- Page 1 VIESMANN Operating instructions for the system user ViCare climate sensor ViCare wireless repeater ViCare climate sensor ViCare wireless repeater Please keep safe. 6155211 GB 2/2020...
- Page 2 Safety instructions Safety instructions Please follow these safety instruc- tions closely to prevent accidents and material losses. Safety instructions explained Danger Note This symbol warns against the risk Details identified by the word "Note" of injury. contain additional information. Please note This symbol warns against the risk of material losses and environmen- tal pollution.
- Page 3 Safety instructions Safety instructions (cont.) Danger Damaged equipment poses a safety hazard. Check the appliance for external damage. Never start up a damaged appliance. Auxiliary components and individual parts For replacement, use only spare parts supplied or approved by Viessmann.
-
Page 4: Table Of Contents
Intended use ..................Product information ................Spare parts lists .................. ■ Data connections with ViCare climate sensor ........Data connections with ViCare wireless repeater ........3. Preparing for installation Installation location for ViCare climate sensor ........Wireless signal range ................. -
Page 5: Operational Reliability
Safety and liability Operational reliability The ViCare climate sensor has ventilation slots in the bottom left corner to measure temperature and humid- ity. Do not cover these ventilation slots. Liability No liability is accepted for loss of profit, unattained The Viessmann General Terms and Conditions apply,... -
Page 6: Disposal Of Packaging
Note tions for connections and hook-ups. The device is intended exclusively for domestic or The ViCare climate sensor is only for use with a Viess- semi-domestic use, i.e. even users who have not had mann gateway, e.g. Vitoconnect, type OPTO2. -
Page 7: Product Information
If you want to use the device as a ViCare wireless repeater, you have to operate it with the plug-in power If you want to use the device as a ViCare climate sen- supply unit provided. sor, you have operate it with batteries. The ViCare cli-... -
Page 8: Data Connections With Vicare Wireless Repeater
Introductory information Data connections with ViCare climate sensor (cont.) Note Please note that the compatibility of iOS and Android devices changes over time. It is essential to keep mobile devices updated and even to replace them if necessary. Further information can be found on the internet at www.vicare.info... -
Page 9: Installation Location For Vicare Climate Sensor
Note ■ ■ The installation location must be dry and free of frost. ■ Check the reception quality of the ViCare climate ■ Distance to floor: Min. 1.5 m sensor at the planned installation location. ■ Not near windows or doors ■... -
Page 10: Vicare Wireless Repeater
Installation location for ViCare climate sensor (cont.) ViCare wireless repeater If there are problems with the range of the wireless sig- nal in low power radio, a further device can be used as a ViCare wireless repeater: See page 11. -
Page 11: Device As Vicare Climate Sensor
(with plug-in power supply unit), you first have to reset it to the factory setting. See page 14. Then pair again with the ViCare app. See page 13. Fig. 5 Battery 3 V CR2450... -
Page 12: Mounting The Appliance On The Wall
Installation sequence Device as ViCare wireless repeater (cont.) Fig. 6 Micro USB port for plug-in power supply unit (5 V ) 1. Remove the battery. Note If you are using the device with a plug-in power supply 2. Insert the micro USB connector into the device and unit, remove the battery. -
Page 13: Display And Controls
If pairing was successful, the status LED shows green for about 5 seconds. The ViCare app dis- 4. Scan QR code on the ViCare climate sensor. plays the successful connection. 6. Put the ViCare climate sensor back on the wall. -
Page 14: Displaying The Battery Level
Note Note The battery level display only works if the ViCare cli- You can also see the battery level of the ViCare cli- mate sensor has been paired. mate sensor in the ViCare app. Transmitting current temperature and humidity values Briefly press operating button (<... -
Page 15: Software Update
Viessmann gateway and the device is updated. The functionality of the device is not interrupted by the update process. Cleaning You can clean the surfaces of the ViCare climate sen- sor with a microfibre cloth. Do not use any cleaning agents. Maintenance/battery replacement The ViCare climate sensor is maintenance-free. - Page 16 Specification Specification ViCare climate sensor Power supply Battery: 1 x 3.0 V CR2450 (button cell) Power consumption 0.5 W Max. transmitting power 0.1 W (e.i.r.p.) IP rating IP 20D to EN 60529; ensure through design/installation. Protection class Low power radio Radio frequency 2.4 GHz...
-
Page 17: Final Decommissioning And Disposal Of The Heating System
Appendix Final decommissioning and disposal of the heating system Viessmann products can be recycled. Components and fluids from your heating system do not belong in ordinary domestic waste. Please speak to your contractor about the correct dis- posal of your old system. - Page 18 Data connections............. 7, 8 Display............... 13 Software update............15 Specification – Plug-in power supply unit........16 Email................5 – ViCare climate sensor..........16 – ViCare wireless repeater.........16 Factory settings, restoring..........14 Terms and Conditions..........5 General Terms and Conditions........5 Update................15 Information..............7 Installation location............9...
- Page 20 Viessmann Werke GmbH & Co. KG Viessmann Limited D-35107 Allendorf Hortonwood 30, Telford Telephone: +49 6452 70-0 Shropshire, TF1 7YP, GB Fax: +49 6452 70-2780 Telephone: +44 1952 675000 www.viessmann.com Fax: +44 1952 675040 E-mail: info-uk@viessmann.com...
