- Page 1 PLCM-E4 Ethernet/USB controller of CNC machine I N S T R U CT I O N M A N U A L 01. General information 02. Delivery set 03. Technical features 04. Main connectors and indicators 05. Software installation 06. Terms of Warranty...
-
Page 2: General Information
DO NOT CONNECT POWER SUPPLY’S «-» TO GROUND, MASS, • LED17 signals about supplying current. HOUSING, ETC. • XS2 connector (fig. 2) is intended for PLCM-E4 connection to PLCM-E4. Connection is recommended to provide with cable of the IT IS RECOMMENDED TO USE HIGH QUALITY NOISE-PROOF CABLES 5th category or higher. -
Page 3: Software Installation
04. Main connectors and indicators PLCM-E4. Ethernet/USB controller of CNC machine By analogy to LPT-port, contacts 1, 2, 3, 4, 5, 6, 7, 8, 9, 14, 16, 17 are outputs, 10, 11, 12, 13, 15 are inputs, The second port is 16 optoisolated inputs. - Page 4 05. Software installation PLCM-E4. Ethernet/USB controller of CNC machine Pin number in Connect LED26 XP51 DB25 Input/output MACH3 Packet LED27 XP52 output output E-stop LED28 XP53 output Tab. 1. Controller state output output output output output MACH3 MACH3 Input Relay...
- Page 5 Fig. 3/4. Cable type setup / speed and duplex mode setup Fig. 7. Automatic network installation When choosing PLCM-E4 after ‘Next’ pressing, software installation Fig. 5. Software installation wizard wizard will offer to execute automatic setting of network adapter PC for correct connection to PLCM-E4 (fig.
- Page 6 05. Software installation PLCM-E4. Ethernet/USB controller of CNC machine Controller automatic search can disrupt local network, use this function only if you do not use local network resources on the PC and do not use the Internet. Press ‘Next’, then ‘Install’. The master will copy the necessary files and finish its work.
- Page 7 ‘C:\Mach3\ PLСM.log’. When exploring incorrect device work, this file must be sent to Purelogic R&D technical Support with the detailed problem description. To receive IP-address automatically we recommend to leave this item active, if there is a device which can dynamically assign IP-addresses (e.g.
- Page 8 05. Software installation PLCM-E4. Ethernet/USB controller of CNC machine (After pressing the button ‘install’ the application will require 2-3 minutes for introduction of changes. On ‘slow’ PC this procedure will take a little more time). If for some reason you failed to make connection to PLCM controller in automatic mode, produce setting manually.
-
Page 9: Terms Of Warranty
05. Software installation PLCM-E4. Ethernet/USB controller of CNC machine 1.3. Product’s component parts and configuration can be changed by manufacturer without notice due to the product consistent technical improvement. 2. Conditions for warranty acceptance 2.1. The product is accepted only in the same completeness of set as it was purchased. - Page 10 06. Terms of Warranty PLCM-E4. Ethernet/USB controller of CNC machine 4.7. The product which was resold by the initial buyer to the third party. 4.8. The product with defects which were caused by low-quality spare parts or fulfilled their service life spare parts,consumable materials, also using spare parts, consumable materials not corresponding with manufacturer’s requirements.
- Page 11 We draw your attention to the fact that there can be some changes in this instruction due to the product consistent technical improvement. You can always download our latest versions at www.purelogic.ru w w w. pure lo g i c . ru Contacts...
