BLUE EMBER GRILLS FG50057 Assembly Manual And Use And Care

Outdoor gas barbeque/grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Outdoor Gas Barbeque/Grill
Assembly manual and Use and Care
MODEL
FG50057
(Propane/Natural Gas Series)
MODEL MAY NOT BE EXACTLY AS SHOWN
!
WARNING!
Hazardous Fire or Explosion may result if
these instructions are ignored.
It is your responsibility to see that your new barbeque
is assembled, installed, maintained and cared for
properly. Failing to carefully follow the instructions in
this manual could result in serious bodily injury and/or
property damage. Any modification to the barbecue is
dangerous and is not permitted.
WARRANTY INFORMATION
Full Model No. from outer carton:_______________________
Date Purchased:_____________________________________
Serial Number
(
: _____________________________________
from rating plate)
SAVE THIS MANUAL FOR FUTURE REFERENCE
Installer must leave instructions with the consumer for future reference.
KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE THE WARRANTY.
ATTACH YOUR RECEIPT TO THE INSIDE COVER OF THIS MANUAL FOR EASY
REFERENCE.
Imported by: Home Depot of Canada Inc.
MANUFACTURED FOR:
900-1 Concorde Gate Toronto, Ontario M3C 4H9 Canada
Onward Manufacturing Company
Manufactured for: Fiesta Barbeques A Division of Wolfedale Engineering Ltd.
585 Kumpf Drive, Waterloo, Ontario Canada N2V1K3
2 Walker Drive, Brampton, Ontario L6T 5E1 Canada
Made in China
THIS APPLIANCE IS FOR OUTDOOR USE ONLY
DANGER!
!
IF YOU SMELL GAS:
1. Shut off gas supply to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odour continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
WARNING!
!
• Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
• An LP cylinder not connected for use shall not
be stored in the vicinity of this or any other
appliance.
!
CAUTION!
Some parts may contain sharp edges-especially if
noted in the manual! Wear protective gloves if
necessary.
1-800-265-2150
1-888-267-2159
C
www.blueembergrills.com
SP1716A-37
SP1716-37
CA-041011
US
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FG50057 and is the answer not in the manual?

Questions and answers

Related Manuals for BLUE EMBER GRILLS FG50057

Summary of Contents for BLUE EMBER GRILLS FG50057

  • Page 1 Outdoor Gas Barbeque/Grill Assembly manual and Use and Care MODEL FG50057 (Propane/Natural Gas Series) DANGER! MODEL MAY NOT BE EXACTLY AS SHOWN WARNING! IF YOU SMELL GAS: 1. Shut off gas supply to the appliance. Hazardous Fire or Explosion may result if 2.

  • Page 2: Table Of Contents

    THANK YOU FOR FOR RESIDENTIAL USE ONLY. PURCHASING THIS BARBEQUE DO NOT USE FOR COMMERCIAL CAUTION COOKING. We are dedicated to creating the ultimate barbeque experience by providing you with all the right tools, Combustion by-products produced when starting with this manual. It is important to read using this product contain chemicals known to the state of California to cause cancer, birth WARNING...

  • Page 3: Getting Familiar With Your Barbeque

    GETTING FAMILIAR WITH YOUR BARBEQUE DO NOT USE YOUR BARBEQUE UNTIL YOU HAVE Fig. 1 READ AND UNDERSTOOD ALL THE 10mm CASTING INFORMATION IN THIS MANUAL. WARNING IT IS EXTREMELY IMPORTANT TO BE SURE THAT: BEFORE YOU USE THIS APPLIANCE •...

  • Page 4: Electrical Caution

    CARING FOR YOUR EQUIPMENT PROVIDING POWER TO YOUR BARBEQUE ELECTRICAL CAUTION To provide power to the barbecue, plug grounded electrical cord into • If any accessory installed on this barbeque requires an external rear electrical box as shown. (Page 14, Fig.15) electrical power source, it must be electrically grounded in accordance with local laws or in the absence of local laws, with Plug electrical cord into properly grounded...
  • Page 5 TRANSPORTATION AND STORAGE: ALTHOUGH IT IS SAFE WHEN USED PROPERLY, CARELESS HANDLING OF THE PROPANE GAS CYLINDER COULD RESULT IN WARNING FIRE, EXPLOSION, AND/OR SERIOUS INJURY. PROPANE GAS IS HEAVIER THAN AIR, AND WILL COLLECT IN LOW AREAS, INCREASING THE ABOVE RISKS. THEREFORE: •...

