Lighting Fixture
Installation Guide
WALL WASHER DOWNLIGHT
MMP-080W/20B/Z1/2
Installation Details Installation Diagram
1
Ceiling cut out
Install the mounting equipment
for ceiling cut out
Φ3-15/64"(82mm)
1 Accurately cut a 3-15/64" opening
and install the mounting frame.
Leave space to rotate
the lighting fixture
φ82mm
φ3-15/64"
2 Slide the metal fittings from upper
500mm
side
19 "
11/16
3
Use a screw driver and tighten the
metal fittings
On step 2, please fix the metal
a fitting firmly with your fingers.
If not, it may cause falling of fixtures
Make sure to tighten the metal
fittings securely with a screwdriver.
b
(torque 1.0 〜2.0 N・m) If it is loose,
it may cause falling of the fixture
Metal fitting
Wiring connection
Provide electrical service according
1
to the "National Electrical Code" or
your local electrical code from a
suitable junction box to the
2
wiring box(located on the plaster
frame).
Remove the fixture wiring box
2
cover.
Remove appropriate round knock-
out(s) and connect conduit to
wiring box with proper connect-
or(s)(not included).
3
TO 0-10V DIMMER
Connect supply wires to wires in
3
fixture wiring box with proper size
CAPPED 0-10V
wire nuts(not included).Be sure
CONTROL WIRES
to cover all bare current carrying
conductors.Connect white to white;
black to black; and green or bare
DRIVER
copper wire(from electrical service)
to bare copper wire(in wiring box)
For 0-10V dimming
Make the two connections to the
violet and grey wires and tuck them
back into the smaller compartment. Prepare a wire with a margin
to rotate the lighting fixture
Make sure the supply wire connec-
tions remain separate and are locat-
ed in the larger junction box comp-
artment.
Place wires and connections back in
4
wiring box and replace cover.
Caution
a
Space to rotate
the lighting fixture
Mounting frame
Push tight
2
Ceiling
3
Make certain no bare wires are
box cover exposed outside the connectors.
*Wire nuts by others.
WIRE NUT*
BLACK BLACK
WIRE NUT*
WHITE WHIT E
GREEN OR BARE
GREEN OR BARE
WIRE NUT*
Installation Details
Installation to ceiling
b
Install the safety wire to the
1
mounting frame.
Install the fixture to the mounting
2
frame.
Make sure to install the safety wire
h
to the mounting frame securely.
Use clean soft cloth to clean up and
i
maintain inner side of the body.
Make sure the fixture will not touch
Standard to screw
any objects in ceiling.
torque 1.0〜2.0N・m
Install with MINIMUM SPACINGS
between (a) center-to-center
of adjacent luminaires:
600 mm ( 24̲ in);
(b) top of luminaire to
overhead building member:
200 mm ( 8 in);
(c) luminaire center to side
building member:
300 mm ( 12 in)
Installation Diagram
h
Safety wire
1
Ceiling
2
Mounting frame
Safety wire
(a)
(a)
(c)
【Direction of radiation】
wall
Lighting
Fixture
Tokyo
R
1-20-6 BF1 Ebisuminami,Shibuya-ku,
Tokyo,152-0022,Japan
Tel:81-3-5768-3681
To install ModuleX safety
Caution
i
Mounting frame
Fixture
Inside
Clean gloves
(b)
