- Page 1 BM20 INSTRUCTIONS MANUAL MONOBLOCK DIRECTIONAL CONTROL VALVES SOUPAPE DE COMMANDE DIRECTIONNELLE MONOBLOC BM20 UPGRADE YOUR HYDRAULIC CONTROL...
- Page 2 Installation Dimensions / Dimensions d’Installation 8669673 – 902457 ITEM BM20/1 ZB FU /MO A1/ BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL...
- Page 3 Installation Dimensions / Dimensions d’Installation 8669681 – 902458 ITEM BM20/2 ZB FU /MO A1/MO A1/ BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL...
- Page 4 Installation Dimensions / Dimensions d’Installation 8669699 – 902459 ITEM BM20/3 ZB FU /MO A1/MO A1/MO A1/ BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL...
-
Page 5: Pressure Drop
Customizable with a variety of spool and positioner options PRESSURE DROP BM20 A-T PRESSURE DROP BM20 P-A PRESSURE DROP 3 2 1 FLOW (gpm) FLOW (gpm) BM20 P-T PRESSURE DROP 1 2 3 1 2 3 FLOW (gpm) BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL... -
Page 6: Parts List
Nº Parts Parts Nº sub part Sub part Screw Relief Valve kit Check valve Kit handle Handle cup Handle cap kit Screw Seal Spool kit Spool Positioner cap Positioner kit Positioner kit Screw BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL... -
Page 7: Setting The Relief Valve
Adjustable pressure range is 1,300 PSI to 3,600 PSI. Do not backout adjusting screw to the point it falls out. BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL... - Page 8 Step 2. Take out the load Check Valve (Part. 2) and install on the relief valve plug Step 3. Screw the Relief Valve Plug into the Relief Valve port with 8 mm hex key and tighten to 44 ft. lbs. BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL...
- Page 9 This requires either a pressure relief valve in the system or a pump that has pressure compensation. • Overpressure may cause sudden and unexpected failure of a component in the hydraulic system resulting in serious personal injury, always use a gauge when adjusting a relief valve. BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL...
- Page 10 BM20 MONOBLOCK DIRECTIONAL CONTROL VALVES / INSTRUCTIONS MANUAL...
- Page 11 CHUTE DE PRESSION BM20 A-T PRESSURE DROP BM20 P-A PRESSURE DROP 3 2 1 FLOW (gpm) FLOW (gpm) BM20 P-T PRESSURE DROP 1 2 3 1 2 3 FLOW (gpm) SOUPAPE DE COMMANDE DIRECTIONNELLE MONOBLOC BM20 / MANUEL D’INSTRUCTIONS...
-
Page 12: Liste Des Pièces
PIÈCES DE RECHANGE BM20 Nº de Pièces Pièces Nº de sous-pièce Sous-pièce Kit Soupape de Sûreté Écrou Clapet anti-retour Kit Tige levier Actionnement levier Kit Porte-levier Joint Kit Bobine Bobine Porte-Positionneur Positionneur Positionneur SOUPAPE DE COMMANDE DIRECTIONNELLE MONOBLOC BM20 / MANUEL D’INSTRUCTIONS... - Page 13 La plage de pression réglable est de 1,300 à 3,600 PSI. Ne pas desserrer totalement la vis de réglage afin d’éviter qu’elle ne tombe. SOUPAPE DE COMMANDE DIRECTIONNELLE MONOBLOC BM20 / MANUEL D’INSTRUCTIONS...
- Page 14 Étape 3. Visser le Bouchon de la soupape de sûreté dans l’orifice de la Soupape de sûreté à l’aide d’une clé hexagonale de 8mm et serrer à un couple de 44 pi-lb. SOUPAPE DE COMMANDE DIRECTIONNELLE MONOBLOC BM20 / MANUEL D’INSTRUCTIONS...
- Page 15 • Une surpression peut entraîner une panne soudaine et inattendue d’un composant dans le système hydraulique et provoquer des blessures graves; toujours utiliser un manomètre lors du réglage d’une soupape de sûreté. SOUPAPE DE COMMANDE DIRECTIONNELLE MONOBLOC BM20 / MANUEL D’INSTRUCTIONS...
- Page 16 Quality management system certified according to ISO 9001: 2008 Certicate Nr 50 100 11533 BLB S.r.l. T. +39 0444 401141 F. +39 0444 401086 Via Natta, 1 36040 Brendola (VI) W. www.blbhydraulic.com Italy E. info@blbhydraulic.com...
