  • Page 1 USER MANUAL VERSION 1.1 September 2018 POS455 Hardware System...
  • Page 2 Copyright 2018 All Rights Reserved Manual Version 1.1 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 CE MARK This device complies with the requirements of the EEC directive 2014/30/EU with regard to “Electromagnetic compatibility” and 2014/35/EU “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 4 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
  • Page 5 Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release September 2017 • D36 V4.0 MB added September 2018 • D86S MB added...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ........1 1-1. Standard Accessories .............1 1-2. Optional Accessories ............2 2. System View ........3 2-1. Front & Side View ............3 2-2. Rear View .................3 2-3. IO Ports View..............4 2-4. System Dimensions ............5 3. System Assembly & Disassembly 6 3-1.
  • Page 7 ........ 15 ....... 17 6-1. D36 V2.1 Motherboard ..........17 6-1-1. Motherboard Layout ............17 6-1-2. Connectors & Functions ..........18 6-1-3. Jumper Setting ..............19 6-2. D36 V4.0 Motherboard ..........21 6-2-1. Motherboard Layout ............21 6-2-2. Connectors & Functions ..........22 6-2-3. Jumper Setting ..............23 6-3.
  • Page 8 The page is intentionally left blank. viii...

  • Page 9: Packing List

    Packing List 1-1. Standard Accessories a. System b. Power adapter c. Power cord d. RJ45-DB9 cable (x2) e. Driver bank Note: Power cord will be supplied differently according to various region or country.

  • Page 10: Optional Accessories

    1-2. Optional Accessories a. MSR module b. Fingerprint module c. iButton module d. Customer display e. 8.4" 2 display...

  • Page 11: System View

    System View 2-1. Front & Side View Description Fingerprint (option) Touch screen MSR (option) Power button Stand VESA bottom cover Stand front cover 2-2. Rear View Description Dummy door of the HDD VESA top cover Cable cover...

  • Page 12: Io Ports View

    2-3. IO Ports View D36 Motherboard Description Powered USB 24V (option) Powered USB 12V (option) Power button DC 19V in COM 1, 2, 3 (from right to left) USB 2.0 x 4 Cash drawer USB 3.0 x 1 D86U Motherboard g h i Description Powered USB 24V (option)

  • Page 13: System Dimensions

    D86S Motherboard a b c Description Cash drawer USB 2.0 x 2 COM 1, 2, 3 (from left to right) USB type C DC 19V in Power button USB 3.0 x 4 2-4. System Dimensions 404.89 mm 359.36 mm 105° 62°...

  • Page 14: System Assembly & Disassembly

    System Assembly & Disassembly Disassemble the Stand 3-1. 1. Slide the VESA bottom cover outwards. 2. Loosen the thumb screw (x1) and slide the stand towards the IO panel to release it from the system. 3. Reverse the steps above to attach stand to the system.

  • Page 15: Install The Power Adapter

    Install the Power Adapter 3-3. The system is equipped with a 65W or 90W power adapter. Please follow the steps to install the power adapter. 1. The stand is designed to allow for clean cable management. There is a cable channel through the stand, which has a quick access cover.

  • Page 16: Peripheral Installation

    Peripheral Installation Install the MSR Module 4-1. 2. Insert the MSR module in place and fasten the screws (x2) on the back to secure the module.

  • Page 17: Install The Fingerprint Module

    Install the Fingerprint Module 4-2. 2. Insert the Fingerprint module in place and fasten the screws (x2) on the back to secure the module.

  • Page 18: Install The Ibutton Module

    Install the iButton Module 4-3. 2. Insert the iButton module in place and fasten the screws (x2) on the back to secure the module.

  • Page 19: Install The Customer Display

    Install the Customer Display 4-4. 1. Follow the steps in Chapter 3-1 to diassemble the stand from the LCD panel. 2. Remove the thumb screw (x1) from the VESA top cover and then pull the cover up. 3. Attach the LCM module to system by fastening the thumb screw (x1). 4.

  • Page 20: Install The Second Display

    Install the Second Display 4-5. 1. Follow the steps in Chapter 3-1 to diassemble the stand from the LCD panel. 2. Remove the thumb screw (x1) from the VESA top cover and then pull the cover up. 3. Attach the 8.4"' 2 display module to system by fastening the thumb screw (x1).

