290...
  • Page 83 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC13CRV-S, S1 CRBE0290 END ITEM NO. : RMC003F060DA, DB Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1 RCV122A005B PANEL ASSY, FRONT 2 RCV123A005B PANEL ASSY SIDE(R) 3 RCV124A500A PANEL ASSY,TOP 4 RCV132A004...
  • Page 84 All manuals and user guides at all-guides.com '15 • SRK-T-172 HEAT EXCH. & CONTROL 19 24 (LIQ.) (GAS) CRBE0288a...
  • Page 85 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC13CRV-S, S1 CRBE0288a END ITEM NO. : RMC003F060DA, DB Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-3 RMC301A087 HEAT EXCH ASSY (AIR) 2 FOR SPARE PART 2 RMC321A292 PIPE ASSY 3 RMC321A295...
  • Page 86 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY CRBE0290...
  • Page 87 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC10CRS-S, S1, S2, S3, S4, S5, S6 CRBE0290 END ITEM NO. : RMC003F060AA, AB, AC, AD, AF, AG, AH Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1 RCV122A006C PANEL FRONT 2 RCV123A001...
  • Page 88 All manuals and user guides at all-guides.com '15 • SRK-T-172 HEAT EXCH. & CONTROL 17 23 (LIQ.) (GAS) CRBE0420...
  • Page 89 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC10CRS-S, S1, S2, S3, S4, S5, S6 CRBE0420 END ITEM NO. : RMC003F060AA, AB, AC, AD, AF, AG, AH Recommendable Purchased Q'ty Part No. Part Name Note RE.Q 100 500 1000 1-3 RMC301A082 HEAT EXCH ASSY (AIR) 2 RMC321A262...
  • Page 90 All manuals and user guides at all-guides.com '15 • SRK-T-172 PANEL & FAN ASSY CRBE0290...
  • Page 91 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC13CRS-S, S1, S2, S3, S4, S5, S6 CRBE0290 END ITEM NO. : RMC003F060BA, BB, BC, BD, BF, BG, BH Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1 RCV122A005B PANEL ASSY, FRONT 2 RCV123A005B...
  • Page 92 All manuals and user guides at all-guides.com '15 • SRK-T-172 HEAT EXCH. & CONTROL 19 24 (LIQ.) (GAS) CRBE0288a...
  • Page 93 All manuals and user guides at all-guides.com '15 • SRK-T-172 SRC13CRS-S, S1, S2, S3, S4, S5, S6 CRBE0288a END ITEM NO. : RMC003F060BA, BB, BC, BD, BF, BG, BH Recommendable Purchased Q'ty Part No. Part Name RE.Q Note 100 500 1000 1-3 RMC301A087 HEAT EXCH ASSY (AIR) 2 FOR SPARE PART...
  • Page 94 All manuals and user guides at all-guides.com RESIDENTIAL AIR-CONDITIONING TECHNICAL MANUAL & PARTS LIST Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. Copyright MITSUBISHI HEAVY INDUSTRIES, LTD.

This manual is also suitable for:

Srk10crv-s1Srk13crv-sSrk13crv-s1Srk10crs-sSrk10crs-s1Srk10crs-s2 ... Show all
