Table of Contents
(2)
A
(2)
B
(2)
C
(4)
D
(4)
E
(4)
F
ALLEN WRENCH
( included )
Assembly Instructions
1 - Attach part ( H ), Front Legs Assembly, to part ( G ), Seat Main Assembly , as shown in Figure 1 see
detail 1 using ( 2 ) of joint connector bolts ( A ) , ( 2 ) Lock washers ( D ) , ( 2 ) washers ( E ) and ( 2 ) hex
nuts ( F ), tighten bolts using an allen wrench and also an adjustable wrench.
( Detail 1 )
D
Hardware and Parts
3.50
2.75
2.75
I
(Right Arm
Assembly)
( Front Legs Assembly )
WRENCH
( not included )
Figure 1
( Front Legs Assembly )
H
A
E
F
Assembly Instructions
Item No: MHYA-F
Hyannis Folding Adirondack
( Seat Main Assembly )
G
H
Do not use
any hand drill
on this product
G
( Seat Main Assembly )
J
(Left Arm
Assembly)
Advertisement
Table of Contents
Related Manuals for Sister Bay MHYA-F
Summary of Contents for Sister Bay MHYA-F
- Page 1 Assembly Instructions Item No: MHYA-F Hyannis Folding Adirondack Hardware and Parts 3.50 ( Seat Main Assembly ) 2.75 2.75 (Right Arm (Left Arm Assembly) Assembly) ( Front Legs Assembly ) Do not use any hand drill WRENCH on this product...
- Page 2 To clean your product, use mild soap and water. For heavy soil build-ups use any non-abrasive household cleaners or ask your Sales Representative about Sister Bay Furniture Cleaner. Please contact our Customer Service Department for assembly assistance, questions or replacement parts at 1-866-947-7632...
