Wize PRG11A Instruction Manual page 10

Universal projector mount kit
Hide thumbs Also See for PRG11A:
Table of Contents

Advertisement

6 -3
M AKE A DJ US T M ENT S- R OLL
Adjust the roll by turning the knob labeled "roll"
RU
Réglez le rouleau en tournant le bouton étiqueté "rouler"
pitch
SCREEN
"roll"
roll
7
L O CK AND M ICRO -AD JUST
Tighten the pitch and roll lock screws, then, if required, use pitch and roll knobs to
micro adjust the image.
RU
.
Serrer la vis de blocage de tangage et de roulis, puis, si nécessaire, utilisez les bou-
tons de tangage et de roulis de micro-réglage de l'image.
pitch lock
pitch
roll lock
yaw
roll
10
,
,
roll
yaw
pitch
SCREEN
SCREEN
JKR311824-0001
