Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Table of Contents 1 Introduction General 1 - 1 Additional Information 1 - 1 Customer Training 1 - 2 Customer Service 1 - 2 Technical Support 1 - 2 Product Repair and Return...
Page 6
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Frame Ground 5 - 6 Fuse or Circuit Breaker Panel 5 - 6 Meter and Alarm Termination Panel 5 - 9 6 Product Warranty 2 - Table of Contents Issue 4 January 1999...
Page 7
5 - 4 Figure 5-4A: List C Fuse Panel for J85568E-1 Mini-Distribution Bay 5 - 7 Figure 5-4B: List D Circuit Breaker Panel for J85568E-1 Mini-Distribution Bay 5 - 8 Figure 5-5: Fuse Sizes and Ordering Comcodes for Mini-Distribution Bay...
Page 9
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay List of Tables Table 3-A: J85568E-1 Mini-Distribution Bay Ordering Information 3 - 1 Table 3-B: Recommended Double Hole Terminal Lugs for Terminating Load Cables (750KCMIL Maximum) 3 - 3 Table 3-C: Recommended Double Hole Terminal Lugs...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Introduction General This product manual (Select Code 157-005-102) describes the J85568E-1 Secondary DC Distribution Mini-Bay. This unit is also known as a Mini-Battery Distribution Fuse Bay (Mini-BDFB) or Mini-Battery Distribution Circuit Breaker Bay (Mini-BDCBB). Complementing the 7-foot, 9-foot and 11.5-foot J85568C-1 series of DC Power Distribution Bays, the...
For other customers worldwide, contact your local field support center or your sales representative to discuss your specific needs. Product Repair Repair and return service is provided for Lucent Technologies customers around the world. For customers in the United States, and Return...
Page 13
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay conformance issues prior to customer ownership, contact your local customer service. Issue 4 January 1999 Introduction 1 - 3...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Product Description Overview The J85568E-1 Mini-Distribution Bay (Power Distribution Bay) distributes -48Vdc power in a two-load arrangement, with a 300-ampere capacity per load. There are four fuse or circuit breaker panel positions. Load Bus A connects the top two fuse or circuit breaker panels.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay • Internal 2-hole return bus • Digital current meter • Visual alarm indication per panel – Red LED - Fuse Alarm – Green LED - Power On – GMT alarm fuse per fuse block •...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay 23.33 22.33 12.00 Central Office Panel White Color Position Figure 2-1: J85568E-1 Mini-Distribution Bay (four fuse panels shown) Issue 4 January 1999 Product Description 2 - 3...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Ordering Information List Structure Table 3-A describes the list structure of the J85568E-1 Mini-Distribution Bay. List 2 provides the assembly with four empty panel positions. Panel positions 1 and 3 must be equipped with a fuse or circuit breaker panel to support bus bars.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay 1. The engineer must furnish all terminal lugs for load and return leads. Hardware for terminating load leads, load return leads, input battery and return cabling, and frame ground is provided with List 2.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Table 3-E: Recommended Single Hole Terminal Lugs for Terminating to Circuit Breakers KS-5482 KS-20921 Terminal Mounting Comcode Wire Wire Material WP-91412 L94 406338152 WT-1300 Furnished WP-91412 L74 405356189 With WP-91412 L2 405347436 Blue...
Page 23
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay ED-83127-30 Fuse or Circuit Breaker Panel 157-005-102 J85568E-1 Mini-Distribution Bay Product Manual Issue 4 January 1999 Ordering Information 3 - 5...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Safety Please read this section carefully before installing, maintaining, or repairing the J85568E-1 Mini-Distribution Fuse Bay. Admonishments Always take precautions to protect personal safety as well as the equipment when working on power systems. Throughout this manual, admonishments relating to personal safety are labeled DANGER or Warning.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay For all installations, the appropriate connector should be applied only to the correct size conductor as specified by the connector manufacturer, using only the connector manufacturer's recommended tooling or tooling approved for that connector.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay – Be aware of potential hazards in the area you are working before entering the equipment. – Identify exposed hazardous electrical potentials on connectors, wiring, etc. (note the condition of these circuits, especially any wiring).
Page 28
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay One of these two symbols (or equivalent) may be used to identify the presence of rectifier and battery voltages. The symbol may sometimes be accompanied by some type of statement, for example: “Battery voltage present.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Electrostatic – Assume all circuit packs containing electronic (solid-state) components can be damaged by ESD. Discharge – When handling circuit packs (storing, inserting, (ESD) removing, etc.) or when working on the backplane, always use the appropriate grounding procedure:...
