Model: EMDS4/1H/AT/MH
7351393
INSTRUCTION MANUAL
EN
LED Emergency Downlight Ares

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMDS4/1H/AT/MH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Malmbergs EMDS4/1H/AT/MH

Summary of Contents for Malmbergs EMDS4/1H/AT/MH

  • Page 1 Model: EMDS4/1H/AT/MH 7351393 INSTRUCTION MANUAL LED Emergency Downlight Ares...
  • Page 2 TECHNICAL SPECIfICATIONS 73 513 93 Art.No Max. 4W LED Power Input Voltage 230V, 50Hz Lumen Output 300lm Operation Non-maintained Function Manual and auto test 0°C - +25°C Ambient Operating Temp Charge Duration Discharge Duration NiMH, 7.2V 0.8Ah Battery IP20 Protection Class 196 mm 75 mm 196 mm...
  • Page 3 INSTALLATION Ø 42-50 mm Ceiling surface thickness 1-25 mm Wiring instruction Live 220-240VAC supply Neutral Battery male and female connector LIGHT DISTRIBUTION CURVE -165 -150 -135 -120 -105 C0/180 C90/270 (cd)
  • Page 4 AUTOMATIC TEST OPTION Once the unit is powered up it will automatically initiate a self test. The self test will check the function of the luminaire and indicate its status as follows: • Every 4 seconds: Checks for battery disconnection, charge board fault, lamp failure and transformer failure.
