- Page 1 Secondary DC Power Distribution Bay H569-445 Product Manual Select Code 157-005-104 Comcode 108405283 Issue 5 May 2000 © 2000 Lucent Technologies...
- Page 3 Secondary DC Power Distribution Bay H569-455 Notice: The information, specifications, and procedures in this manual are subject to change without notice. Lucent Technologies assumes no responsibility for any errors that may appear in this document. © 2000 Lucent Technologies All Rights Reserved...
-
Page 5: Table Of Contents
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Table of Contents 1 Introduction Product Summary 1 - 1 Documentation 1 - 3 Customer Assistance Contacts 1 - 3 Customer Training 1 - 3 Customer Service 1 - 3 Technical Support... - Page 6 Lucent Technologies Secondary DC Power Distribution Bay H569-445 4 Product Warranty 2 - Table of Contents Issue 5 May 2000...
- Page 7 Lucent Technologies Secondary DC Power Distribution Bay H569-445 List of Figures Figure 1-1: H569-445 Secondary DC Power Distribution Bay 1 - 2 Figure 2-1: 2-1/2-Foot Extension Cabinet 2 - 4 Figure 2-2: 2-Foot or 4-1/2-Foot Extension Cabinet 2 - 5...
- Page 9 Lucent Technologies Secondary DC Power Distribution Bay H569-445 List of Tables Table 2-A: Lugs and Hardware for Breakers and Fuses 2 - 13 Table 2-B: Lugs and Hardware for External Return Bus Bars 2 - 14 Issue 5 May 2000...
-
Page 11: Introduction
In many applications, telecommunication equipment requires power redundancy from the battery plant. A BDFB or BDCBB provides this redundancy through the use of multiple load buses. The H569-445 is a cabinetized distribution system that supports these applications by providing up to six distinct load buses for the 7-foot cabinet or up to eight distinct load buses for the 9-foot cabinet. -
Page 12: Figure 1-1: H569-445 Secondary Dc Power
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Figure 1-1: H569-445 Secondary DC Power Distribution Bay 1 - 2 Introduction Issue 5 May 2000... -
Page 13: Documentation
• H569-445 Ordering and Installation Guide • T-83150-30 Wiring Drawing • SD-83150-01 Schematic Drawing This documentation is provided with each H569-445 bay in Documentation Service Kit, Comcode 848296505. Customer Assistance Contacts Customer Training Lucent Technologies offers customer training on many Power Systems products. -
Page 14: Product Repair And Return
For domestic warranty service, contact your Warranty Service Manager (WSM). For international warranty service, contact your sales representative. On-Line Power For Lucent Technologies users logging in from inside the corporate Systems Product firewall, the address of the “Power Systems On-Line Product Manuals” Manuals page is http://www.cic.lucent.com/lineage.html. -
Page 15: Product Description
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Product Description Cabinet The Secondary DC Power Distribution Bay, Model H569-445, is available in five cabinet arrangements. These include: Arrangements 7-foot cabinet: 26 inches wide by 15 inches deep 7-foot cabinet with 2-foot extension cabinet... -
Page 16: Features
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Features The following is a list of the many features provided with this product: Distributes +24, -48, or ±130 volt dc power (±130 volt not offered • with BDCBB) • 7-, 9-, or 11-1/2-foot cabinet arrangements •... -
Page 17: Cabinet Types And Features
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Cabinet Types Two cabinet types and three cabinet extension options are available: and Features Group 1 7 ft Cabinet Group 2 9 ft Cabinet 848258562 2-1/2 ft Extension Cabinet for 9 ft cabinet... -
Page 18: Figure 2-1: 2-1/2-Foot Extension Cabinet
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Cabinet Types and Features, continued 9' Cabinet Frame Mounting Hardware Ground Strap Figure 2-1: 2-1/2-Foot Extension Cabinet 2 - 4 Product Description Issue 5 May 2000... -
Page 19: Figure 2-2: 2-Foot Or 4-1/2-Foot Extension Cabinet
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Cabinet Types and Features, continued 4-1/2' Frame Frame Mounting Mounting Hardware Hardware Ground Ground Strap Strap 7' Cabinet 7' Cabinet L u c L u c e n t e n t... -
Page 20: Figure 2-3: Fuse Panel Position Numbering
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Cabinet Types and Features, continued Panel Position 1 Panel Position 2 (fuse panel shown) (fuse panel shown) Panel Position 3 Panel Position 4 (fuse panel shown) (fuse panel shown) Panel Position 5... -
Page 21: Figure 2-4: Circuit Breaker Panel Position Numbering
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Cabinet Types and Features, continued Panel Position 6 Panel Position 5 (blank panel shown) (blank panel shown) Panel Position 4 Panel Position 3 (fuse panel shown) (fuse panel shown) Panel Position 2... -
Page 22: Load Bus Arrangements
