Headset jack
USB port
Send key
Make a phone call
Symbol key
Open the symbol list
Alt key
Type the alternate
character on a key
Next key
Move through a list
How do I navigate?
Roll the trackwheel
and highlight items on the screen.
Click (press) the trackwheel
the menu or select items.
Press the Escape button
screen, cancel an action, or go back one
page in the browser.
Power button
Notification LED
to move the cursor
to open
to exit a
BlackBerry 7100t™
Getting Started Guide
Trackwheel
Select or click an item
Escape button
Exit a screen
Convenience key
Open a list of useful links
Open a selected link
End key
End a phone call
Backspace key
Enter key
Shift key
Type a capital letter
How do I type?
To type using SureType™
letter key only once until you have typed an entire
word. The letters on the screen change
automatically until a word is formed.
To switch to the multi-tap input
field, hold the * key. Press a key once for the first
letter and twice for the second letter.
technology, press each
method, in a text

Advertisement

Table of Contents
loading

Summary of Contents for Blackberry 7100t

  • Page 1 Click (press) the trackwheel the menu or select items. Press the Escape button screen, cancel an action, or go back one page in the browser. BlackBerry 7100t™ Getting Started Guide Notification LED How do I type? to move the cursor To type using SureType™...
  • Page 2 Tips Phone Open the phone screen or Press make a phone call End a call Press Turn mute on and off Press during a call Change the volume Roll the trackwheel during a call Dial a letter in a phone Hold number (once for the first letter,...
  • Page 3: Typing And Editing

    Navigating your handheld Lock the Hold handheld/keyboard (set a password for added security) Unlock the Press handheld/keyboard Double-click the trackwheel Roll the trackwheel or Press Move the cursor Return to the previous Press the Escape button screen Return to the Home screen Press Click an item Highlight the item >...
  • Page 4: Make A Phone Call

    How do I... Make a phone call 1. On the Home screen, type a phone number. 2. Press the Send key. 3. To end the call, press the End key. Send an email message 1. In the messages list, click the trackwheel. 2.
  • Page 5: Table Of Contents

    On any Help screen, click the trackwheel. Click • Index to see a list of additional help topics. In the BlackBerry Desktop Software On the Help menu, click Desktop Help • Handheld User Guide Contents to view the...
  • Page 6: Setting Up Your Handheld

    Press the battery cover release button. Slide off the battery cover. If the battery is inserted, remove it. Remove your SIM card from its packaging. Hold the SIM card with the metal contacts facing down so that the notches on the card align with the notches in the SIM card holder on your handheld.
  • Page 7: Charge The Battery

    USB hub, the hub must be self powered. Windows®98, Windows ME, Windows 2000, • or Windows XP BlackBerry Desktop Software or BlackBerry • Handheld Manager must be installed to obtain the required USB driver on your computer. See “Setting up for email” on page 5 for more information.
  • Page 8 When your SIM card is inserted and the battery is charged, turn on the radio in a wireless coverage area. See the inside front cover of this guide for information on wireless coverage levels and the wireless radio.
  • Page 9: Setting Up For Email

    Click Activate. Note: Your system administrator might request that you install the BlackBerry Handheld Manager program on your computer to reduce the amount of data that is transmitted over the wireless network when your handheld is connected to your computer.
  • Page 10: Frequently Asked Questions

    If your handheld does not connect, open the BlackBerry Desktop Software. Click Options > Connection Settings. In the drop-down list, click the correct port.
  • Page 11 When you are prompted to generate an • encryption key, follow the on-screen instructions. Your computer must be on and the BlackBerry Desktop Redirector must be running to send and receive messages on your handheld. How do I reset my handheld?
  • Page 12 ©2005 Research In Motion Limited. All Rights Reserved. The BlackBerry and RIM families of related marks, images, and symbols are the exclusive properties of, and trademarks of, Research In Motion Limited (RIM). All other brands and marks are the properties of their respective owners. IBM, Lotus, Domino, and Lotus Notes are trademarks of International Business Machines Corporation in the United States, other countries, or both.
