215-1573 Rev. F; ECN 08-518
© 2008 Bradley Corporation
Page 1 of 10
9/29/08
Installation
S19-315BF
S19-315BF
S19-315FBF
S19-315PBF
S19-315FPBF
Barrier Free Recess-Mounted
Drench Shower with Barrier Free
Cabinet-Concealed Swing-Down
Eyewash
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . 2
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Rough-Ins. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation Instructions. . . . . . . . . . . . . . . . 5–6
Drench Shower Components and Parts List . 7
Eyewash Components . . . . . . . . . . . . . . . . 8–9
Eyewash Parts List. . . . . . . . . . . . . . . . . . . . 10
S19-315FBF
P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX 262.251.5817
bradleycorp.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bradley S19-315BF
Summary of Contents for Bradley S19-315BF
- Page 1 Eyewash Parts List....10 S19-315FBF 215-1573 Rev. F; ECN 08-518 P.O. Box 309, Menomonee Falls, WI USA 53052-0309 © 2008 Bradley Corporation PHONE 800.BRADLEY (800.272.3539) FAX 262.251.5817 bradleycorp.com Page 1 of 10 9/29/08...
- Page 2 For questions regarding the operation or installation of this product, visit www. bradleycorp.com or call 1-800-BRADLEY. Product warranties and parts information may also be found under ”Products” on our web site at www.bradleycorp.com. 9/29/08 Bradley Corporation • 215-1573 Rev. F; ECN 08-518...
- Page 3 1" (25mm) NPT to showerhead 33-5/8" (854mm) 16-15/16" (430mm) 41-3/4"–46" (1060mm–1168mm) from floor 33"–37-1/4" (838mm–946mm) max. to floor 3" (76mm) 1-1/4" (32mm) 7-1/4" waste (184mm) 1" (25mm) nominal copper tube supply Bottom View Bradley Corporation • 215-1573 Rev. F; ECN 08-518 9/29/08...
- Page 4 19" (483mm) min. 19" (483mm) min. to 23-1/4" (591mm) max. to 23-1/4" (591mm) max. bottom of cabinet bottom of cabinet Wall opening to floor to floor 25-5/8" (651mm) wide 32-1/8" (816mm) high 9/29/08 Bradley Corporation • 215-1573 Rev. F; ECN 08-518...
-
Page 5: Installation
S19-315BF S19-315FBF S19-315PBF S19-315FPBF NOTE: Use teflon tape Supplied by only. installer NOTE: Use teflon tape only. Secure cabinet to wall, four places. Bradley Corporation • 215-1573 Rev. F; ECN 08-518 9/29/08... -
Page 6: Connect Water Supply
S19-315BF, S19-315FBF, S19-315PBF, S19-315FPBF Installation Connect Water Supply Mount safety sign to wall. To showerhead Connect 1" NPT supply piping Exploded view of valve and handle assembly 9/29/08 Bradley Corporation • 215-1573 Rev. F; ECN 08-518... - Page 7 Service Prepacks Valve Mounting Hardware Prepack (includes Valve Mounting Bracket, U-Bolt, Nuts and Washers) S45-2236 Screw Prepack (includes twelve screws and Torx Power Bit) S45-2245 Valve/Handle Prepack (includes Handle and Valve Assembly) Bradley Corporation • 215-1573 Rev. F; ECN 08-518 9/29/08...
- Page 8 S19-315BF, S19-315FBF, S19-315PBF, S19-315FPBF Installation Assembly of Components for Eyewash (parts list on page 10) NOTE: Shown in the “ON” position. NOTE: Items 1a-1w come preassembled as Item 1. 10 (Tailpiece) 10 (Tubular Trap) 9/29/08 Bradley Corporation • 215-1573 Rev. F; ECN 08-518...
- Page 9 Installation S19-315BF, S19-315FBF, S19-315PBF, S19-315FPBF Assembly of Components for Eyewash continued . . . EMERGENCY EYEWASH PULL HANDLE TO ACTIVATE UNIT Bradley Corporation • 215-1573 Rev. F; ECN 08-518 9/29/08...
- Page 10 Bolt, 5/16"-18 x 1" 125-001DA O-Ring 160-458 Bolt, 5/16"-18 x 3/4" 131-082 Base S27-102 Stop Valve 160-428 Screw, Set 169-348 Union 113-1058 Shank 169-639 1/2" Elbow, 90° 110-115 Hex Nut 142-002CB Washer 9/29/08 Bradley Corporation • 215-1573 Rev. F; ECN 08-518...