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Load Bus The bus bars used in the distribution bay are sized to provide a rated current carrying capacity of 600 amperes. (A minimum of two 750 Arrangements KCMIL feeder cables are required per shunt for currents larger than 500 amps per shunt.) A load bus is defined as one or more fuse or circuit... -
Page 23: Figure 2-5: Group 20 Load Connection Points
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Load Bus Arrangements, continued Group 61 Bus Bar (Group 61 provides 1 left side and 1 right side bus bar.) Battery Input Cable Connection 800A Shunts Group 20 Load Connection Group 40 Bus Bar Link... -
Page 24: Discharge Return Bus Options
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Discharge Two optional discharge return bus options are available for terminating fuse or circuit breaker return leads: (1) Bus bar returns located in the Return Bus distribution bay (G-61 and G-61A) or (2) A return bus located outside Options the distribution bay on a cable rack. -
Page 25: Figure 2-6: External Discharge Return Bus Options On Cable Rack
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Discharge Return Bus Options, continued 848258687 848258679 ED83019-50 Group 1 Figure 2-6: External Discharge Return Bus Options on Cable Rack Issue 5 May 2000 Product Description 2 - 11... -
Page 26: Figure 2-7: Bus Bar Hole Pattern And Numbering Schemes
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Discharge Return Bus Options, continued .221 Dia. on .62 Centers (24 Places) Row A for 1st Level Row B for 1st Level .437 Dia. on 1.00 Centers Row D for 2nd Level... -
Page 27: Lugs And Hardware
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Lugs and Hardware Breakers and Fuses Table 2-A: Lugs and Hardware for Breakers and Fuses Wire Gauge Type Hardware Comcode Flex 406338152 Load Provided 14-10 14-10 406144428 Return Provided 405356189 Load Provided... -
Page 28: External Return Bus Bars
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Lugs and Hardware, continued External Return Bus Bars Table 2-B: Lugs and Hardware for External Return Bus Bars Wire Gauge Comcode Flex 405356171 10-14 10-14 Rows B & E for 848258679 & 848258687 405348178 &... -
Page 29: Digital Meters And Monitoring Shunts
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Digital Meters As discussed in the previous sections, there are six possible load buses in the 7-foot distribution bay, three per side, and eight possible load and Monitoring buses in the 9-foot distribution bay, four per side. Each load bus is Shunts equipped with an 800 ampere shunt per Group 20. -
Page 30: Figure 2-9: G-71 Digital Meter
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Digital Meters and Monitoring Shunts, continued G-71 The G-71 digital meter monitors the 800-ampere shunts, as well as each distribution panel voltage (see Figure 2-9). It is available only for the 48-volt system. The shunts are wired to the meter through a rotary switch, enabling the user to select any of the possible load buses. -
Page 31: Groups 30A-30D
Lucent Technologies Secondary DC Power Distribution Bay H569-445 ED83127-30 Fuse Panels Groups 30A-30D Each fuse panel is equipped with 20 single position fuse blocks for TPS fuses. If alternate fuse blocks are desired, they can be ordered separately and installed in the field. Spare fuse holders are supplied with the fuse panels. -
Page 32: Figure 2-10: H569-445 Group 30A-30D Fuse Panel (One Shown; Two Are Provided Per Group)
Lucent Technologies Secondary DC Power Distribution Bay H569-445 ED83127-30 Fuse Panels, continued Front Back Figure 2-10: H569-445 Group 30A-30D Fuse Panel (One Shown; Two Are Provided Per Group) 2 - 18 Product Description Issue 5 May 2000... -
Page 33: Groups 31A And 31B
Lucent Technologies Secondary DC Power Distribution Bay H569-445 ED83127-30 Fuse Panels, continued Groups 31A and Groups 31A and 31B each provide two circuit breaker panels, one for the left side and one for the right side of the bay. See Figure 2-11 (one shown;... -
Page 34: Alarm Circuit Module (Bep1)
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit The alarm circuit module, apparatus code A-CP/BEP1, provides a means for indicating a power loss and a fuse or circuit breaker alarm for Module (BEP1) each fuse or circuit breaker panel. Indications of these alarms are by means of an LED and by contact closures. -
Page 35: Figure 2-12: A-Cp/Bep1 Board Layout
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued CR101 CR102 P102 P101 Figure 2-12: A-CP/BEP1 Board Layout Issue 5 May 2000 Product Description 2 - 21... -
Page 36: Figure 2-13: A-Cp/Bep1 Input/Output Connections (Alarm Module With No Power Is In "Normal" State)
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Panel Alarm Input Connector Remote Alarm Output Connector Pins 2 and 9 send ABS to light Frame Alarm. Alarm State P102 P101 Fuse/Circuit Breaker K101-4 Power Loss (Aud) -
