2. Verify the Access Point Passes the Self Test

Before mounting the access point in its network location, you should first
verify that it is working properly by plugging it into a power source, or
connecting it to a switch that provides Power over Ethernet, and verifying that
it passes its self test.
1.
10/100-TX
48V 0.38A
In
Or connect power adapter
to the power connector
N o t e
The RSVLC-0501 does not have a power switch. It is powered on when the
power adapter is connected to the access point and to a power source, or when
a network cable is connected to the access point and to a network device that
provides Power over Ethernet. For safety, when connecting to an electrical
outlet, the power outlet should be located near the access point.
Use only the AC power adapter supplied with the access point. Use of other
adapters, including adapters that came with other HP network products, may
result in damage to the equipment.
Connect a network cable from a PoE source device (such as a switch) to
the RJ-45 port on the back of the access point, or connect the supplied
power adapter to the power connector on the back of the access point,
and then into a properly grounded electrical outlet.
Console Auxiliary Port
Connect network
cable to PoE switch
2
Primary
Reset Clear
2.4 GHz or 5 GHz Antenna
(802.11a/b/g)
Installing the RSVLC-0501
Installation Procedures
1
Primary
2.4 GHz Antenna only
(802.11b/g)
2-5
