*Always follow manufacturer instructions* & & Mini QUICK POWER SCAPE™ Soil Conditioner Mini Skid Steer Loaders Mini Track Loaders Read this Manual Before Use *AAA Rent-All 225-291-1356*...
Page 2
YOUR ATTACHMENTS DEALER ADDRESS: PHONE: CONTACT: NOTE: Quick Attach Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold.
Page 3
Indicates potentially Quick Attach Attachments LLC cannot anticipate hazardous situation which, if not avoided, every possible circumstance that might involve will result in death or serious injury.
Page 4
Keep all shields, guards, and covers in place. penetrate the skin causing serious injury. Do not modify equipment or add attachments that Avoid the hazard by relieving the are not approved by Quick Attach Attachments LLC. pressure before disconnecting hydraulic lines.
Page 5
*Always follow manufacturer instructions* SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation.
Page 6
The locations of the safety decals are shown. Part Number: 200001 If these decals are missing, damaged, or Location: On left top of main frame painted over they must be replaced. Call Quick Attach Attachments LLC (320-759- Quantity: 1551) for replacement decals. *AAA Rent-All 225-291-1356*...
Page 7
2. Sitting in the operator’s seat, lower seat bar and fasten the seat belt and with the 2. Drive the loader to the rear of the controls in a neutral position, start the attachment. Put the loader quick attach engine. coupler into the attachment mounting bracket.
Page 8
*Always follow manufacturer instructions* USER’S INSTRUCTIONS FOR MOUNTING THE MINI SOIL CONDITIONER_ Attaching Hydraulics: 1. Connect the hydraulic quick couplers from the attachment to the loader. Be sure to thread the hoses through the hose holder on the loader. Bungee straps can be used as an alternate method of securing the hoses.
Page 9
*Always follow manufacturer instructions* OPERATING THE MINI SOIL CONDITIONER Getting started 1. If the soil is very hard or compacted, break up the ground before using this attachment. 2. Before starting work in an area, be sure to survey the entire area carefully so that there aren’t any obstructions that may interfere with the operation or damage the attachment.
Page 10
*Always follow manufacturer instructions* OPERATING THE MINI SOIL CONDITIONER____________ Normal operation IMPORTANT: Always operate the attachment with the loader arms fully lowered. (see diagramsbelow) 1. Position the loader where the work is to be done. CORRECT LOADER ARM POSITION 2. Fully lower the loader’s arms, engage the hydraulic drive with the throttle set at idle.
Page 11
*Always follow manufacturer instructions* OPERATING THE MINI SOIL CONDITIONER Clearing Usually, clearing an area of rocks is the final operation, except for areas that have abundant rocks. When clearing rocks, it is necessary to set the Mini Soil Conditioner at a very shallow depth, just touching the soil.
Page 12
*Always follow manufacturer instructions* ROUTINE MINI SOIL CONDITIONERMAINTENANCE_______ Lower the attachment to rest on the skid shoes and rear roller, shut down the engine, relieve the hydraulic pressure to the attachment, wait for all motion to stop, and set park brake before leaving the operator’s seat to perform service of any kind.
Page 13
*Always follow manufacturer instructions* ROUTINE MINI SOIL CONDITIONER MAINTENANCE Lubrication (continued) Grease both lower float arm pivot bushings after every 8 hours of operation. Grease the rotor bearing after every 8 hours of operation. Grease the wheel bearings after every 4 hours of operation.
Page 14
*Always follow manufacturer instructions* SET UP ASSEMBLY OF THE MINI SOIL CONDITIONER The mini soil conditioner is shipped with the caster wheel arms in the raised position. To place them in the “working” position, remove the bolt from hole A and lower wheel arm fully.
Page 15
*Always follow manufacturer instructions* SET UP ASSEMBLY OF THE GENERIC CONTROL HANDLE HARNESS Mounting the generic control handle wire harness will vary from loader to loader. Use these instructions as a general guide. You may need to drill holes to mount pieces of this harness. Mounting hardware is not included.
Page 16
*Always follow manufacturer instructions* MINI SOIL CONDITIONER PARTS INFORMATION__________ *AAA Rent-All 225-291-1356*...
Page 17
*Always follow manufacturer instructions* MINI SOIL CONDITIONER PARTS INFORMATION__________ ITEM PART NO. DESCRIPTION STOCK NUMBER 400201 DRUM W/A 48 400200 MOTOR MOUNTW/A 400203 MAIN FRAME 48 W/A 400204 TIRE ARM W/A 400205 TIRE SPINDLE W/A 400000 MOUNTFRAME TORO MINI W/A OPTIONAL MOUNTPACKAGE 400001 MOUNTFRAME ASV MINI W/A...
Page 18
*Always follow manufacturer instructions* MINI SOIL CONDITIONER PARTS INFORMATION__________ Manual Option Hydraulic Option *AAA Rent-All 225-291-1356*...
Page 19
*Always follow manufacturer instructions* MINI SOIL CONDITIONER PARTS INFORMATION__________ MANUAL OPTION PART ITEM NUMBER DESCRIPTION STOCK NUMBER 400287 HOSE 1/2X32 10MB-10FJX 400288 HOSE 1/2X80 10FJX-8FJX 400289 HOSE 1/2X112 10MB-8FJX 200170 MOTOR 300214 ADPT NIPPLE 10MJ-10MJ HYDRAULIC OPTION PART ITEM NUMBER DESCRIPTION STOCK NUMBER 400287...
Page 20
*Always follow manufacturer instructions* WIRE HARNESS PARTS INFORMATION______________ REF. PART NO. DESCRIPTION QTY. PKG WIRE HRN GENERIC MINI ………………………………. 1 300248 HRN WIRE LOWER MINI ……………………………………….. 1 300244 CONN 4-WAY TRAILER MALE ………………………………… 1 200083 CONN 4-WAY TRAILER FEMALE ……………………………... 1 200079 HRN WIRE UPPER MINI ………………………………………...
Page 21
*Always follow manufacturer instructions* MINI SOIL CONDITIONER GENERAL SPECIFICATIONS Model Mini Soil Conditioner 48”/43.5” Working Width/Fully Angled 19” Overall Height 50” Overall Length Angling 25° right and left Hydraulic Angling Optional Teeth 54 Carbide tipped 9 – 15 GPM Recommended Hydraulic Flow Operating Weight 470 pounds All dimensions are in INCHES.
Page 23
*Always follow manufacturer instructions* LIMITED WARRANTY Quick Attach Attachments, LLC warrants each new machine manufactured by us to be free from defects in material and workmanship for a period of twelve (12) months from date of delivery to the original purchaser.