  • Page 6: Hose & Regulator

    NOTE: IMPROPER LIGHTING PROCEDURES CAN CAUSE THE FLOW HOSE & REGULATOR CONTROL TO ACTIVATE, RESULTING IN REDUCED HEAT OUTPUT. IF THIS IS SUSPECTED, RESET THE FLOW CONTROL BY SHUTTING OFF ALL BURNER CONTROLS AND THE CYLINDER VALVE. WAIT WARNING: INDICATES AN POTENTIALLY 30 SECONDS, THEN TURN THE CYLINDER VALVE ON EXTREMELY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, SLOWLY - WAIT 5 SECONDS AND TURN THE BURNER VALVE ON...

  • Page 7: Cleaning & Maintenance

    CLEANING & MAINTENANCE To keep your barbeque working at its peak efficiency as well as contribute DO NOT IGNITE THE BURNERS WHILE PERFORMING THE LEAK to the safe operation of this unit, perform all of the operations below at CHECK. 2.

  • Page 8: Cleaning Other Parts Of Your Appliance

    CASTING INTERIOR AND WARMING RACK: CLEANING OTHER PARTS OF At least once a year remove all components from inside your barbeque. YOUR APPLIANCE Loosen any cooking residue with a scraping tool for large particles and a brass barbeque brush for smaller particles. Scrub with hot water and a General Grill Cleaning: Do not mistake brown or black accumulation of strong detergent, then rinse thoroughly or spray barbeque degreaser grease and smoke for paint.

  • Page 9: Using Your Appliance Correctly

    USING YOUR APPLIANCE CORRECTLY BEFORE USING YOUR APPLIANCE READ ALL INSTRUCTIONS IN THIS MANUAL Fig. 9A WARNING: ENSURE SIDE BURNER LID IS UP BEFORE LIGHTING SIDE BURNER. INTERNAL LIGHT LEFT BURNER CENTER BURNER IGNITOR MODEL MAY NOT BE EXACTLY AS SHOWN. SIDE BURNER PARTS OPTIONAL (READ WARNING)

  • Page 10: Lighting

    LIGHTING IF LIGHTING MAIN BURNERS ONLY, ENSURE SIDE BURNER KNOB Prior to lighting your barbeque, visually check all hoses before each CAUTION IS IN THE OFF POSITION. use for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, DO NOT USE YOUR BARBEQUE.

  • Page 11: Relighting

    SIDE BURNER (OPTIONAL) USING THE IGNITOR 1. Raise side burner lid. 2. Push in and turn the side burner control knob to 'HIGH'. 3. Depress ignitor. Repeat if necessary (Figure 12A). 4. If burner does not light immediately (within five seconds), turn the burner control knob off, and wait 5 minutes to clear the gas.

  • Page 12: Shutting Down

    COOKING TEMPERATURES SHUTTING DOWN YOUR HIGH Setting: Use the HIGH setting to preheat the barbeque, sear meat such as steak, & to burn off any cooking residue from the BARBEQUE grids after cooking your meal. HIGH is rarely used for extended cooking.

  • Page 13: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSES CORRECTION Burner Will Not Light (match or ignitor) • Blocked venturi tubes • Clean out blockage (Page 7) or Burners Not Hot Enough • Cylinder or gas supply valve turned off • Open cylinder or gas supply valve •...
  • Page 14 WARRANTY The OMC Warranty is eff ective from date of purchase and is BURNERS limited to the repair or replacement of parts at no charge which The life of OMC burners (made of stainless steel) depends prove to be defective under normal domestic use. almost entirely on proper use, cleaning and maintenance.

