INSTALLATION/OPERATION INSTRUCTION
Local control
buttons
Projector
Lift
bottom
plate
Universal
projector
bracket
(optional)
Elegant ceiling
closure
Wize
Wize PL180L, PL300
Motorized projector lifts
Capacitor (Junction box)
– high-quality mount solutions for
audio-video installations
Lift hanger
Motor
Lift top plate
Lift top plate
Running belt
Stabilizing
aluminum
scissor
Screw pole
Remote
control
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wize PL180L
Summary of Contents for Wize PL180L
- Page 1 Wize PL180L, PL300 Motorized projector lifts INSTALLATION/OPERATION INSTRUCTION Lift hanger Capacitor (Junction box) Motor Local control buttons Lift top plate Lift top plate Running belt Projector Stabilizing aluminum Lift scissor bottom plate Universal Screw pole projector bracket (optional) Elegant ceiling...
- Page 2 IMPROPER INSTALLATION OR ASSEMBLY. READ THE FOLLOWING WARNINGS BEFORE BEGINNING. Do not use this product for any purpose not explicitly specified by Wize AV. Improper installation may cause property damage or personal injury. If you do not understand these directions, or have doubts about the safety of the installation, contact Wize AV Customer Service or call a qualified contractor.
-
Page 3: Table Of Contents
3. Connection ..............................6 3.1 Electric connection ..........................6 3.2 Limit switch adjustment ........................6 Drawings ..............................7 4.1 PL180L, PL300 ceiling closure panel ....................7 4.2 PL180L, PL300 closure frame ......................8 4.3 PL180L, PL300 bottom plate ....................... 9 Warranty ............................10... -
Page 4: Related Data
1. Related data PL 1 80 L PL 300 Model# Loading capacity, kg 7 00x508x280 Specification AxBxC, cm 700х508х220 Lift height (closed), cm Lift height (fully extended), cm Travelling distance, cm Net weight, kg 29,5 Lift packing dimensions, cm 995x725x460 995x725x520 Running speed 45 mm/sec... -
Page 5: Installation
2. Installation 2.1 Before Installation: 1. Open the carton and take out the lift. Check the lift and accessories to see if they are in well condition. 2. Hold the lift and connect to proper power. Run it up and down be the equipped IR and RF or remote control to see if it works normally. -
Page 6: Ceiling Closure Panel Installation
2.3 Ceiling closure panel installation 1. According to the ceiling material to choose proper screw, fix the closure frame on the ceiling opening. 2. Connect power, extend the lift by wire switch. 3. Insert the four screw poles into the related installation holes in the triangle installation plate (A) on the ceiling frame and the according holes on the lift bottom plate (B). -
Page 7: Connection
3. Connection 3.1 Electric connection: 1. The lift operates on AC220V-240V, 50Hz, 1 ph. current. 2. Junction box is a white box located under the lift top plate. 3. Change the EU plug to your local standard if necessary. All wiring should comply with local and national electrical codes and should be done by a licensed electrician. -
Page 8: Drawings
4. Drawings 4.1 PL180L, PL300 ceiling closure panel *all measurements are in mm... -
Page 9: Pl180L, Pl300 Closure Frame
4.2 PL180L, PL300 closure frame *all measurements are in mm... -
Page 10: Pl180L, Pl300 Bottom Plate
4.3 PL180L, PL300 bottom plate *all measurements are in mm... -
Page 11: Warranty
Wize AV will not be liable for any damages arising out of the use of, or inability to use, Wize AV products. Wize AV bears no responsibility for incidental or consequential damages. This includes, but is not limited... -
Page 12: Ce Declaration Of Conformity
6. CE Declaration of conformity We hereby declare that Wize electrical products fulfil the basic requirements for product safety as supported by tests performed according to the following international standards: EN 62233:2008 Low voltage directive (LVD); Human exposure to Electromagnetic fields (EMF) up to 300...
