Summary of Contents for F.I.T. LED PRO 5000
- Page 1 ...
-
Page 2: Specification
Content Specification Operation Instruction Specification Ⅰ. Construction ... - Page 3 1.2 Specification Brightness White: 5000Lumen; Red: 150Lumen Light Beam White: 120degrees;Red:130degrees Battery 11.1V/5200mAh Sanyo battery core lithium battery Burn time White Led around1 hour up, Red LED 10 hours up...
- Page 4 Depth Rating 100m/330ft White: CREE XM-L T6*9PCS, Color temperature: 5700K~6500K LED spec Red: CREE XP-E R2*3PCS (Red, 620nm) LED Life Over 50000 hours Materials Aircraft degree aluminium+Hard anodized Surface treatment Hard anodized Size 75.5(D)*141(L)mm Weight 561g(under water, battery included) 1190g(on land, battery ) White light step-less adjustment, white / red status indicator, Brightness level indicator, Battery status indicator, Low Function...
- Page 5 Ⅱ. Operation 2.I Assembly For Battery 2.1.1 Anticlockwise unscrew the rear cap of the video light. 2.1.2 Insert Lithium-ion battery pack into the light, both sides of the battery are the same (no electrode design). 2.1.3 Clockwise turn the rear cap back to the light. ★...
-
Page 6: Status Indicator
2.2 Turn On / Off Video Light 2.2.1 Turn on: Press combine button, the light will be turned on (Full100% white is the default). 2.2.2 Turn off: Under any turn on mode, press the combine button for 3 seconds up, the light will be turned off. - Page 7 2.5 Capacity Indicate Capacity Status Indicator >75% green 50%-75% yellow 20%-50% <20% flicking red 2.6 Brightness indicate Brightness Indicate 71%-100% 31%-70% 10%-30% 2.7 Charger Usage 2.7.1 When Lithium-ion battery pack need to be charged, please insert the DC plug into the interface of the charger kit as following, 2.7.2 Then insert the AC plug into the power socket.
-
Page 8: Temperature Protection
2.8 Temperature Protection If temperature reaches the setting value when you use the video light on land, program will decrease the brightness to 20% automatically. And will recover to its initial protected brightness automatically as soon as the temperature has been decreased. - Page 9 When you find the o-ring inside the rear cap of the video light is broken or in bad- shaped, please remove the defective one, then replace a new one. Please daub appropriate silicone grease before replacing, any sharp tool is not allowed to avoid damaging O ring.
