This way of FW upgrade/restoration allows force upgrade, even in case of mismatch of the device
article and FW file version. Please mind the original article when performing the update. It could be found
on a back cover of the device as well as on its package box (see pics below)
Model name on a back cover
The upgrade procedure contains of 2 stages:
– USB RK282x driver installation (should be installed just once, at 1st connection)
– FW update
1 Please, unpack the PMP3084B FW update utility you PC.
Make sure the PMP3084B is completely switched off and NOT connected to USB.
2
FIRMWARE UPDATE INSTRUCTION
(utility ver. 1.23)

DRIVER INSTALLATION

PMP3084B
Model name on a package box
Press a PAGE DOWN button (#1, marked with
red on a picture)
Keep the button pressed and connect the device
to the PC
Release the PAGE DOWN button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiPad PMP3084B and is the answer not in the manual?

Questions and answers

Related Manuals for Prestigio MultiPad PMP3084B

Summary of Contents for Prestigio MultiPad PMP3084B

  • Page 1 PMP3084B FIRMWARE UPDATE INSTRUCTION (utility ver. 1.23) This way of FW upgrade/restoration allows force upgrade, even in case of mismatch of the device article and FW file version. Please mind the original article when performing the update. It could be found on a back cover of the device as well as on its package box (see pics below) Model name on a back cover Model name on a package box...
  • Page 2 PMP3084B The system will report a new device and offer to install the driver for this one. IF there is no NEW DEVICE FOUND notification – pls check the Device Manager for a new device(Scan for Hardware Changes could help ) right-click on the RK281X Device, select Update Driver Software) The set of available drivers could be found in...
  • Page 3 Please refer to MID Business Development Manager for newest FW file for production/rework operations. Actual FW for warranty service use is available at http://service.prestigio.com/TABLET/PMP3084/FIRMWARE/ Please connect the PMP3084B to USB AS DESCRIBED IN CHAPTER 2 OF DRIVER INSTALLATION OPERATION: switch off the PMP3084B, press the Page Down button, connect USB cable.
  • Page 4 PMP3084B The respective box at Device Upgrade Area will have GREEN color. This mean the device is connected properly and is ready for FW update. NOTE: The possible solutions for the situation that no GREEN box appears are: - re-install the RK281x driver, - connect the device to another USB port - check the USB cable and replace it if necessary...
  • Page 5 PMP3084B Press Upgrade button The upgrade process starts. Do not disconnect the USB cable during the upgrade process As soon as the FW re-flash process will be over the box in Device Upgrade Area will be GREY Log will state that Upgrade is over. As soon as this operation is over the PER3084B will restart automatically...
  • Page 6 PMP3084B After the restart the device will re-format the DATA and CACHE partitions, it will take about 3-5 minutes After the initial touchscreen calibration, locale selection and setup the update process is finished...