  • Page 15: Warranty Information

    CASTER ASSEMBLY FIG.1 NOTE: Assembled Some grill parts shown in the assembly steps View may differ slightly in appearance from those on your particular grill model. However, the method of assembly remains the same. TOOLS REQUIRED: • Extra Common Nuts & Bolts are supplied.
  • Page 16 BASE CABINET ASSEMBLY • Attach Cabinet side panels to base as shown. Assembled NOTE: Right panel has two holes located on View the top right corner for bottle opener. • Attach bottle opener to right panel as shown. SP53-16 (2) 1/4-20 NUT HEX HD FLANGED Right hand Panel...
  • Page 17 REAR PANEL ASSEMBLY • Attach rear panel by sliding notches over screws on side panels as shown. Tighten screws. Assembled View SP46-21 (4) 1/4" X1/2" SCREW HEX HD SP84-18 (2) 1/4-20 X .5 HEX HD BOLT F F IG.4 SP46-21 (4) 1/4" X 1/2" SP84-18 (2) 1/4-20 X .5 SCREW HEX HD HEX HD BOLT...
  • Page 18 TRIM PANEL & HEAT SHIELD ASSEMBLY • Attach top trim panel as shown. Assembled Tighten screws. View • Attach heat shield as shown. Tighten screws SP61-21 (7) 10-B X .375 SCREW SELF TAP SP53-16 (4) 1/4-20 NUT HEX HD FLANGED SP83-18 (4) 1/4"-20X.50"...
  • Page 19 FRONT DOOR ASSEMBLY Assembled View • Install door handles as shown. • Slide top pins on doors into upper holes as shown. • A) Drop locking pins through lower holes in door into base assembly. #10-24 NUT HEX HD • B) Once in position rotate pins into FLANGED HANDLE locked position as shown.
  • Page 20 CASTING ASSEMBLY REGARDING IMPROPER ASSEMBLY OF HOSE ON PROPANE AND NATURAL GAS FG/FGQ/FGF500 MODELS DURING THE ASSEMBLY PROCESS OF THE BASE ASSEMBLY STEP, THE CUSTOMER NEEDS TO ENSURE THAT THE HOSE IS UNTIED FROM BURNER BEFORE FINAL ASSEMBLY. CUSTOMER SHOULD RELEASE THE TIE AND PASS THE HOSE THROUGH THE GAP BETWEEN HEAT SHIELD WARNING AND FRONT PANEL BEFORE ASSEMBLING THE FIREBOX (BASE) TO THE CART (CABINET).
  • Page 21 CASTING ASSEMBLY CONTINUED FAILURE TO ENSURE ANY OF THESE • Using two people, lower the top cover assembly carefully WARNINGS MAY RESULT IN onto base and attach as shown. HAZARDOUS FIRE OR EXPLOSION • Push hose assembly through front of cart assembly CAUSING SERIOUS BODILY INJURY WARNING ensuring it goes between heat shield and front panel...
  • Page 22 CASTING ASSEMBLY CONTINUED • Secure base casting as shown. Important For Natural Gas models, direct the hose through the hole in the base as shown. DANGER: DO NOT PASS HOSE ABOVE SHIELD HOSE MUST NOT TOUCH ANY PART OF THE BASE WARNING: DANGER ENSURE HOSE ASSEMBLY DOES NOT CONTACT THE...
  • Page 23 GRID ASSEMBLY FIG.7 Step 2 Step 3 Step 1 Step 1 • Rest the ends of heat plates into notches inside casting as shown. Step 2 • Install Smoker on hooks inside cover assembly. Step 3 • Install 3 grids as shown. Step 4 •...
  • Page 24 SIDE SHELF ASSEMBLY F F IG.8 Assembled View • Position side shelves onto shelf brackets as shown (A). Lift shelf and drop into locking position (B). Insert wingbolt into middle hole in bracket to lock shelf in position (C). • Position ice/wine bucket and condiment tray as shown.
  • Page 25 SIDE BURNER HOSE ASSEMBLY • Position hose into end of side burner venturi tube until groves line up (A). Snap clip into the groove on side burner tube to secure parts (B). • Check hose to ensure it is securely positioned in tube end. •...
  • Page 26 GREASE TRAP ASSEMBLY DO NOT ALLOW GREASE TO BUILD UP IN BOTTOM OF BARBEQUE. PLEASE CLEAN ON A REGULAR BASIS TO ENSURE EXCESSIVE CAUTION GREASE DOES NOT BUILD UP ON BOTTOM PAN. Grease Pan • Slide in grease pan and grease tray as shown (fully forward).
  • Page 27 TANK ASSEMBLY FOR PROPANE MODELS PLEASE FOLLOW THE FOLLOWING STEPS FOR NG MODELS PLEASE FOLLOW THE FOLLOWING STEPS BEFORE PROCEEDING WITH THE FOLLOWING STEPS, ENSURE YOU HAVE READ-NATURAL GAS WARNING SECTIONS OF THE USE AND CARE INSTRUCTIONS. Important For NG models, direct the hose through the hole in the base as shown.
  • Page 28 151* 150* FG50057...
  • Page 29 ITEM QTY. SP PART No. DESCRIPTION Gas Barbeque Grill: SP155-42 COVER ASSY SP37-33 COVER CAST END CAP LH Model FG50057 SP38-33 COVER CAST END CAP RH SP87-9 COVER PANEL HOW TO ORDER SP88-9 COVER LINER SPARE PARTS: SP53-19 HANDLE SP43-33...
  • Page 30 DESCRIPTION SP104-9 BOTTOM PAN RESIN Gas Barbeque Grill: SP46-16 1/4-20 INSERT NUT SP59-16 3/8-16 INSERT NUT Model FG50057 SP53-16 1/4-20 NUT HEX HD FLANGED SP83-18 1/4"-20 X .50" CARRIAGE BOLT HOW TO ORDER SP84-18 1/4-20 X .5 HEX HD BOLT...
  • Page 31 STOP Should you encounter a problem with our product CALL US FIRST Do not return this product to the store. WE CAN HELP GRILL SERVICE CENTER 1-800-265-2150 in Canada 1-888-267-2159 Grilling Safety Checklist ❑ Read and understand owners manual. ❑ Never overfill LP cylinder. Overfilled cylinders may cause freeze-up of regulator.