Page 37: Detailed Circuit Description
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Detailed Circuit The BEP1 consists of two monitoring circuits, one for panel power loss Description and the other for fuse failures. These circuits are described as follows. -
Page 38: Figure 2-14: Frame Alarm
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Detailed Circuit In some installations, the use of a ABS lead from the battery plant may Description, not be available or desirable. An alternative alarming method continued substitutes power from a load bus for ABS. -
Page 39: Monitoring Multiple Alarm Modules For Negative Plants
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Monitoring In most distribution bay applications, customers require remote Multiple Alarm monitoring of a frame, fuse or circuit breaker alarm only and not Modules for individual load buses. Therefore, fuse or circuit breaker alarms on... -
Page 40: Figure 2-16: P101 Frame Power Loss Alarm Wiring
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Monitoring Remote monitoring of power loss is furnished for individual fuse or Multiple Alarm circuit breaker panels. However, power loss alarms will probably not be Modules for... -
Page 41: Monitoring Multiple Alarm Modules For Positive Plants
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Monitoring Opto-isolator U101 is current-direction sensitive. Therefore, remote Multiple Alarm monitoring of frame alarms for positive plants is wired differently than Modules for for negative plants. For positive plants, fuse alarms on multiple packs Positive Plants should be daisy-chained together via P101. -
Page 42: Reference Data
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Alarm Circuit Module (BEP1), continued Reference Data Input Voltage: 24V (21 to 30 Vdc), 48V (42 to 60 Vdc) Current Drain: 12 milliamps normal operation, 22 milliamps with fuse or circuit breaker alarm. -
Page 43: Safety
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Safety Safety Please read and follow all safety instructions and warnings before installing, maintaining, or repairing the power system. Reference the Statements individual module product manuals for additional safety statements specific to the modules. - Page 44 Lucent Technologies Secondary DC Power Distribution Bay H569-445 Safety Statements, continued • If the proper connector for the country of installation is not provided, obtain appropriate connectors and follow manufacturer's and all local requirements for proper connections. All national and local rules and regulations are to be followed when making field connections.
-
Page 45: Warning Statements And Safety Symbols
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Warning The symbols may sometimes be accompanied by some type of statement; e.g., “Hazardous voltage/energy inside. Risk of injury. This Statements and unit must be accessed only by qualified personnel.” Safety Symbols... - Page 46 Lucent Technologies Secondary DC Power Distribution Bay H569-445 Warning Statements and Safety Symbols, continued The symbols may sometimes be accompanied by some type of statement; e.g., “Hazardous voltage/energy inside. Risk of injury. This unit must be accessed only by qualified personnel.”...
-
Page 47: Precautions
Lucent Technologies Secondary DC Power Distribution Bay H569-445 Precautions When working on or using this type of equipment, the following precautions should be noted: • This unit must be installed, serviced, and operated only by skilled and qualified personnel who have the necessary knowledge and practical experience with electrical equipment and who understand the hazards that can arise when working on this type of equipment. - Page 49 Lucent Technologies Secondary DC Power Distribution Bay H569-445 Product Warranty A. Seller warrants to Customer only, that: 1. As of the date title to Products passes, Seller will have the right to sell, transfer, and assign such Products and the title conveyed by Seller shall be good;...
- Page 50 Lucent Technologies Secondary DC Power Distribution Bay H569-445 Warranty Period Repaired Product Product Type New Product or Part* Central Office Power 24 Months 6 Months Equipment** * The Warranty Period for a repaired Product or part thereof is as listed or, in the case of Products under Warranty, is the period listed or the unexpired term of the new Product Warranty Period, whichever is longer.
- Page 51 Lucent Technologies Secondary DC Power Distribution Bay H569-445 The transportation expense associated with returning such Product to Seller shall be borne by Customer. Seller shall pay the cost of transportation of the repair or replacing Product to the destination designated by Customer within the Territory.
