EDAN INSTRUMENTS iM8s Instruction

Thermal printer

深圳市理邦精密仪器有限公司

EDAN INSTRUMENTS,INC.

Instruction to Install Thermal Printer

on iM8s/iM9s

Ver. 1.0

Howard Zhao

2014/1/27

This Guidance Is Available on: iM8s/iM9s

Tel: 8 6 -755 -26899914

Fax : 86 -755 -26 8983 30

www.edan. co m.c n

Address:3/F-B,Nanshan Medical Equipments Part, Nanhai Rd 1019#, Nanshan,Shenzhen, 518067 P.R.China

Table of Contents

Need help?

Do you have a question about the iM8s and is the answer not in the manual?

Page 1 Instruction to Install Thermal Printer on iM8s/iM9s Ver. 1.0 Howard Zhao 2014/1/27 This Guidance Is Available on: iM8s/iM9s Tel: 8 6 -755 -26899914 Fax : 86 -755 -26 8983 30 www.edan. co m.c n Address:3/F-B,Nanshan Medical Equipments Part, Nanhai Rd 1019#, Nanshan,Shenzhen, 518067 P.R.China...
Page 2 深圳市理邦精密仪器有限公司 EDAN INSTRUMENTS,INC. 1 Preparation 1.1 Tools and parts participate in the installation: Thermal printer (with 2 screws attached)  Cross head screwdriver  Knife  2 Installation 2.1 You will find a thin gaps (as Fig.1 shows). Insert the knife into the gap, and pull the shell out by raising the handle of the knife.
Page 3 深圳市理邦精密仪器有限公司 EDAN INSTRUMENTS,INC. 2.2 Having opened the shell, you will see two cables inside, one is for communication and other is for power supply (as Fig.4 shows). Then connect these 2 cables to the relevant port on the printer Power Supply Port COMM Port Fig.3, Connect two cables...
Page 4 深圳市理邦精密仪器有限公司 EDAN INSTRUMENTS,INC. 2.4 Select VECTOR for RECORDER, and then reboot the M3. The procedure finishes. Fig.8, Select MODULE SETUP Fig.9, Mark RECORDER checkbox 3 Press Record button to test the printing Fig.9, Press Record button Tel: 8 6 -755 -26899914 Fax : 86 -755 -26 8983 30 www.edan.