  • Page 21: Cash Drawer Installation

    4-6. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal Cash drawer 2 In Cash drawer 1 Out Cash drawer 1 In 12V / 19V (or 24V) Cash drawer 2 Out Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 22 Bit 7: Reserved Bit 6: Reserved Bit 5: Reserved Bit 4: Cash Drawer 1 pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 3: Cash Drawer 1 pin input control. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 2: Reserved Bit 1: Reserved...
  • Page 23 Model Name POS455 Mainboard D86U D86S Intel SKYLAKE U CPU CPUBGA-1296 14nm Intel Skylake S Intel Bay Trail CPU BGA-1170 Celeron 3955U 2GHz, LLC 2M i7-6700 3.4G L3 8MB, 65W 22nm (15W,EIA) i5-6500 3.6G, L3 6M, 65W CPU support Intel Bay Trail CPU I3-6100U 2.3GHz, LLC 3M(15W,...
  • Page 24 Model Name POS455 Mainboard D86U D86S Customer display Flush mount LCM display 2 x 20 characters (COM) Speaker 1 or 2 x 2W Control/Indicator Power button Power LED 2(turn on: blue / turn off: Amber) EMC & Safety FCC, Class A, CE, LVD...

  • Page 25: D36 V2.1 Motherboard

    6-1. D36 V2.1 Motherboard 6-1-1. Motherboard Layout CN13 CN12 SATA1 CN14 USB2 CN24 RJ45_1 USB1 CN23 CN15 CN10 JP1 CN17 CN11 MINI_PCIE1 USB3 CN18 CN25 BAT1 CN19 DDR3_A1 CN20...

  • Page 26: Connectors & Functions

    6-1-2. Connectors & Functions Connector Function Front I/O board Inverter connector LVDS connector System FAN connector LPT port connector Speaker & MIC connector 40pin external connector CN10 HDD LED connector CN11 Power LED connector CN12 SATA power connector CN13/14 USB port (internal) CN15 PS2 keyboard connector CN17...

  • Page 27: Jumper Setting

    6-1-3. Jumper Setting Inverter Selection Function CCFL Cash Drawer Power Setting Function COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility.
  • Page 28 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1366 x 768 Single Panel LVDS 1366 x 768 Single...

  • Page 29: D36 V4.0 Motherboard

    6-2. D36 V4.0 Motherboard 6-2-1. Motherboard Layout CN34 CN32 CN13 CN12 CN33 SATA1 CN31 USB2 RJ45_1 USB1 CN7 CN1 USB3 MINI_PCIE1 BAT1 CN19 DDR3_A1 CN27 CN29...

  • Page 30: Connectors & Functions

    6-2-2. Connectors & Functions Connector Function C N 1 / C N 1 3 / C N 2 1 / Internal USB connector CN29 EC Debug CPU FAN connector LPT connector 40Pin connector CN12 SATA power connector CN18 COM5 (touch) connector CN19 Wide range power connector CN25...

  • Page 31: Jumper Setting

    6-2-3. Jumper Setting Cash Drawer Power Setting Function COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility.

  • Page 32: D86U Motherboard

    6-3. D86U Motherboard 6-3-1. Motherboard Layout SATA1 USB3 RJ45_1 SATA0 CN21 USB2 SKT1 CN19 CN22 CN15 USB1 CN23 MINI_PCIE1 CN10 CN20 SKT2 JP1 CN4 CN24 DDR3_A1 CN28 CN17 CN25...

  • Page 33: Connectors & Functions

    6-3-2. Connectors & Functions Connector Function Front I/O board HDD LED connector USB connector System FAN connector LPT port connector Smart device connector Debug port CN10 Speaker & MIC connector CN11 40 pin external connector CN12 Audio connector(right) CN13 Audio connector(left) CN14 CN15 two color LED...

  • Page 34: Jumper Setting

    6-3-3. Jumper Setting Cash Drawer Power Setting Function COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility.
  • Page 35 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1366 x 768 Single Panel LVDS 1366 x 768 Single...

  • Page 36: D86S Motherboard

    6-4. D86S Motherboard 6-4-1. Motherboard Layout DIMM_A1 CN10 CPU1 CN11 CN13 BAT1 CN16 CN15 CN12 CN22 CN21 SKT1 CN18 CN14 CN19 SKT2 CN17 CN6 CN5 SATA1...

  • Page 37: Connectors & Functions

    6-4-2. Connectors & Functions Connector Function System FAN connector eDP connector HDD power connector USB connector CN4 /8 / 12 MIC-In connector Audio connector(right) Audio black connector M.2 connector Power LED connector CN10 Audio connector(left) CN11 40 pin external connector CN13 CN14 Printer connector...

  • Page 38: Jumper Setting

    6-4-3. Jumper Setting Cash Drawer Power Setting Function COMBO Speaker Setting Function Enagle Jumper open COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility.

  • Page 39: Appendix: Drivers Installation

    Appendix: Drivers Installation and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models. You can refer to the drivers installation guide for each driver in the “Driver/ Manual List”.
