Mylek MYHH0406C Instruction Manual

Aluminum ceramic heater
Hide thumbs Also See for MYHH0406C:

Advertisement

Table of Contents

Aluminum ceramic heater
INSTRUCTION MANUAL
Model: MYHH0406C & MYHH0410C & MYHH0415C & MYHH0420C
BEFORE USE:
Please read the instructions carefully. You must inspect the appliance including its
cable and plug for any signs of damage. If the product is damaged, DO NOT USE
and contact your supplier immediately for refund or replacement.
This product is only suitable for well insulated spaces or occasional use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MYHH0406C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mylek MYHH0406C

Summary of Contents for Mylek MYHH0406C

  • Page 1 Aluminum ceramic heater INSTRUCTION MANUAL Model: MYHH0406C & MYHH0410C & MYHH0415C & MYHH0420C BEFORE USE: Please read the instructions carefully. You must inspect the appliance including its cable and plug for any signs of damage. If the product is damaged, DO NOT USE and contact your supplier immediately for refund or replacement.

  • Page 2: Safety Instructions

    Introduction: General Information: Please read the entire instruction manual before using the product and then save it for future reference. We reserve the right for any errors in text or images and any necessary changes made to technical data. If you have any questions concerning technical problems or programming of this unit please contact our dedicated Customer Services on 0800 091 3171 or email: sales@hygienesuppliesdirect.com...
  • Page 3 • Children of less than 3 years should be kept away unless continuously supervised. • Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended, normal operating position and that they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • Fixed heaters are to be installed so that switches and other controls cannot be touched by a person in the bath or shower. • WARNING: In order to avoid overheating, do not cover the heater. Warning: When installed in a bathroom this product should be installed in volume 2 according to the national wiring rules and installed by a qualified electrician.

  • Page 5: Model Specifications

    MODEL SPECIFICATIONS Model No. FINS RATED VOLTAGE RATED POWER MYHH0406C AC220-240V, 50-60Hz 600W MYHH0410C AC220-240V, 50-60Hz 1000W MYHH0415C AC220-240V, 50-60Hz 1500W AC220-240V, 50-60Hz 2000W MYHH0420C STRUCTURE AND PARTS Out-let LCD Screen Side cover Control panel Body Power switch (Back side)
  • Page 6 Picture 4 Drill holes on the wall according to the instructions below using a 10mm drill bit, please make sure you drill the correct measurements to your model number shown below. Model 240 200 MYHH0406C 240 300 MYHH0410C 240 400 MYHH0415C...
  • Page 7 If not wall-mounting, please assemble the feet to the heater as shown above. 1) Control panel and screen. Screen Select mode or program Power on / Stand by Temperature + / Timer + Open-window on/off Temperature - / Timer - Setting / OK Buttons Explained: Power on / stand by...

  • Page 8: Quick Start (Basic Operation)

    2) Quick start (basic operation): Press to turn on the screen, the unit will work under COMFORT mode , press to set the desired temperature, symbol will show when the unit is in heating mode and turn off when the set temperature is reached. 3) Clock setting: Before setting the program, the clock will require setting before using the P1/P2/P3 programs, only when the clock is set can the programs work correctly.

  • Page 9: Program Settings

    5) Screen Child Safety lock Please note, during any programming, if the unit controls are not used for 1 minute, the unit display will dim and go into child lock mode. To unlock simply follow the instruction below. Press together to unlock the control panel. 6) Program Settings The unit has three programs which can be modified according to your requirements.
  • Page 10 • Press until the program is displayed, then press once to modify the program. • and the first hour bar and modes start to flash. • Press to choose the mode you require for this hour either • Once the mode is selected press to move to the next hour or if you wish to move back to the previous hour to change your mode.
  • Page 11 • and the first hour bar and modes start to flash and days are displayed. • Press to choose the mode you require for this hour either • Once the mode is selected press the to move to the next hour or if you wish to move back to the previous hour.
  • Page 12 Setting program This program lets you set the time and mode for each individual day Monday – Sunday and is usually the user preferred program. Monday Saturday • Press until the program is displayed, then press once to modify the program. •...

  • Page 13: Maintenance

    8) Open Window Detection Function: Press to turn on/off the windows function. When the logo displays on the screen, it means window function is active. When the function is active, a drop in temperature by 2ºC in less than 2 minutes means the heater detects a open window and will stop working and the window logo will flash.
  • Page 14 Information requirements for electric local space heaters Model identifier(s): MYHH0406C Item Symbol Value Unit Item Unit Heat output Type of heat input, for electric storage local space heaters only (select one) Nominal heat output 0.60 Manual heat charge control, with integrated...
  • Page 15 Information requirements for electric local space heaters Model identifier(s): MYHH0415C Item Symbol Value Unit Item Unit Heat output Type of heat input, for electric storage local space heaters only (select one) Nominal heat output 1.50 Manual heat charge control, with integrated [no] thermostat Minimum heat output...

  • Page 16: Service / Warranty

    SERVICE WARRANTY Hygiene Supplies Direct guarantees the product free from defects in materials and workmanship for a period of 1 year from date of purchase. Should this unit be operated under conditions other than those recommended, at voltages other than the voltage indicated on the unit, or any attempts made to service or modify the unit, then the warranty will be rendered void.

This manual is also suitable for:

Myhh0410cMyhh0415cMyhh0420c
