Jeep Wrangler
i407-WRA-JK
Restyle Installation Manual
˜ Model: Wrangler JK
˜ Model Year: 2007-2018
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Warning: Before you begin wiring, remove the ground wire from the negative
terminal of the battery. Failing to do so can lead to electric shock, injury or damage
to equipment.
Introduction
˜ Congratulations on purchasing the i407-WRA-JK. This installation manual is designed to take you through the
step-by-step installation of the i407-WRA-JK into a 2007-2018 Jeep Wrangler JK. Please familiarize yourself
with the owners manual and if you still have additional questions please call 1-800-TECH-101.
Note:
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. We recommend that you have the
product installed by an Alpine authorized dealer.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly is
Warning
expected to lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly is only
Caution
expected to lead to injury or property damage.
i407-WRA-JK
Model
Jeep
Wrangler JK
Jeep Wrangler
20210811v1
˜ 1/18
Year
2007-2018
Advertisement
Table of Contents
Related Manuals for Alpine i407-WRA-JK
Summary of Contents for Alpine i407-WRA-JK
- Page 1 ˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as a result of failure to follow the instructions in the manuals.
- Page 2 The installation and wiring of this product re- wheel, gear shift, or the like; or pose a threat quires specialized skills and experience. Have to passengers. Doing so could lead to an ac- the product installed by an Alpine authorized cident or injury. dealer.
-
Page 3: Tools Required
Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 3/18 Tools Required Panel Removing Tool 7mm Sockets #2 Phillips Screwdriver Wire Cutters Extension Ratchet T20 Torx Digital Multimeter Air Saw Wire Strippers Pliers... -
Page 4: Accessory List
Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 4/18 Accessory List Head Unit Box Parts (i407-WRA) iLX-407 Head Unit Round Head Screws M5#8 (4pcs) Video In/Out Harness Camera/Preout Harness Side Mounting Brackets L&R Documents OM QR Card Alpine Installation Registration Card Manual Aux Power Pig Tail... - Page 5 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 5/18 Programming the iDatalink Maestro Module INSTALL THE WEBLINK PLUG-IN REGISTER A WEBLINK ACCOUNT Go to: Go to: idatalinkmaestro.com/plugin and follow the installation steps. The idatalinkmaestro.com/register and complete the registration process. Maestro module must be programmed specifically for each vehicle A confirmation email will be sent to you requiring validation.
- Page 6 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 6/18 Factory Unit Disassembly Process (2007-2010 Only) Release 2 clips on the top of the bottom panel. This DISCONNECT THE BATTERY BEFORE CONTINUING. FAILURE TO DO SO WILL will expose two 7mm screws. Remove those.
- Page 7 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 7/18 Factory Unit Disassembly Process (2011-2017 Only) Remove the knee cover panel and extract (2) 7mm DISCONNECT THE BATTERY BEFORE CONTINUING. FAILURE TO DO SO WILL screws located to the right and left sides of the steering wheel column.
-
Page 8: Installation Instructions
Mount the i407-WRA-JK head unit using the factory 7mm screws and return factory panels to their corresponding place... - Page 9 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 9/18 Disconnecting the Uconnect® (only for 2011-2017 vehicles with factory Uconnect®) Remove the factory climate control panel. It is Disconnect the 24pin OEM connector. clipped on and can be removed with a panel removing tool. Extract the (2) 7mm bolts from Uconnect®...
- Page 10 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 10/18 i407-WRA-JK Wiring Diagram AMPLIFIED VEHICLES To Vehicle Connectors WARNING! Antenna Power/Speaker To OBDII Connector Adapter 16-pin Green Connector Failure to follow this procedure will result in no audio from Navigation and Bluetooth sources. Aux Input Cable...
-
Page 11: Component Locations
Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 11/18 Component Locations IMPORTANT: These would be the typical locations used to install the separate components. The Maestro module and SiriusXM tuner (sold separately) would not have restrictions and could be moved based on the installers discretion. - Page 12 Apple. Third party adapters may not work i407-WRA-JK HDMI Usage With An Android Phone Do not use the head unit’s USB to power HDMI devices. This port is meant for Apple CarPlay, Android Auto, and USB ash drives.
- Page 13 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 13/18 i407-WRA-JK Wire Descriptions Vehicle Antenna CAN Interface Connector (included) To Interface Box USB extension cable (included) To USB ash drive, iPhone or Android smartphone Microphone (included) VIDEO IN To drive recorder, DVD player, etc.
- Page 14 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 14/18 Wire Harness Pin Outs Radio I/O Radio Main CAN I/F Blue 22AWG Red 22AWG 9 10 Blue 22AWG Red 20AWG 9 10 Black 22AWG Blue/White 22AWG White 22AWG Orange/White 22AWG Blue/White 22AWG Yellow/Blue 22AWG...
- Page 15 6-pin Black Connector CAMERA/PRE OUT POWER WARNING! The use of this connection This connection goes to Rear Camera is intended for Alpine the camera connector on Input HCE-TCAM1-WRA rear the main harness. This view camera ONLY. handles the power, ground, reverse light, and illumination connections.
- Page 16 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 16/18 Adding The KTA-450 (Sold Separately) (2011-2017 Only) To make room for the KTA-450 the tabs on the OEM rear support bracket need to be bent outward about 1/2” as shown in the pictures below. This will help support the rear and amplifier. A protective tape or heat shrink needs to be used so the metal does not cause damage to the amplifier.
-
Page 17: Troubleshooting Guide
˜ 17/18 Set Up Guide Turn the vehicle’s Ignition switch to ACC. Turn ON the i407-WRA-JK by pressing any key. With the vehicle parked, engage the parking brake, release the parking brake and engage the parking brake again. If a rear camera is present, turn it ON in the settings menu. (HOME/SETTINGS/CAMERA/REAR CAMERA/ CAMERA SELECT/REAR/OK). - Page 18 Jeep Wrangler i407-WRA-JK 20210811v1 ˜ 18/18 Troubleshooting Guide Continued Symptom Possible Cause Remedy One of the power wires does not Test the power wires with a digital multimeter have proper voltage and trace from there. 4 pin Maestro data cable is Check for proper connection or disconnected or damaged.
