superbrightleds DS-DMX23 User Manual

Important: Read all instructions prior to installation.
DMX512 to SPI Decoder / Controller
Compatible IC Settings
This controller is compatible with the following IC types:
• D705 • LPD8806
• GW6205 • MBI6120
• LPD1101 • P9813
• LPD6803 • SK6812
• LPD8803 • SK9822
Controller Layout
setting buttons
RJ45 DMX
RJ45 DMX
DMX ( - )
DMX ( + )
GND
DMX ( - )
DMX ( + )
Restore Factory Default Parameters
• Hold ◄ and ► button simultaneously for 2 seconds to display "RES".
Safety and Notes
• Product should be installed and serviced in accordance with applicable national,
• To reduce the risk of electric shock, ensure that the power source and circuit
• Strips controlled by data input only (same DATA
• Strips controlled by data and clock input (separate
• TLS3001 • TM1812
• TLS3002 • TM1814B
• TM1803 • TM1829
• TM1804 • TM1914A
• TM1809 • UCS1903
XLR3 DMX
(male)
state, and local building and electrical codes.
breakers are switched off before performing any installation or wiring procedures.
and CLK output) can connect up to six strips.
DATA and CLK output) can connect up to three strips.
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
• UCS1909
• UCS1912
• UCS2903
• UCS2909
• UCS2912
display
XLR3 DMX
(female)
Rev Date: V3 03/18/2021
4400 Earth City Expy, St. Louis, MO 63045
User Manual
DS-DMX23
• UCS6909
• UCS6912
• WS2801
• UCS8904B
• WS2803
• WS2811
• WS2812
GND
CLK3 signal output
DATA3 signal output
CLK2 signal output
DATA2 signal output
CLK1 signal output
DATA1 signal output
V+ output
power input ( - )
power input ( + )
866-590-3533 superbrightleds.com
