PLCM-E1b CNC Ethernet controller I N S T R U CT I O N M A N U A L 01. General information 02. Delivery set 03. Technical features 04. Main connectors and indicators 05. Software installation 06. Terms of Warranty... -
Page 2: General Information
• For controller power supply, direct current source is used, supply voltage is 12V. • Ethernet connector is designed for PLCM-E1b connection to local area network. The connection must be performed with cable 5 or of higher category, You can apply patch-cords with straight through or crossover crimping type. -
Page 3: Software Installation
04. Main connectors and indicators PLCM-E1b. CNC Ethernet controller • P1 Port represents LTP PC port analog and has identical assignment and location of contacts: Outputs 1, 2, 3, 4, 5, 6, 7, 8, 9, 14, 16, 17. Inputs 10, 11, 12, 13, 15. - Page 4 Fig. 7. Plug-in option Controller automatic search can disrupt local network, use this When choosing PLCM-E1b after ‘Next’ pressing, software installation function only if you do not use local network resources on the PC and wizard will offer to execute automatic setting of network adapter PC for do not use the Internet.
- Page 5 ‘failure’ in motion while rotating the picture or some other load on controlling device, this means that Windows firewall blocks access to Mach3). PLCM-E1b. You must either add MACH3 to firewall exception or disable Time of advance calculation of path of PLMach – similar buffer, firewall.
- Page 6 05. Software installation PLCM-E1b. CNC Ethernet controller Ethernet / USB STEP 48V, 70V ENABLE Fig. 9. General scheme of CNC control 8 (800) 555 63 74 www.purelogic.ru Edition from 05.06.2015...
- Page 7 Automatic address assignment installation will work with the controller setting only when there is local DHCP server in the net. In all other cases the In (C:\Mach3\Purelogic), supplied with the devise you will find set_ controller will not contact the plug-in. ip.exe file.
- Page 8 05. Software installation PLCM-E1b. CNC Ethernet controller (After pressing the button ‘install’ the application will require 2-3 minutes for introduction of changes. On ‘slow’ PC this procedure will take a little more time). If for some reason you failed to make connection to PLCM controller in automatic mode, produce setting manually.
-
Page 9: Terms Of Warranty
06. Terms of Warranty PLCM-E1b. CNC Ethernet controller 4.2. The product with traces of foreign objects or substances impact, Terms of Warranty including dust, liquids, insects, also objects having extraneous inscription. 4.3. The product with traces of unauthorized tampering and (or) repair... - Page 10 We draw your attention to the fact that there can be some changes in this instruction due to the product consistent technical improvement. You can always download our latest versions at www.purelogic.ru w w w. pure lo g i c . ru Contacts...
