IMPORTANT KEEP FOR FUTURE REFERENCE

WARNING
• Not suitable for children under 18 months or over 5 years.
• Use only with children able to climb in and out of bed unaided.
• The bed rail should not be used as a substitute for a cot as it cannot provide
the same level of safety as a cot.
• Never use without the fixing devices firmly attached to the bed and mattress.
• This bedguard should not be used on a sleeping surface that is more than 60cm
from the floor.
• When the bed rail is fitted well it should touch the side of the mattress.
• When the bed rail is fitted well it should touch the side of the mattress.
• Not suitable for beds with recessed baseboards.
• Use only on Mattress: Width: 76-160cm / 30-63in, Depth: 10-25cm / 4-10in,

ASSEMBLY

PARTS

A 1 x Storage Bag
B 1 x Cover
C 2 x Bedrail Frames (J=Brackets)
D 2 x Linking Tubes (frame & base)
E 2 x Base Tubes
A

ASSEMBLY SUMMARY

C
E
INSTRUCTION MANUAL
Phoenix Bed Rail
Complies with Standards: BS7972-2001+A1-2009
Length: 160-200cm / 63-78.75in.
B
D
D
C
D
E
E
C
F719
F761

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phoenix Bed Rail F719 and is the answer not in the manual?

Questions and answers

Summary of Contents for dreambaby Phoenix Bed Rail F719

  • Page 1 F719 INSTRUCTION MANUAL F761 Phoenix Bed Rail Complies with Standards: BS7972-2001+A1-2009 IMPORTANT KEEP FOR FUTURE REFERENCE WARNING • Not suitable for children under 18 months or over 5 years. • Use only with children able to climb in and out of bed unaided. •...
  • Page 2 HOW TO ASSEMBLE Open brackets (J) Feed Cover onto Frame (C) Squeeze buttons in, join both Frames (C) with 1 x Linking Tube (D) Spread Cover (B) Join Base Tubes (E+D+E) using over Frame (C) remaining Linking Tube (D) Feed through bottom of Cover (B) Squeeze buttons (E) Insert securely into Brackets (J) To remove cover...
  • Page 3 INSTALLATION PARTS LIST H Straps Anchors J Brackets K Tabs L Bed rail HOW TO INSTALL 1. Pull down Brackets (J) until 2. Slide Brackets (J) under mattress. they click and lock into position. 3. Position bed rail (L) so there is a gap of at 25cm 25cm least 25cm / 10in from both ends of bed.
  • Page 4 • arising from abnormal use of the products; • caused by installation or removal of the products other than in accordance with the supplied installation and removal instructions; or • arising under the law of tort or contract. Dreambaby products by ®...

This manual is also suitable for:

Phoenix bed rail f761
