Costway TY557833 Owner's Manual

Children's electric toy car
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CHILDREN'S
ELECTRIC TOY CAR
• Suitable for 37~96 months
• Maximum user weight: 30kgs
• Adult assembly required
OWNER'S MANUAL
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important
information.
Before first time use, charge the battery for at least 4-6 hours.
ITEM :TY557833

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TY557833 and is the answer not in the manual?

Questions and answers

Related Manuals for Costway TY557833

Summary of Contents for Costway TY557833

  • Page 1 CHILDREN'S ELECTRIC TOY CAR ITEM :TY557833 • Suitable for 37~96 months • Maximum user weight: 30kgs • Adult assembly required OWNER'S MANUAL Read and understand this entire manual before using! Please keep this manual for future reference as it contains important information.
  • Page 2 caution WARNING CHOKING HAZARD - Small parts. Not suitable for children under 37 months. Use the vehicle on generally level ground ONLY! IMPORTANT This label means the information or assembly for One Wheel Drive version ONLY! This label means the information or assembly for Two Wheels Drive version ONLY! H/L SPEED This label means the information for High/Low Speed version ONLY! WARNING!

  • Page 3: Parts List

    Parts List Q’ty Q’ty Par t REMARKS Par t REMARKS PART PART PART PART PICTURE PICTURE (pcs) (pcs) NAME NAME Driving Vehicle wheel body Handle Wheel Steering Seat shaft Placed Front alxe in the Rear axle assembly plate package Placed Placed Ø5 Ø10...
  • Page 4 Parts List Par t Q’ty REMARKS Q’ty REMARKS PART PART PART PART PICTURE PICTURE (pcs) (pcs) NAME NAME Placed on the Ø5 nut Charger steering wheel Assembly package Q’ty REMARKS Q’ty Par t Par t REMARKS PART PART PART PART PICTURE PICTURE (pcs)

  • Page 5: Parts Diagram

    Parts Diagram NOTE: Some parts shown are assembled on both sides of vehicle Tools Required Screwdriver(not included) Pliers(not included)

  • Page 6: Assembly Steps

    Assembly Steps • Your new vehicle requires adult assembly. Please set aside at least 40 minutes for assembly. Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state. Care should be taken in unpacking and assembly of the vehicle.
  • Page 7 Assembly Steps ● Remove all the parts from the rear axle. ● Insert the real axle through the hole in the rear of the vehicle body. Rear axle ● Fit the driving wheel onto the Driving wheel rear axle from the left side(standing at the rear of the vehicle body).
  • Page 8 Assembly Steps ● Remove a Ø10 locknut and a Ø12 washer from the front axle. And leave Ø12 washer over a Ø12 washer. ● Fit a wheel onto the front axle. Ø12 washer ● Fit a Ø12 washer onto the front axle. ●...
  • Page 9 Assembly Steps ● Remove the screw in the battery cover on the back of the handle bar with a screwdriver and lift to open. ● Insert two “AA” (LR6) alkaline batteries into the handle bar. ● Replace the battery cover. NOTE: The products does not included “AA”...
  • Page 10 Assembly Steps ● Locate the red connector and plug it into Fuse box the terminal on battery. Red connector ● Insert the tabs on the seat into the slots in M5x12 machine screw the vehicle body, and tighten a M5x12 Seat machine screw to secure it with a screwdriver.

  • Page 11: How To Operate Your Vehicle

    How To Operate Your Vehicle WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • Never use in roadways, near cars, on or near steep inclines or steps, swimming pools or other bodies of water.
  • Page 12 How To Operate Your Vehicle Ensure the power switch has been turned on Use Operation( Sound buttons Forward-backward Power switch switch Foot padeal H/L SPEED Sound buttons ADVANCED USE - High speed Drive High/low speed switch Make sure your child Power switch knows how to steer, how to start and stop the vehicle and knows the...

  • Page 13: Charging Your Vehicle

    Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger my cause a fire or explosion. - Do not use the battery or charger for any other product.
  • Page 14 Charging Your Vehicle 1. Open the cover of the socket (the socket is at the rear of the vehicle) 2. Plug the charger port into the input socket. 3. Plug the charger plug into a wall outlet. The battery will begin charging. WARNING! This product with CHARGING PROTECTION: When charging, all the functions will be cut off!

  • Page 15: Troubleshooting Guide

    Troubleshooting Guide ■ PROBLEM: The vehicle does not run PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for a full 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped.

  • Page 16: Maintaining Your Vehicle

    Troubleshooting Guide ■ PROBLEM: The vehicle does not run very long. POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old.

  • Page 17: Disposal Of Battery

    Disposal Of Battery Disposal Of Batter y ● Your sealed lead-acid battery must be recycled or disposed of in an environmentally sound manner. ● Do not dispose of your lead-acid battery in a fire. The battery may explode or leak. ●...
