Menlo Systems FPD510 Operating Manual

Product Specifications

Optical Input
Supply Voltage
Current Consumption
Max. Incident Power
Operating Temperature
Spectral Range
Fiber Connector
Frequency Range
3dB-Bandwidth
Am Klopferspitz 19, 82152 Martinsried, Germany
Phone +49 89 189166-0, Fax +49 89 189166-11
http://www.menlosystems.de
FPD510 Operating Manual
Fiber coupled High Sensitivity PIN Photo Detector Unit
SMF28, FC/APC
+8 to +15 V
50 mA
10 mW
10-40 °C
850-1650 nm
FC/APC
0-250 MHz
0-200 MHz
1
0, 8
0, 6
0, 4
0, 2
0
800 1000
(850-1650 nm)
Rise Time
Gain
Dark State Noise Level
NEP (calculated)
Output Connector
Output Impedance
Device Dimensions (mm)
Output Coupling
1200 1400
Wavelengt h (nm)
05.11.2008
Page 1/2
2 ns
4x10 V/W
4
-120 dBm
(5-200 MHz)
-80 dBm
(0-5 MHz)
3 pW/Hz
1/2
SMA
50 Ω
60x50x27
DC
1600 1800
