INSTALLATION
Safety notice
– Electronic vehicle systems may fail
if they are incorrectly installed or
serviced.
– Disconnect the negative terminal of
the battery before installing or
removing any equipment.
– When drilling any holes, ensure
that no vehicle components are
damaged.
1 2 V
Supplied installation materials
14
182
165
53
1-20
Recommended location for
installation
Dashboard
Vehicle trunk
glove box
center console
SUV storage bin
Installation position
From -10 to 105
Recommended accessories
Extension cable (4-feet 4-inches)
7 607 621 154
Extension cable (19-feet 6-inches)
7 607 621 155
Universal mounting frame
7 608 002 377
Spacer installation frame 6 mm
7 608 002 076
Spacer installation frame 10 mm
7 608 002 176
