- Page 1 BDE-D-KTA User manual Your global partner for entrance solutions www.record.group...
- Page 2 Document identification Article nr.: 102-903401276 Version: Publication date: 01/08/2022 Translation of the original manual Subject to technical modifications Copyright © agtatec ag...
-
Page 3: Table Of Contents
Table of contents Table of contents List of changes ..............................1 Safety................................. Presentation of warning signs....................... Intended purpose of use ........................General hazards ........................... State of technology ..........................Personal protective equipment ......................Spare parts and liability ........................2 General information ............................10 Purpose and use of the instructions ..................... -
Page 4: List Of Changes
List of changes List of changes Change Location Complete revision of all Sections and content Entire document New Section structure Entire document Revision of all graphics Entire document 4 / 20 BAL_BDE-D-KTA_EN_1V1_REC_102-903401276... -
Page 5: Safety
Safety Safety Presentation of warning signs Various symbols are used in this guide for easier understanding: NOTICE Useful advice and information to ensure correct and efficient workflow of the system. IMPORTANT Specific details which are essential for trouble-free operation of the system. IMPORTANT Important details which must be read for proper function of the system. -
Page 6: General Hazards
Safety General hazards The following section lists hazards that can be caused by the system even when used as intended. To reduce the risk of malfunction, damage to property or injury to persons and to avoid dangerous situations, the safety instructions listed here must be observed. The specific safety instructions in the other sections of this manual must also be observed. - Page 7 Safety CAUTION Risk of material damage or injury due to unforeseen opening, closing or turning of the door! a) The door can open, close or turn unexpectedly. This may result in damage to property or injury to persons. ð No persons may be present in the opening area of the system. ð...
-
Page 8: State Of Technology
Safety DANGER Danger to life due to electric current! a) In case of contact with live parts, there is an immediate danger to life due to electric shock. Damage to or removal of the insulation or individual components can be life-threatening. ð... -
Page 9: Spare Parts And Liability
Safety The head protection serves to protect against falling and flying parts and materials. It also protects the head from bumping into hard objects. Protective goggles protect the eyes from flying parts, dust, splinters or splashes. Protective gloves are designed to protect hands from friction, abrasions, punctures or serious injury and from burning caused by contacting hot surfaces. -
Page 10: General Information
General information General information Purpose and use of the instructions These instructions are an integral part of the system and enable efficient and safe handling of the sys- tem. In order to ensure proper functioning, the instructions must be accessible at all times and kept in the immediate area of the system. -
Page 11: Definition Of Terms
General information Definition of terms Term: Explanation: System The term is also used in these instructions as a synonym for the product. Door operators, revolving doors, sliding doors, etc. are re- ferred to as a system. If information in these instructions refers to a specific type, this is shown accordingly in the text. -
Page 12: Description
Description Description Identification Front view Rear view Side view BUILT-IN TYPE Rear view Side view Front view Keypad with 6 keys DIP-switch CAN-termination / selector BDE 1 or 2 Navigation information Terminal board CAN bus LCD display Terminal board for external service lock 12 / 20 BAL_BDE-D-KTA_EN_1V1_REC_102-903401276... -
Page 13: Connection To Control Unit
This chapter is intended for service personnel. Connection to the CAN bus CAN adapter BDE-D-KTA Connect the connecting cable to the CAN connection and connect it to the CAN connection of the controller (wires twisted in pairs). DIP switches (S1-1, S1-2) must be set before connection! These are set to ON at the factory. -
Page 14: Technical Data
Technical Data Technical Data Supply voltage: 24 VDC from CAN bus Connected load: < 2 W Dimension of front panel: 60 x 60 mm, adapted for Feller or Jung systems Dimension built-in type: 92 x 44 mm Temperature range: -20… +50°C Resolution of LCD display: 112 x 64 pixels, with background light 14 / 20... -
Page 15: Operation
Operation Operation Key functions Function Operating button – Selection of the corresponding operating mode – Display of additional information – Initiating the operation lock – Restart the controller – Restart Hardware of the operating unit NOTICE You can switch to the menu display by briefly pressing the INFO BUTTON twice. In this area, the keys have the function printed above or below the keys (navigation informa- tion). -
Page 16: Menu Display
Operation Type Instructional symbol Example 1: Operating mode with information symbol Example 2: Operating mode with error symbol Example 3: Operating mode with both instructional symbols Menu display You can switch to the menu display by briefly pressing the INFO Button twice (double-click). -
Page 17: Restart Via Keyboard
– The control panel keys are locked. – Unwanted manipulation of the control unit is impaired. – The locked state of BDE-D-KTA control unit is displayed on the screen with a key sym- bol (bottom left). Unlocking the control unit... -
Page 18: Malfunctions
Sometimes malfunctions can be remedied by the operator himself. If the operator do not rem- edy the fault, contact the responsible service centre. Before calling, please note the information which is shown on the display of the BDE-D-KTA operating unit. This information provides the service technician with important information for possible troubleshooting. -
Page 19: Taking Out Of Service And Disposal
Taking out of service and disposal Taking out of service and disposal Decommissioning When shutting down or taking out of service, the system is disconnected from the mains supply and any existing battery is unplugged. NOTICE After each temporary shutdown a new commissioning must be carried out. Dismantling and disposal IMPORTANT All machine parts must be sorted by type of material and disposed of according to... - Page 20 Your global partner for entrance solutions...
