- Page 1 PERMACONN PM45-3G Install Manual Radio Data Comms Unit 5/20 - 30 Stubbs Street Silverwater NSW 2128 Telephone: 61 2 9352 1777 Facsimile: 61 2 9352 1700...
- Page 2 Introduction The Permaconn system provides two-way communication between supervised premises and the Monitoring Centre. The Permaconn PM45 is a versatile state of the art microprocessor based 3G and IP security communicator. This unit can interface with a range of alarm panels using RS232 and Contact ID.
-
Page 3: Installation Procedure
Atlas Web Platform Atlas is a secure web portal that enables users to activate and interrogate their Permaconn 3G/IP communicators remotely for diagnostic and control purposes. This portal can be accessed via the web using any Smartphone, Tablet or PC. We strongly recommend using this application to verify your install. - Page 4 Four digit Panel ID number 8 digit telephone number When an event is sent from the alarm panel the ‘CID’ LED will be [Green-Steady on]. Ping the communicator using Atlas to verify status of installation. Permaconn PM45- 3G V3 August 2014 Version 1.0...
-
Page 5: Antenna Installation
Apply DC power and depress reset button for: o 5 seconds to reset 3G settings. o 10 seconds to reset IP configuration. LEDS will all flash together for four (4) seconds to confirm successful default. Permaconn PM45- 3G V3 August 2014 Version 1.0... - Page 6 Ensure there is a common negative between PM45 and the device being switched. The outputs can be Opened, Closed or Pulsed remotely using the Permaconn Atlas web portal. Compatible with ‘Pocket Secure’ remote arming App, available on iTunes and Google Play.
- Page 7 Before you start you need the following: Laptop Network cable IP configuration program - ‘IP Setup.exe’ (available from www.permaconn.com) To connect to the PM45: Connect the PM45 to the PC (or in the same LAN with standard Ethernet cable). Run the program ‘IpSetup.exe’.
- Page 8 You can use any port above 10000, not critical. Remote Port [55300] This must match the ‘listen’ port of the Permaconn server, the default should be correct for your country. This port is vital - if incorrect the unit will not be able to connect.
-
Page 9: Contact Id Reporting Codes
Dialler Interface Lead Fail – Issue with dialler lead between Permaconn communicator and the Alarm Panel. Permaconn Communicator - IP path poll fail. Permaconn Communicator – Cellular network path poll fail. Permaconn Communicator – Communicator is offline. Auxiliary 1 – Auxiliary input alarm on communicator. - Page 10 3 x Open Collector output @ 50mA (max) Function control using Atlas web portal and/or ‘Pocket Secure’ Ethernet interface using ‘IpSetup’ program Static IP Network Configuration Atlas web portal using cellular 3G connection Approvals EN301489, EN301908, EN62311, EN60950-1 Permaconn PM45- 3G V3 August 2014 Version 1.0...
- Page 11 Liability ANY LIABILITY FOR CONSEQUENTIAL AND INCIDENTAL DAMAGES IS EXPRESSLY DISCLAIMED. RADIO DATA COMMS AND PERMACONN LIABILITY IN ALL EVENTS IS LIMITED TO, AND SHALL NOT EXCEED, THE PURCHASE PRICE PAID. While every effort has been taken to ensure the accuracy of this document, Radio Data Comms assumes no responsibility or liability for any errors or omissions.