Page 30
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay – Minimize electrostatic discharge when handling circuit modules. 4 - 6 Safety Issue 4 January 1999...
Page 31
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Issue 4 January 1999 Safety - 7...
Page 32
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay - 8 Safety Issue 4 January 1999...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Installation Safety Read Section 4, Safety , carefully before installing the J85568E-1 Mini-Distribution Bay. Tools and The following tools are required to install the Mini-Distribution Bay: Materials Required • Equipment to handle shipping container, remove...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Unpacking, Before opening the packaging, carefully inspect the outside in the presence of shipping personnel for signs of damage. If Handling, and damaged, follow the shipping carrier's procedure for filing a Frame damage claim.
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Hold Down Plate Floor Anchor Bolt Framework Base Hold Down Washer Floor Covering Note: Use 3/4 Inch Drill for Floor Anchor Bolts. The Required Minimum Drill Depth is 4 Inches. Figure 5-1: Typical Floor Mounting Detail 7.25...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Frame Ground Connection Alarm Termination Board Bus A Bus B Product Manual Holder Distribution Return Bus Figure 5-3: Rear View of Mini-Distribution Bay and A/B Load Connections (four fuse panels shown) 5 - 4 Installation...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Connecting List 2 is configured with two load buses. A 300-ampere shunt and bus bar assembly connects Load Bus A to the top two fuse Load and or circuit breaker panels and Load Bus B to the bottom two fuse Distribution panels.
Page 38
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Frame Ground The frame ground connection is located on the top rear crossbar. Connection is made using a 1/4-inch double hole terminal lug on 0.625-inch centers. Refer again to Table 3-C for recommended terminal lugs for the frame ground connection.
EQUIPMENT TYPE Red LED SPARE FUSES FUSE Green LED ALARM POWER FUSE SIZE (AMPS) Front View Alarm Circuit Module BEP1 Rear View Figure 5-4A: List C Fuse Panel for J85568E-1 Mini-Distribution Bay Issue 4 January 1999 Installation 5 - 7...
POWER FUSE/CB (AMPS) Front View Alarm Circuit Module BEP1 Rear View Figure 5-4B: List D Circuit Breaker Panel for J85568E-1 Mini-Distribution Bay Figure 5-5: Fuse Sizes and Ordering Comcodes for Mini-Distribution Bay 5 - 8 Installation Issue 4 January 1999...
Page 41
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Meter and The top panel on the Mini-Distribution Bay is a meter and alarm termination panel. It consists of a digital meter and A/B switch Alarm wired to the current monitoring shunts of each load and an alarm Termination termination circuit board.
Page 42
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay If wiring for Open on Alarm (AUD, VIS, or REMOTE), strap across the common and normally closed contacts in the empty fuse panel positions of the 847206737 PWB assembly on the rear of the alarm and meter panel. For example, if fuse panels are...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Table 5-A: DIP Switch Settings and Alarm Connections for Generating Frame Alarms Closure on Alarm (FAJ: C and NO Contacts; PWR Loss: C and NC Contacts) Alarm Connection Alarm Type DIP Switch Setting...
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay BUNDLE CABLES IN SETS OF FOUR. RECOMMENDED CABLING PLAN 5.5" FROM WALL IT MAY BE NECESSARY TO STACK FOR FULLY LOADED PLANT BUNDLES. TIE DOWN TOP CROSS-BAR INPUT FEEDER CABLES INPUT FEEDER CABLE...
Page 45
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Product Warranty A. Seller warrants to Customer only, that: 1. As of the date title to Products passes, Seller will have the right to sell, transfer, and assign such Products and the title conveyed by Seller shall be good;...
Page 46
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay Warranty Period Repaired Product Product Type New Product or Part* Central Office 24 Months 6 Months Power Equipment** The Warranty Period for a repaired Product or part thereof is as listed or, in the case of Products under Warranty, is the period listed or the unexpired term of the new Product Warranty Period, whichever is longer.
Page 47
Lucent Technologies J85568E-1 Secondary DC Mini-Distribution Bay associated with returning such Product to Seller shall be borne by Customer. Seller shall pay the cost of transportation of the repair or replacing Product to the destination designated by Customer within the Territory.
