F.I.T. PRO LED650 Manual

F.I.T. PRO LED650
Diving Backup Light
Please read carefully before using the manual
(LED Light)
Specifications
Brightness
650 lumen ( 1 * 18650 Li-ion )
(Lumen)
350 lumen ( 3 *AAA )
Beam Angle
10 Degress
(In water)
Battery 1 * 18650 Li-ion or 3 *AAA
Run time approx.90 min + 10 min
Waterproof 100m / 330ft
LED
1pcs XM-L2 U2
Parameters
LED Life Over 50000 hours
Material Aviation aluminum
Oxidation Hard anodic oxidation
Size 34 (D) x 133.3 (L) mm
3 *AAA : 170 (in air), 70g (in water)
Weight
1 * 18650 Li-ion: 175g (in air), 80 (in water)
Contents
<Instruction>
-Component
-Specifications
-Unpacking
<How to use>
-Battery Loading
-Operating Instructions
-Temperature Protection
-Battery Level Indicator
-Automatic Overheat Protection
-Charge the battery
<Maintenance and Warranty>
-Care and Maintenance
-Warning
-Standard Warranty
-Troubles Solution
Component
Light Head
Unpacking
Spot Light (1pcs)
①
④ O Ring 2pcs
Battery Loading
1. Anti-clockwise rotate to open the tail cap;
2. Loading 3*AAA batteries into the battery clamp and loading
the battery into the tail cap.(Or loading 18650 Li-ion battery
with the battery tube into the tail cap.) The polarity of the
battery must match the polarity of the contacts.
3. Holding the light head and attach the tail cap by rotating
clockwise.
2
Tail Cap
Switch Button
Diving backup light ② Battery tube
⑤
Battery Clamp
.............................................1
.............................................2
.............................................3
.............................................3
............................................ 4
.............................................5
............................................ 5
............................................ 5
............................................ 5
............................................ 6
............................................ 6
............................................ 7
............................................ 7
Battery Level Indicator
Battery clamp
③
Wrist lanyard
1
3
